Purpose:
To empower owners and mechanics to perform efficient and correct maintenance and repair, saving time and money.
Target Audience:
Suzuki KingQuad LT-A500XP/Z owners, DIY enthusiasts, home mechanics, and professional service technicians.
Visual Aid Quality:
Filled with illustrations, photographs, and diagrams for part identification and proper assembly.
Accessibility:
Easily transferable between devices or printable for on-site work.
Manual Type:
Factory Service Manual / Workshop Manual
Delivery Method:
Digital Download
Content Summary:
Detailed service information, step-by-step repair instructions, maintenance specifications, operation of major systems, diagnostics, troubleshooting, overhaul, component removal/installation, illustrations, photographs, diagrams.
General Information:
Included
Engine:
Complete overhaul, troubleshooting, diagnostics, removal/installation, internal components.
Suspension:
Front and rear suspension systems, including shock absorbers, springs, linkage, and adjustments.
Driveline Axle:
Front and rear drive shafts, CV joints, differentials, axle shafts, and related components.
Brake:
Hydraulic brake system, including calipers, master cylinders, brake lines, rotors, pads, and bleeding procedures.
Transmission Transaxle:
Automatic transmission, torque converter, planetary gears, clutch packs, lubrication, and troubleshooting.
Steering:
Steering column, handlebars, tie rods, steering knuckles, and adjustment procedures.
Body Accessories:
Body panels, fenders, racks, seat, lighting, electrical accessories, and installation/removal.
Scheduled Maintenance:
Recommended service intervals for oil changes, filter replacements, inspections, etc.
Troubleshooting:
Diagnostic flowcharts and common problem resolutions for various systems.
Overhaul:
Detailed instructions for complete disassembly and reassembly of major components.
Removal Installation:
Step-by-step guidance for removing and reinstalling all major parts and systems.
Depth Of Coverage:
Comprehensive; covers everything from basic maintenance to complete engine rebuilds and advanced diagnostics.
Engine Type:
4-stroke, liquid-cooled, DOHC, V-twin
Bore X Stroke:
Not specified in product info, but typically around 72.0 mm x 60.2 mm
Compression Ratio:
Not specified in product info, but typically around 9.3:1
Horsepower:
Not specified in product info, estimated around 30-35 HP
Torque:
Not specified in product info
Fuel Delivery:
Electronic Fuel Injection (EFI)
Fuel Type:
Unleaded gasoline
Recommended Oil Viscosity:
Refer to manual for specific Suzuki recommendation (typically 10W-40 or 20W-50)
Oil Capacity:
Refer to manual for specific capacity (typically around 2.5-3.0 liters with filter change)
Ignition System:
Electronic ignition (CDI)
Cooling System:
Liquid-cooled
Starting System:
Electric starter and potentially recoil starter
Transmission Type:
Automatic (CVT - Continuously Variable Transmission)
Drive System:
Shaft drive, selectable 2WD/4WD with differential lock
Gear Selection:
High (H), Low (L), Neutral (N), Reverse (R), Park (P)
Transmission Fluid Type:
Refer to manual for specific Suzuki recommendation (typically dedicated ATV CVT fluid or specific ATF)
Transmission Fluid Capacity:
Refer to manual for specific capacity.
Overall Length:
Not specified in product info, but typically around 83-85 inches
Overall Width:
Not specified in product info, but typically around 47-49 inches
Overall Height:
Not specified in product info, but typically around 48-50 inches
Dry Weight:
Not specified in product info, but typically around 600-650 lbs
Ground Clearance:
Not specified in product info, but typically around 10-11 inches
Towing Capacity:
Not specified in product info, but typically around 650-1300 lbs
Rack Capacity Front:
Not specified in product info, but typically around 100 lbs
Rack Capacity Rear:
Not specified in product info, but typically around 200 lbs
Atv Safety Standards:
Adheres to ANSI/SVIA standards where applicable for ATVs.
Braking System:
Multi-disc hydraulic brakes front and rear, sealed for protection.
Engine Braking:
Provided by the CVT system, assisting with downhill control.
Lighting:
Dual headlights, taillight, and brake light for visibility.
Ergonomics:
Designed for rider comfort and control, contributing to safer operation.
Display Panel:
Digital instrument cluster providing speed, RPM, fuel level, gear indicator, odometer, trip meters, 4WD indicator, etc.
Selectable 4Wd:
Electronic push-button engagement of 2WD/4WD with front differential lock for optimal traction.
Accessories Power:
Typically includes a DC power outlet for charging accessories.
Engine Oil Change:
Typically every 600 miles or 6 months (refer to manual for exact interval).
Air Filter Cleaning:
Regular inspection and cleaning, especially in dusty conditions (refer to manual).
Spark Plug Inspection:
Typically at first service and then periodically (refer to manual).
Valve Clearance Check:
Initial check at break-in, then at longer intervals (refer to manual).
Engine Oil Type:
Suzuki recommends specific motorcycle or ATV engine oil meeting API SG/SH/SJ or higher, JASO MA certified. Viscosity typically 10W-40 or 20W-50.
Coolant Type:
Suzuki recommends a permanent type antifreeze coolant (ethylene glycol based) with a 50/50 mix with distilled water.
Brake Fluid Type:
DOT 4 hydraulic brake fluid.
Common Wear Items:
CV joint boots, brake pads, tires, battery, and drive belts (for CVT) are common wear items on ATVs.
Electrical Connections:
Ensuring clean and tight electrical connections is crucial for reliable operation, especially in off-road environments.
Manufacturer:
Suzuki Motor Corporation
Legacy:
Suzuki has a long-standing reputation for producing reliable and capable ATVs.
Kingquad Lineage:
The KingQuad series has evolved into a premium line of utility ATVs, known for their powerful engines and advanced features.
2009 Updates:
The 2009 model likely received minor updates or refinements over previous generations. Specific details are in the manual.
