Kawasaki Mule 610 4X4 Mule 600 KAF400 Models 2005-2009 Service & Repair Manual Download PDF

Normaler Preis: $16.99
Verkaufspreis: $16.99
Normaler Preis
Grundpreis: pro

🏷️ Basic Information Identification Make: Kawasaki Model: Mule 610 4x4 / Mule 600 Model Code: KAF400 Applicable Years: 2005, 2006, 2007, 2008, 2009 👋 Introduction Market Position Vehicle Type: Utility...

17 people are viewing this right now

Typ: Atv

Anbieter:

Art.-Nr: 6760

Stichworte: 2005 2006 2007 2008 2009 Atv KAF400 Kawasaki Mule Mule 600 Mule 610 4X4 Powersports UTV

Produktvarianten

Beschreibung

🏷️ Basic Information

Identification

Make:

Kawasaki

Model:

Mule 610 4x4 / Mule 600

Model Code:

KAF400

Applicable Years:

2005, 2006, 2007, 2008, 2009

👋 Introduction

Market Position

Vehicle Type:

Utility Vehicle / Side-by-Side (SxS)

Target Audience:

Off-road enthusiasts, farmers, ranchers, hunters, property owners needing a rugged work vehicle

Competitive Analysis

Key Competitors:

John Deere Gator, Polaris Ranger (early models), Cub Cadet Volunteer

Key Features

Drivetrain:

Selectable 2WD/4WD system

Transmission:

CVT with High/Low range and Reverse

Cargo Capacity:

Generous cargo bed for hauling

Reliability:

Known for robust Kawasaki engineering and durability

📋 Manual Details

Coverage Areas

Manual Type:

Factory Service & Repair Workshop Manual

Language:

English

Format:

Digital Download (PDF)

Usage Rights:

Unlimited use on multiple devices, life-time access

Print Capability:

Printable (single pages or entire manual)

Page Count

Estimated Page Count:

Hundreds of pages (specific count not provided but described as comprehensive)

📖 Manual Coverage

Systems Covered

Engine:

Internal inspection, disassembly, assembly, tuning, troubleshooting, diagnostics

Fuel System:

Carburetor (Mikuni VM Series), fuel tank, fuel pump, fuel lines, filters, adjustments

Cooling System:

Radiator, fan, water pump, thermostat, coolant, hoses, troubleshooting

Ignition System:

CDI unit, ignition coil, spark plug, wiring, timing, troubleshooting

Lubrication System:

Engine oil, oil filter, oil pump, oil passages, maintenance

Transmission:

Continuously Variable Transmission (CVT) - belt inspection, clutch assembly, drive and driven pulley service, maintenance

Drivetrain:

4WD system engagement, front differential, rear differential, driveshafts, U-joints, axle boots, maintenance

Brakes:

Hydraulic system, brake pads, brake calipers, brake drums (rear), brake fluid, bleeding, maintenance, troubleshooting

Suspension:

Front and rear suspension components, shocks, springs, bushings, lubrication, alignment checks

Steering:

Steering wheel, steering column, tie rods, steering linkage, maintenance, adjustments

Electrical System:

Battery, charging system (alternator), starter motor, lighting (headlights, taillights, brake lights), wiring diagrams, fuses, troubleshooting

Body And Chassis:

Frame inspection, body panels, seat, cargo bed, fenders, maintenance

Procedures Included

Routine Maintenance:

Oil changes, filter replacements, spark plug checks, air filter cleaning/replacement, fluid level checks, lubrication points

Troubleshooting Diagnostics:

Step-by-step guides for identifying and resolving common problems

Engine Rebuild:

Complete disassembly, inspection, measurement, and reassembly procedures

Transmission Service:

CVT belt replacement, clutch inspection and service

Brake System Repair:

Pad/shoe replacement, caliper/drum service, brake line replacement, bleeding procedure

Electrical Component Replacement:

Starter, alternator, battery, lights, ignition components

Suspension And Steering Repair:

Component replacement, adjustments, lubrication

Wiring Diagram Interpretation:

Detailed diagrams for all electrical systems

Technical Depth

Depth Of Information:

Professional-level detail suitable for mechanics and advanced DIYers

Diagrams And Illustrations:

Hundreds of detailed photos and exploded diagrams

Torque Specifications:

Comprehensive list of torque values for critical fasteners

Clearances And Tolerances:

Specific measurements for engine components and other parts

Service Data:

All necessary technical data for repair and maintenance

📊 Manual Specifications

File Format

File Type:

PDF (Portable Document Format)

Platform Compatibility:

Windows and macOS compatible

Searchability:

Likely searchable text-based PDF (standard for professional manuals)

Print Quality

Print Resolution:

High resolution, suitable for clear reproduction of diagrams and text

Binding Type

Digital Binding:

N/A (Digital Download)

Paper Type

Digital Paper Type:

N/A (Digital Download)

⚙️ Engine Specifications

Primary Engine

Engine Type:

4-stroke, Single Cylinder, OHV

Displacement:

401 cc

Bore X Stroke:

76.0 x 88.0 mm

Cooling Method:

Liquid-cooled

Compression Ratio:

9.0:1

Performance

Horsepower Gross:

Approx. 11.3 HP (at specified RPM, varies slightly by year)

Torque Gross:

Approx. 17.7 lb-ft (at specified RPM, varies slightly by year)

Fuel System

Fuel Delivery:

Carburetor (Mikuni VM24)

Fuel Type:

Unleaded gasoline, minimum octane rating 87

Fuel Tank Capacity:

5.7 US gal (21.5 L)

Lubrication System

Oil Type:

SAE 10W-40 API SG or higher (check specific manual for exact recommendations)

Oil Capacity W Filter:

Approx. 1.7 US qt (1.6 L)

Ignition System

Spark Plug Type:

NGK CR6HSA or equivalent

🔧 Transmission

Standard

Transmission Type:

Automatic (CVT - Continuously Variable Transmission)

Gear Selection:

H (High), L (Low), R (Reverse), N (Neutral)

Features

Drive System:

Shaft drive to differentials

Differential Lock:

Locking front differential (on 4x4 models)

Maintenance

Cv Trans Oil Type:

Specific CVT fluid required (check manual for part number and type)

📐 Dimensions

Exterior

Overall Length:

Approx. 112.2 in (2850 mm)

Overall Width:

Approx. 54.1 in (1375 mm)

Overall Height:

Approx. 70.9 in (1800 mm)

Wheelbase:

Approx. 71.7 in (1820 mm)

Ground Clearance:

Approx. 6.7 in (170 mm)

Cargo

Cargo Bed Dimensions Lxwxh:

Approx. 37.4 x 42.3 x 10.4 in (950 x 1075 x 265 mm)

Cargo Bed Capacity:

Approx. 340 kg (750 lbs)

Weights

Curb Weight:

Approx. 465 kg (1025 lbs) for 4x4 model

Towing Capacity:

Approx. 500 kg (1100 lbs)

Payload Capacity:

Approx. 360 kg (795 lbs) for 4x4 model

Front Tire Size:

AT22x8-10

Rear Tire Size:

AT22x10-10

Wheel Bolt Pattern:

4 x 140 mm

🛡️ Safety Features

Ratings

Rollover Protection:

ROPS (Roll-Over Protective Structure) equipped

Active Features

Brakes:

Hydraulically operated disc brakes (front), drum brakes (rear)

Parking Brake:

Mechanical type

Passive Features

Seatbelts:

Standard seatbelts (3-point)

Lighting:

Halogen headlights, LED taillight/brake light

💡 Technology Features

Infotainment

Features:

Basic utilitarian design; typically does not include advanced infotainment systems. Focus on functionality.

Driver Assistance

Features:

No electronic driver assistance systems such as ABS or traction control. Relies on mechanical systems.

Connectivity

Features:

N/A (Utility vehicle focused on operation, not connected features)

🔧 Maintenance

Service Intervals

Engine Oil Change:

Every 6 months or 100 hours of operation (whichever comes first)

Air Filter Cleaning:

Check/clean every 50 hours, replace annually or as needed

Spark Plug Inspection:

Check/clean every 100 hours, replace annually

Cv Belt Inspection:

Inspect every 6 months or 50 hours for wear and damage

Brake Fluid Change:

Recommended every 2 years or as needed

Fluid Specifications

Engine Oil Viscosity:

SAE 10W-40

Coolant Type:

Permanent type antifreeze (ethylene glycol based), 50/50 mix with distilled water

Brake Fluid Type:

DOT 3

Differential Oil Type:

Refer to manual for specific gearbox and differential oil specifications (e.g., GL-4 or GL-5 gear oil, or specific Kawasaki gear lubricant)

Known Issues

Cv Belt Wear:

CVT belts can wear prematurely under heavy use or if improperly maintained, leading to slipping or no engagement.

Carburetor Issues:

Can be prone to clogging if fuel is not clean, requiring cleaning and adjustment.

Electrical Connections:

Corrosion or loose connections in wiring harness can cause intermittent electrical issues.

📚 Vehicle History

Brand Heritage

Manufacturer:

Kawasaki Heavy Industries, Ltd.

Reputation:

Long-standing reputation for engineering quality and durability in motorcycles, ATVs, and utility vehicles.

Model Evolution

Predecessor:

Kawasaki Mule series, often focused on simpler designs and smaller displacements.

Positioning:

The Mule 610 4x4/600 was positioned as an entry-level, affordable, and capable utility vehicle, offering 4x4 capability in a compact package.

Production

Production Period:

2005-2009 for the KAF400 series covered by this manual.

🏆 Awards & Recognition

Recognitions

Industry Standing:

Kawasaki Mules are generally recognized for their durability and value in the utility vehicle market.

Ratings

Safety Design:

Designed with ROPS and standard safety features for utility work.
