Segment:
Cruiser Motorcycle
Target Audience:
Owners seeking self-maintenance, independent repair shops, Harley-Davidson enthusiasts
Key Competitors:
Indian Motorcycles, Custom Choppers, other cruiser brands
Model Design:
Unique 'Rocker' styling with integrated rear suspension, distinctive fuel tank shape, and custom aesthetics
Manual Advantage:
Provides factory-level repair and maintenance guidance, crucial for maintaining the specific engineering of the FXCWC
Primary Coverage:
Service, Repair, and Maintenance
Secondary Coverage:
Troubleshooting, Diagnostics, Specifications
Type:
Factory Service Manual / Repair Manual
Powertrain:
Engine (Twin Cam 96B), Transmission (6-speed Cruise Drive), Clutch, Final Drive
Chassis:
Frame, Front Suspension (Telescopic Fork), Rear Suspension (Monoshock Swingarm), Wheels, Tires, Brakes (Front & Rear Disc)
Electrical:
Ignition System, Lighting (Headlight, Taillight, Signals), Instrumentation, Battery, Charging System (Alternator, Regulator), Starter System, Fuel Injection System (EFI)
Bodywork And Trim:
Fuel Tank, Fenders, Seat, Handlebars, Controls, Footpegs, Mirrors, Exhaust System
Routine Maintenance:
Oil Changes, Filter Replacements, Lubrication, Chain Adjustment (if applicable), Spark Plug Replacement, Air Filter Service
Repair Procedures:
Engine Top-End Rebuild, Transmission Disassembly/Reassembly, Clutch Service, Brake Caliper Overhaul, Suspension Component Replacement, Electrical Component Diagnosis and Repair
Troubleshooting Diagnostics:
Diagnostic Trouble Codes (DTCs), Symptom-Based Troubleshooting Guides, Electrical Schematics with Pinouts
Depth:
Comprehensive (from basic fluid checks to full engine and transmission rebuilds)
Diagnostic Tools:
References to Harley-Davidson specific diagnostic tools (e.g., WHIM, Digital Technician) and procedures
PDF Quality:
High-resolution, searchable text, printable pages
Print Recommendation:
Suitable for professional printing and binding
Ideal Binding:
Coil-bound or comb-bound for lay-flat usability in a workshop environment
Recommended Paper:
Durable, thicker paper stock for workshop conditions
Engine Type:
Air-cooled, Twin Cam 96B V-Twin
Displacement:
96 cubic inches (1584 cc)
Bore X Stroke:
3.75 in. x 4.38 in. (95.25 mm x 111.25 mm)
Valve Train:
Pushrod-actuated, overhead valves with hydraulic lifters; 2 valves per cylinder
Torque Delivery:
Estimated 92.6 lb-ft @ 3,500 RPM (Note: Official Harley-Davidson figures may vary slightly and are not provided in the product description)
Horsepower:
Not officially published by Harley-Davidson for this model, but generally in the 70-80 HP range.
Fuel Delivery:
Electronic Sequential Port Fuel Injection (ESPFI)
Fuel Type:
91 octane or higher recommended
Transmission Type:
6-Speed Cruise Drive
Gear Ratios:
1st: 9.312, 2nd: 6.419, 3rd: 4.747, 4th: 3.777, 5th: 3.279, 6th: 2.790
Clutch Type:
Clutched, 9-plate, wet
Clutch Fluid:
DOT 4 Brake Fluid (for hydraulic clutch system)
Crash Test Ratings:
Motorcycles are not typically subjected to standardized automotive crash test ratings.
Braking System:
Hydraulic disc brakes, front and rear
ABS Availability:
Optional ABS available on some 2008 models, check specific vehicle VIN.
Lighting:
Halogen headlight, LED taillight and brake light, amber incandescent front and rear turn signals
Instrumentation:
Analog speedometer, tachometer, fuel gauge, and indicator lights. Odometer, trip meter, and gear indicator may be digital.
Features:
Limited driver assistance features typical of motorcycles from this era. Focus is on core mechanical and electrical systems.
Features:
No advanced connectivity features like Bluetooth or smartphone integration on this model.
First Service:
1,000 miles (1,600 km) or 6 months
Subsequent Service:
Every 5,000 miles (8,000 km) or 12 months thereafter
Engine Oil:
Harley-Davidson Syn3 (20W-50) or equivalent premium synthetic V-twin motorcycle oil.
Transmission Oil:
Harley-Davidson Formula+ (or equivalent SAE 85W-140 gear oil)
Primary Chain Case Oil:
Harley-Davidson Formula+ (or equivalent SAE 85W-140 gear oil)
Brake Fluid:
DOT 4, Harley-Davidson Premium Synthetic Brake Fluid
Fork Oil:
Harley-Davidson Type E (or equivalent 15W fork oil)
Common Concerns:
Potential for charging system issues (stator/regulator), clutch drag, and normal wear and tear on suspension components. Fuel sensor accuracy can sometimes be a minor concern.
Manual Utility For Issues:
The manual provides detailed troubleshooting guides and specific diagnostic procedures for these common issues.
Harley Davidson Legacy:
Founded in 1903, Harley-Davidson is an iconic American motorcycle manufacturer renowned for its V-twin engines and cruiser-style motorcycles.
Softail Platform:
The Softail platform, introduced in 1983, is characterized by its hidden rear shock absorbers, mimicking the look of a hardtail frame.
Rocker Series:
The Rocker and Rocker C models were introduced in 2008 as part of the Softail family, featuring a unique, stretched-out, low-slung profile and a distinctive swingarm design.
Production Period:
The FXCWC Rocker Custom was produced from 2008 to 2011.
Manufacturing Location:
United States
