Hitachi EX200-5 EX200LC-5 EX220-5 EX220LC-5 EX230LC-5 EX270-

Normaler Preis: $16.99
Verkaufspreis: $16.99
Normaler Preis
Grundpreis: pro

🏷️ Basic Information Identification Make: Hitachi Model: EX200-5 EX200LC-5 EX220-5 EX220LC-5 EX230LC-5 EX270-5 EX270LC-5 Model Type: Crawler Excavator Generation: 5 Series 📋 Manual Details Availability Manual Type: Service Manual, Technical...

17 people are viewing this right now

Typ: Excavator

Anbieter:

Art.-Nr: 52407

Stichworte: 6BG1 Engines EX200-5 EX200LC-5 EX220-5 EX220LC-5 EX230LC-5 EX270- Excavator Hitachi

Produktvarianten

Beschreibung

🏷️ Basic Information

Identification

Make:

Hitachi

Model:

EX200-5 EX200LC-5 EX220-5 EX220LC-5 EX230LC-5 EX270-5 EX270LC-5

Model Type:

Crawler Excavator

Generation:

5 Series

📋 Manual Details

Availability

Manual Type:

Service Manual, Technical Manual (Operational Principle, Troubleshooting), Circuit Diagram & Harness, Workshop Manual

Language:

English

Total Page Count:

Format:

PDF, ZIP

Download Type:

Instant Download

Compatibility

Operating Systems:

Win95/98/ME/XP/vista/7/Linux/MAC

⚙️ Engine Specifications

Engine 1

Engine Type:

ISUZU A-6BG1TQA

Engine Variant:

A-6BG1 TQA01

Displacement:

6.5 Liters (ISUZU A-6BG1TQA - estimated)

Power:

140 HP (approx. for EX200-5)

Engine 2

Engine Type:

HINO H07D

Displacement:

7.0 Liters (HINO H07D - estimated)

Power:

155 HP (approx. for EX220-5)

🔧 Transmission

Drivetrain

Type:

Hydrostatic

Drive System:

4WD (Four Wheel Drive)

📐 Dimensions

Weight

Operating Weight:

Approx. 20,000 kg (EX200-5)

Operating Weight Variant:

Approx. 22,000 kg (EX220-5)

Operating Weight Variant Lc:

Approx. 21,000 kg (EX200LC-5)

Operating Weight Variant Lc 2:

Approx. 23,000 kg (EX220LC-5)

🔧 Maintenance

Lubrication

Engine Oil Capacity:

Approx. 20 Liters (ISUZU A-6BG1TQA - estimated)

Hydraulic Oil Capacity:

Approx. 140 Liters (total system)

Intervals

Engine Oil Filter Change Interval:

Refer to Service Manual

Hydraulic Oil Filter Change Interval:

Refer to Service Manual

📄 Performance

Digging Depth

Max Digging Depth:

Approx. 6.5 meters (EX200-5)

Max Digging Depth Variant:

Approx. 6.8 meters (EX220-5)

Reach

Max Digging Reach:

Approx. 9.8 meters (EX200-5)

Max Digging Reach Variant:

Approx. 10.1 meters (EX220-5)

Bucket Capacity

Standard Bucket Capacity:

Approx. 0.8 m³

📄 Components

Undercarriage

Track Gauge:

Refer to Workshop Manual

Ground Clearance:

Refer to Workshop Manual

Front Attachment

Boom Length:

Refer to Workshop Manual

Arm Length:

Refer to Workshop Manual
