🏷️ Basic Information

Make:

Aprilia

Model:

SL750 Shiver

Year:

2007-2010

👋 Introduction

Category:

Middleweight Naked Sportbike

Target Audience:

Riders seeking a versatile, sporty, and engaging motorcycle experience with a focus on accessible performance and Italian design.

Key Competitors:

Yamaha FZ8, Kawasaki Z800, Suzuki GSX-S750, Triumph Street Triple

Engine Layout:

V-twin architecture

Design Philosophy:

Italian sportbike styling with a focus on performance and rider engagement.

Chassis Type:

Steel trellis frame for agility and feedback.

📋 Manual Details

Systems Covered:

Engine, Fuel System, Ignition System, Cooling System, Lubrication System, Transmission, Clutch, Chassis, Suspension (Front and Rear), Brakes (Front and Rear), Electrical System, Lighting, Instruments, Bodywork, Troubleshooting, Maintenance

Page Count:

N/A (Digital Content)

Manual Type:

Service and Repair Manual

Language:

English

Format:

PDF

📖 Manual Coverage

Engine Mechanical:

Detailed procedures for engine disassembly, inspection, repair, and reassembly of all internal components including cylinder head, valves, pistons, connecting rods, crankshaft, and oil pump.

Fuel System:

Comprehensive coverage of fuel injection system components, fuel pump, injectors, throttle body, fuel pressure regulator, and diagnostic procedures.

Ignition System:

Details on ignition timing, spark plugs, ignition coils, ECU control, and troubleshooting ignition faults.

Cooling System:

Information on radiator, cooling fan, thermostat, water pump, coolant flow, and bleeding procedures.

Lubrication System:

Coverage of the oil sump, oil pump, oil filter, oil passages, and oil change procedures.

Transmission Drivetrain:

Detailed procedures for clutch operation, gear shifting mechanism, transmission disassembly, inspection, and reassembly. Includes information on chain drive and sprockets.

Chassis Frame:

Information on frame construction, steering head, swingarm, and related components.

Front Suspension:

Complete overhaul procedures for front forks, including oil changes, seal replacement, spring inspection, and damping adjustments.

Rear Suspension:

Details on rear shock absorber adjustment and rebuild (where applicable), swingarm bearing service, and linkage maintenance.

Front Brakes:

Procedures for front brake caliper service, master cylinder overhaul, brake line replacement, pad and disc inspection/replacement, and bleeding.

Rear Brakes:

Procedures for rear brake caliper service, master cylinder overhaul, brake line replacement, pad and disc inspection/replacement, and bleeding.

Electrical System:

Wiring diagrams, component testing, battery maintenance, charging system, starter motor, and all electrical circuits.

Lighting System:

Headlight, taillight, brake light, turn signal, and instrument illumination bulb replacement and troubleshooting.

Instrumentation:

Speedometer, tachometer, fuel gauge, and warning light diagnostics and repair.

Bodywork Fairings:

Information on removal and installation of body panels, seat, fuel tank, and other cosmetic components.

Basic Maintenance:

Oil changes, filter replacements, chain lubrication and adjustment, brake fluid checks, tire pressure checks, coolant checks, and general inspections.

Troubleshooting:

Systematic diagnostic guides for common and uncommon problems, including no-start conditions, poor running, electrical faults, and braking issues.

Engine Overhaul:

Complete engine rebuild procedures with torque specifications and clearances for all internal engine components.

Transmission Repair:

Detailed steps for gearbox disassembly, component inspection, and reassembly, including gear and bearing replacement.

Suspension Rebuild:

Complete fork and rear shock absorber service and rebuilding instructions.

Brake System Service:

Bleeding procedures, component replacement (pads, discs, lines, master cylinders, calipers), and system flushing.

Electrical Diagnostics:

Using multimeters and diagnostic tools to identify and repair electrical faults, including wiring harness issues and sensor failures.

Depth:

Comprehensive. Covers everything from routine maintenance to complete engine, transmission, and chassis rebuilds, including in-depth electrical diagnostics and troubleshooting.

📊 Manual Specifications

File Format:

Searchable PDF

Print Quality:

High-resolution, clear text and diagrams suitable for printing.

Binding Type:

N/A (Digital)

Paper Type:

N/A (Digital)

⚙️ Engine Specifications

Engine Type:

Four-stroke, liquid-cooled, 8-valve, DOHC V-twin

Displacement:

749.9 cc

Bore X Stroke:

94 mm x 54 mm

Compression Ratio:

11.0:1

Horsepower Peak:

Approx. 95 HP (70 kW) @ 9000 RPM

Torque Peak:

Approx. 78 Nm (57.5 lb-ft) @ 7000 RPM

Fuel Delivery:

Electronic Fuel Injection (EFI) with Ride-by-Wire throttle control

Fuel Type:

Unleaded gasoline, minimum 95 RON

Ignition Type:

Digital electronic ignition with variable advance

Cooling Method:

Liquid-cooled

Oil Type:

SAE 10W-40, API SG (or higher) motorcycle specific oil

Oil Capacity W Filter:

Approx. 2.8 Liters (2.9 US qt)

🔧 Transmission

Transmission Type:

6-speed sequential manual

Clutch Type:

Hydraulically operated, multi-plate wet clutch

Final Drive:

Chain drive (525 O-ring chain)

Gear Ratios:

Refer to manual for specific gear ratios; includes a close-ratio gearbox for sporty performance.

📐 Dimensions

Length:

Approx. 2170 mm (85.4 in)

Width:

Approx. 800 mm (31.5 in)

Height:

Approx. 1130 mm (44.5 in)

Wheelbase:

Approx. 1470 mm (57.9 in)

Seat Height:

Approx. 830 mm (32.7 in)

Dry Weight:

Approx. 190 kg (418.9 lbs)

Wet Weight:

Approx. 210 kg (463 lbs) (fully fueled)

Fuel Tank Capacity:

15 Liters (3.96 US gal)

🛡️ Safety Features

Safety Features Overview:

While no formal NCAP or IIHS ratings apply to motorcycles, the Shiver is equipped with robust braking systems and designed for predictable handling.

Brakes:

Dual 320 mm front discs with radial-mount 4-piston calipers; Single 240 mm rear disc with 2-piston caliper. Optional ABS available on some models/markets.

Tires:

High-performance sportbike tires (e.g., 120/70 ZR17 front, 180/55 ZR17 rear) for optimal grip.

Lighting:

Halogen headlight, LED taillight and brake light for visibility.

💡 Technology Features

Instrument Cluster:

Digital LCD display providing speedometer, tachometer, fuel level, odometer, trip meters, clock, coolant temperature, and gear position indicator.

Ride By Wire:

Electronic throttle control (ETC) for precise throttle response and potentially smoother power delivery.

ABS:

Anti-lock Braking System (ABS) was an optional feature on certain models and markets, enhancing braking safety.

Connectivity Features:

No Bluetooth or smartphone integration; primarily analog and digital instrumentation.

🔧 Maintenance

Oil Change Interval:

Every 6,000 km (3,700 miles) or 12 months, whichever comes first.

Oil Filter Replacement:

Every 12,000 km (7,500 miles) or 24 months, or with every oil change for optimal protection.

Air Filter Cleaning Replacement:

Inspect every 6,000 km (3,700 miles); clean or replace as needed. Replace every 12,000 km (7,500 miles).

Spark Plug Replacement:

Every 12,000 km (7,500 miles) or 24 months.

Chain Lubrication Adjustment:

Lubricate every 1,000 km (600 miles) and adjust tension as needed; check more frequently under adverse conditions.

Brake Fluid Flush:

Every 24,000 km (15,000 miles) or 24 months.

Coolant Replacement:

Every 24,000 km (15,000 miles) or 24 months.

Engine Oil:

SAE 10W-40, API SG (or higher), JASO MA/MA2 certified

Coolant:

Ethylene glycol-based coolant, 50% mixture with distilled water

Brake Fluid:

DOT 4

Clutch Fluid:

DOT 4 (Shared reservoir with front brake system)

Common Wear Items:

Clutch plates, brake pads, chain and sprockets, fork seals, wheel bearings.

Potential Electrical:

Occasional reports of voltage regulator issues or connector corrosion requiring attention.

Fuel System Notes:

Proper maintenance of the fuel system, including clean fuel and periodic injector checks, is important for optimal performance.

📚 Vehicle History

Manufacturer:

Aprilia is an Italian manufacturer renowned for its racing heritage and performance-oriented motorcycles, particularly in the sportbike and off-road categories.

Introduction Year:

The SL750 Shiver was introduced in 2007, marking Aprilia's entry into the middleweight naked sportbike segment with a focus on accessible performance and Italian flair.

Key Updates 2007-2010:

Minor updates may have occurred during this period, often related to ECU mapping, color schemes, and component suppliers. The core platform remained consistent.

Manufacturing Location:

Italy

🏆 Awards & Recognition

Motorcycle Reviews:

The Shiver was generally well-received for its engaging V-twin engine, agile handling, and stylish Italian design, often praised as a capable and fun all-rounder.

Customer Satisfaction:

Customer satisfaction often correlates with proper maintenance and the owner's understanding of the bike's character and performance.
