HARLEY DAVIDSON FXDWG DYNA WIDE GLIDE 2013 Service Repair Manual

Normaler Preis: $16.99
Verkaufspreis: $16.99
Normaler Preis
Grundpreis: pro

🏷️ Basic Information Identification Make: Harley-Davidson Model: FXDWG Dyna Wide Glide Year: 2013 Codes Model Code: FXDWG 👋 Introduction Market Position Segment: Cruiser Motorcycle Competitive Analysis Competitors: Indian Scout, Victory...

26 people are viewing this right now

Typ: Motorcycle

Anbieter:

Art.-Nr: 494124

Stichworte: 2013 DYNA WIDE GLIDE FXDWG Harley Davidson Misc Motorcycle Motorcycles

Produktvarianten

Beschreibung

🏷️ Basic Information

Identification

Make:

Harley-Davidson

Model:

FXDWG Dyna Wide Glide

Year:

Codes

Model Code:

FXDWG

👋 Introduction

Market Position

Segment:

Cruiser Motorcycle

Competitive Analysis

Competitors:

Indian Scout, Victory Vegas, Triumph Bonneville

Key Features

Styling:

Gothic, chopper-inspired

Engine Platform:

Twin Cam 103

📋 Manual Details

Coverage Areas

Primary Coverage:

Service, Maintenance, and Repair

Page Count

Estimated Pages:

Manual Type

Type:

Factory Service Manual / Repair Manual

Language

Language:

English

Format

Format:

Digital (PDF)

📖 Manual Coverage

Systems Covered

Engine:

Twin Cam 103

Transmission:

6-Speed Cruise Drive

Fuel System:

Electronic Fuel Injection (EFI)

Electrical System:

Ignition, Lighting, Charging, Starting, Instrumentation

Chassis:

Frame, Suspension, Steering

Braking System:

Hydraulic Disc Brakes (Front & Rear)

Wheel Tire Assembly:

Front & Rear Wheels, Tires, Bearings

Exhaust System:

Exhaust Pipes, Mufflers, Heat Shields

Cooling System:

Air-Cooled

Procedures Included

Maintenance:

Scheduled Maintenance, Oil Changes, Filter Replacements, Chain Adjustment

Troubleshooting:

Diagnostic Charts, Symptom-Based Problem Solving

Repair:

Component Overhaul, Reassembly, Part Replacement

Diagnostics:

On-Board Diagnostics (OBD), Sensor Testing

Calibration Adjustment:

Engine Timing, Throttle Position Sensor (TPS)

Technical Depth

Depth:

Comprehensive Engine Rebuild to Minor Adjustments

📊 Manual Specifications

File Format

File Type:

Searchability:

Fully Searchable Text

Print Quality

Image Resolution:

High Resolution, Clear Diagrams and Photos

Binding Type

Binding:

N/A (Digital)

Paper Type

Paper Quality:

N/A (Digital)

⚙️ Engine Specifications

Primary Engine

Engine Type:

Air-Cooled, Twin Cam 103

Displacement:

1690 cc (103 cubic inches)

Bore X Stroke:

3.875 in x 4.380 in (98.4 mm x 111.3 mm)

Compression Ratio:

9.6:1

Valve Train:

Pushrod-operated, overhead valves with two valves per cylinder

Performance

Torque Nm:

Approx. 132 Nm (97.6 ft-lbs) @ 3000 rpm

Horsepower Hp:

Approx. 70 HP

Fuel System

Fuel Delivery:

Electronic Sequential Port Fuel Injection (ESPFI)

Fuel Type:

Premium Unleaded Gasoline

Lubrication System

Oil Type:

Harley-Davidson SYN3 (Synthetic) or equivalent SAE 20W-50

Oil Capacity:

3.5 US quarts (3.3 Liters) with filter change

Ignition System

Ignition Type:

Dual-fire, solid-state electronic ignition

🔧 Transmission

Standard

Transmission Type:

6-Speed Cruise Drive

Clutch Type:

Multi-plate, wet clutch

Features

Primary Drive:

Helical, constant mesh

Final Drive:

Belt Drive

Fluid Type

Transmission Fluid:

Harley-Davidson Formula + Transmission and Primary Chaincase Lubricant

📐 Dimensions

Exterior

Length:

93.2 in (2367 mm)

Width:

37.6 in (955 mm)

Height:

53.6 in (1362 mm)

Wheelbase:

64.2 in (1630 mm)

Ground Clearance:

4.7 in (119 mm)

Weights

Dry Weight:

636 lbs (288.5 kg)

Wet Weight:

Approx. 678 lbs (307.5 kg)

Gvwr:

939 lbs (426 kg)

Cargo

Fuel Capacity:

5.0 US gallons (19 Liters)

🛡️ Safety Features

Ratings

Crash Test Ratings:

N/A (Motorcycle)

Active Features

Braking:

Dual disc front, single disc rear

Lighting:

Halogen headlight, LED tail light, LED turn signals

Passive Features

Frame Construction:

Steel, double-cradle frame

💡 Technology Features

Infotainment

Audio System:

Optional accessory audio systems available

Driver Assistance

Optional

Connectivity

Diagnostic Ports:

Diagnostic connector for service tools

🔧 Maintenance

Service Intervals

First Service Mileage:

1000 miles (1600 km)

Subsequent Service Mileage:

5000 miles (8000 km) or 6 months

Engine Oil Change:

Every 5000 miles (8000 km) or annually, whichever comes first

Transmission Fluid Change:

Every 10,000 miles (16,000 km) or 12 months

Primary Chaincase Lubricant Change:

Every 10,000 miles (16,000 km) or 12 months

Fluid Specifications

Engine Oil Viscosity:

SAE 20W-50

Brake Fluid Type:

DOT 4 (refer to manual for specific H-D recommendation)

Fork Oil Type:

Harley-Davidson Factory Fork Oil (viscosity varies, check manual)

Known Issues

Cam Chain Tensioner Wear:

Early Twin Cam models (pre-2007) were prone to cam chain tensioner wear. 2013 models typically use the updated hydraulic tensioners, but manual inspection is still advised.

Crankshaft Position Sensor:

Potential for failure leading to starting issues or stalling.

Idle Control Valve:

Can become dirty or fail, causing erratic idle.

Regulator Rectifier:

Can overheat and fail, leading to charging system issues.

📚 Vehicle History

Brand Heritage

Manufacturer:

Harley-Davidson Motor Company

Model Evolution

Dyna Platform:

Introduced in 1991

Wide Glide Heritage:

Iconic Chopper Styling

Production

Production Years:

1980-1981, 1984-1986, 1993-2017

Manufacturing Location:

United States

🏆 Awards & Recognition

Recognitions

Model Reviews:

Generally well-received for its styling and performance
