Suzuki RM85 K9 Workshop Repair Manual All 2009 ONWARDS ModelS COVERED

Normaler Preis: $16.99
Verkaufspreis: $16.99
Normaler Preis
Grundpreis: pro

16 people are viewing this right now

Typ: Motorcycle

Anbieter:

Art.-Nr: 125943

Stichworte: 2009 Motorcycle Motorcycles RM Series RM85 RM85 K9 Suzuki

Produktvarianten

Beschreibung

The RM85, introduced from the 2009 model year onwards, is a high-performance youth motocross motorcycle renowned for its competition-oriented design. This model features a potent liquid-cooled, 2-stroke, single-cylinder engine with a displacement of 104 cc, delivering an estimated 23-25 horsepower. Its engineering prioritizes agility and power, with a focus on providing riders with a competitive edge. Key aspects include its robust frame for stability, powerful hydraulic disc brakes for reliable stopping, and ergonomics designed for optimal rider control during demanding off-road use. The RM85 represents a commitment to performance and a strong legacy in the motocross segment. This comprehensive workshop manual provides extensive coverage for the RM85 (K9 generation and onwards), encompassing all aspects of service, repair, and maintenance. It details procedures for complete engine teardown and assembly, transmission servicing, suspension adjustments, brake system maintenance, fuel system tuning, and electrical system diagnostics. The manual includes step-by-step instructions, exploded views, and detailed diagrams to assist owners and technicians in performing regular servicing, troubleshooting common issues, and conducting full component rebuilds. Its purpose is to ensure the optimal performance, reliability, and longevity of the RM85 through clear, accessible technical guidance.

🏷️ Basic Information

Identification

Make:

Suzuki

Model:

Generation

Generation Code:

Applicable Model Years:

2009 onwards

👋 Introduction

Market Position

Segment:

High-performance youth motocross motorcycle

Competitive Analysis

Key Competitors:

KTM 85 SX, Yamaha YZ85, Kawasaki KX85, Honda CR85 (though CR85 was phased out before this era)

Key Features

Vehicle Focus:

Competition-oriented, lightweight, powerful two-stroke engine

Manual Value Proposition:

Enables owners and technicians to perform comprehensive servicing, repairs, and optimizations, maximizing performance and lifespan.

Manual Usability

Ease Of Use:

Designed for clarity with step-by-step instructions, exploded views, and diagrams, making complex procedures accessible.

📋 Manual Details

Coverage Areas

Primary Coverage:

Workshop Service and Repair

Page Count

Estimated Pages:

Extensive (specific count not provided, but described as 'huge amount of detailed repair information')

Manual Type

Type:

Workshop Manual / Service Manual / Repair Manual

Language

Language:

English

Format

Format:

PDF (Digital Download)

📖 Manual Coverage

Systems Covered

Engine:

Complete engine teardown, assembly, tuning, and diagnostics

Transmission:

Clutch system, gearbox disassembly, inspection, and reassembly

Suspension:

Front forks (telescopic, USD type), rear shock absorber, linkages, and adjustments

Brakes:

Front and rear brake systems (hydraulic disc), caliper service, master cylinder, bleeding procedures

Fuel System:

Carburetor removal, cleaning, adjustment, jetting, fuel lines

Electrical System:

Ignition system, CDI unit, lighting, wiring diagrams (general overview for a dirt bike, specific component tests)

Cooling System:

Liquid-cooled engine, radiator, hoses, coolant specifications

Exhaust System:

Exhaust pipe and silencer removal and installation

Frame And Body:

Chassis components, seat, tank, fenders, handlebars, footpegs

Procedures Included

Maintenance:

Regular servicing, oil changes, filter replacements, chain adjustment, spark plug service

Troubleshooting:

Diagnostic guidance for common problems and performance issues

Repair:

Detailed step-by-step repair instructions for all major components

Overhaul:

Complete engine and component rebuild procedures

Adjustment:

Carburetor tuning, suspension adjustments, clutch and brake lever adjustments

Technical Depth

Depth:

Comprehensive, covering all aspects from basic maintenance to complete engine rebuilds and diagnostics

Diagnostics:

Fault finding and troubleshooting guidance

Diagrams And Illustrations:

Detailed exploded views and illustrations for easy identification and reassembly

📊 Manual Specifications

File Format

Format:

Portable Document Format (PDF)

Compatibility:

PC & Mac compatible (Windows 95, 98, 2000, NT, XP, Vista, 7, 8, etc.)

Print Quality

Quality:

High-quality, suitable for printing

Binding Type

Type:

Not applicable (Digital Download)

Paper Type

Type:

Not applicable (Digital Download)

⚙️ Engine Specifications

Primary Engine

Type:

Liquid-cooled, 2-stroke, reed valve, single-cylinder

Bore X Stroke:

48.0 mm x 46.8 mm (typical for RM85)

Displacement:

104 cc (typical for RM85)

Compression Ratio:

9.4:1 (typical, may vary slightly)

Carburetor:

Mikuni VM28SS (typical for RM85)

Ignition:

Digital CDI

Lubrication:

Premix (2-stroke oil mixed with gasoline)

Performance

Horsepower:

Approximately 23-25 HP (estimated, varies by tuning and model year)

Torque:

Not typically specified in readily available public data for this segment, but the manual would detail this.

Fuel System

Fuel Type:

Unleaded gasoline (minimum 91 octane recommended)

Oil Type:

High-quality 2-stroke racing oil (specific recommendations in manual)

🔧 Transmission

Standard

Type:

6-speed constant mesh

Clutch:

Wet multi-plate

Features

Gear Ratios:

Detailed in the manual (specific ratios for each gear)

Final Drive:

Chain drive

📐 Dimensions

Exterior

Overall Length:

Approximately 1845 mm (typical for RM85)

Overall Width:

Approximately 760 mm (typical for RM85)

Overall Height:

Approximately 1160 mm (typical for RM85)

Wheelbase:

Approximately 1270 mm (typical for RM85)

Ground Clearance:

Approximately 325 mm (typical for RM85)

Weights

Dry Weight:

Approximately 75 kg (typical for RM85)

Fuel Tank Capacity:

5.7 Liters (typical for RM85)

🛡️ Safety Features

Ratings

Certification:

N/A (Off-road vehicle, not subject to road safety ratings)

Active Features

Brakes:

Powerful hydraulic disc brakes front and rear for superior stopping power.

Passive Features

Chassis Design:

Robust frame providing stability and rider control.

Ergonomics:

Designed for optimal rider positioning and control during aggressive riding.

💡 Technology Features

Infotainment

System:

N/A (Pure performance motocross bike, no infotainment features)

Driver Assistance

Features:

N/A (No electronic rider aids)

Connectivity

Features:

N/A (No electronic connectivity features)

Engine Management

System:

Digital CDI ignition system for precise spark timing, contributing to crisp throttle response and power delivery.

🔧 Maintenance

Service Intervals

Oil Change:

Frequent intervals recommended, typically every 5-10 riding hours or as specified in the manual, for premix engines.

Air Filter Cleaning:

After every few rides or when visibly dirty, especially in dusty conditions.

Chain Maintenance:

Regular cleaning, lubrication, and tension adjustment (every ride or every few hours).

Spark Plug Service:

Inspection and cleaning/replacement at recommended intervals (e.g., every 10-15 hours).

Fluid Specifications

Engine Oil:

Specific 2-stroke premix oil recommended by Suzuki (e.g., Castrol, Motul, Yamalube 2-stroke racing oil) - details in manual.

Coolant:

Permanent type antifreeze/coolant mixture (50/50 with distilled water), specific brand/type may be recommended.

Brake Fluid:

DOT 4 hydraulic brake fluid.

Transmission Oil:

Not applicable, as it's a 2-stroke with premix lubrication for the engine and a separate gearbox oil (likely SAE 80 or 85W).

Known Issues

Common Wear Items:

Piston rings, piston, clutch plates, brake pads, chain and sprockets, wheel bearings, fork seals are common wear items on high-performance motocross bikes.

Carburetor Tuning:

Requires precise jetting and adjustment for optimal performance at different altitudes and temperatures. The manual provides crucial guidance.

Suspension Maintenance:

Regular fork oil changes and seal replacement are vital for consistent damping performance.

📚 Vehicle History

Brand Heritage

Manufacturer:

Suzuki Motor Corporation

Motorsport Focus:

Suzuki has a long and successful history in motorcycle racing, particularly in motocross and off-road disciplines.

Model Evolution

Rm Series Legacy:

The RM85 is part of Suzuki's highly regarded RM series, known for its performance and reliability in the motocross world.

Generational Updates:

The 'K9' designation typically signifies a model year update, which might include minor chassis, engine, or aesthetic refinements over previous generations.

Production

Production Start Year:

The RM85 model line was introduced in the early 2000s, with continuous updates.

🏆 Awards & Recognition

Recognitions

Motocross Segment:

The RM85 has consistently been praised in motocross reviews for its strong engine performance, agile handling, and competitive pricing within its class.

Certifications

Manual Quality:

The manual itself is a valuable tool, certified by its comprehensive nature and utility for technicians and enthusiasts alike.
