Segment:
Subcompact Crossover SUV
Target Audience:
Young buyers, urban commuters, small families valuing style and practicality
Key Competitors:
Nissan Juke, Mini Countryman, Honda Fit, Ford Fiesta (hatchback variants)
Design Language:
Distinctive, boxy, and youthful styling; highly customizable interior and exterior options
Interior Space:
Surprisingly spacious interior for its exterior dimensions, especially rear headroom and cargo volume
Value Proposition:
Affordable pricing, good fuel economy, and a host of available features
Engine Options Covered:
1.6L Gamma G4FC, 2.0L Beta II G4GC, 1.6L U2 CRDi Diesel (Region Dependent)
Transmission Types Covered:
5-Speed Manual, 4-Speed Automatic, 6-Speed Automatic (with 2.0L)
Trim Levels Covered:
All Trim Levels (e.g., Base, Plus, Exclaim, ! (Exclamation), Sport, Shadow Dragon, Tempo, Rush, Hamster)
Regions Covered:
North America, Europe, Asia, Australia (Varies based on specific manual edition)
Estimated Page Count:
1500+
Type:
Workshop Repair and Service Manual
Engine Mechanical:
Engine assembly, cylinder head, block, crankshaft, pistons, connecting rods, lubrication system, cooling system
Engine Electrical:
Ignition system, fuel injection system, sensors, ECU (ECM) diagnostics, starting and charging system
Transmission Manual:
Clutch system, gearbox assembly, shift mechanism, internal components
Transmission Automatic:
Torque converter, valve body, planetary gear sets, transmission control module (TCM), fluid system
Drivetrain:
Front-wheel drive (FWD), axles, CV joints, differential (integrated into transaxle)
Suspension:
Front McPherson strut, rear torsion beam, shock absorbers, springs, control arms, stabilizer bars
Steering:
Power steering system (Hydraulic or Electric Power Steering - MDPS), steering column, tie rods, steering rack
Brakes:
Front disc, rear drum (standard) or disc (optional), ABS system, brake booster, master cylinder, brake lines, parking brake
Electrical Body:
Lighting system (headlights, taillights, interior), power windows, power locks, mirrors, wipers, horn, keyless entry
HVAC:
Air conditioning system, heater, ventilation, blower motor, climate controls, refrigerant system
Safety Restraints:
Airbag system (SRS), seat belts, pre-tensioners
Body And Chassis:
Frame construction, body panels, doors, hood, tailgate, interior trim, corrosion protection
Diagnostics:
OBD-II (On-Board Diagnostics II) procedures, DTC (Diagnostic Trouble Code) interpretation, diagnostic tool usage
Maintenance Tasks:
Oil changes, filter replacements (oil, air, cabin), spark plug replacement, coolant flush, brake fluid change, transmission fluid change
Repair Procedures:
Engine component replacement, transmission overhaul/rebuild, suspension component repair, brake caliper/rotor replacement, power steering pump/rack replacement, electrical component diagnosis and repair
Troubleshooting:
Systematic diagnostic flowcharts for common and complex issues, symptom-based troubleshooting guides
Component Removal Installation:
Detailed steps for removing and installing major and minor components, including torque specifications
Wiring Diagrams:
Comprehensive electrical schematics for all vehicle systems
Depth:
Comprehensive (from routine maintenance to complete engine and transmission rebuilds)
Diagnostic Capability:
Advanced diagnostics, including sensor data interpretation and ECU programming information (where applicable)
Rebuild Procedures:
Detailed instructions for engine and transmission component rebuilding, including clearances and specifications
Length:
160.6 inches (4079 mm)
Width:
69.5 inches (1765 mm)
Height:
63.4 inches (1610 mm)
Wheelbase:
101.2 inches (2570 mm)
Passenger Volume:
Approximately 105.4 cubic feet
Cargo Volume Behind Rear Seats:
Approximately 19.3 cubic feet
Cargo Volume With Rear Seats Folded:
Approximately 53.1 cubic feet
Curb Weight Min:
Approximately 2800 lbs (1270 kg)
Curb Weight Max:
Approximately 3100 lbs (1406 kg)
Gross Vehicle Weight Rating Gvwr:
Approximately 3858 lbs (1750 kg)
NHTSA Overall Rating:
4 out of 5 stars (overall)
IIHS Top Safety Pick:
Yes (for models equipped with specific safety features)
ABS:
Standard Anti-lock Braking System
Esc:
Standard Electronic Stability Control (ESC)
Traction Control:
Standard Traction Control System (TCS)
Airbags:
Front, front-side, and side-curtain airbags
Seatbelts:
3-point seatbelts with pretensioners and load limiters
Child Anchors:
LATCH (Lower Anchors and Tethers for Children) system
Engine Oil Change:
Every 5,000 - 7,500 miles (8,000 - 12,000 km) or 6-12 months, depending on driving conditions (refer to manual for specific guidance and oil type)
Engine Air Filter:
Every 15,000 - 30,000 miles (24,000 - 48,000 km) or as needed based on inspection
Cabin Air Filter:
Every 12,000 - 15,000 miles (19,000 - 24,000 km) or annually
Spark Plugs:
100,000 miles (160,000 km) for iridium-tipped plugs (typical for this era Kia)
Coolant Flush:
Every 30,000 - 60,000 miles (48,000 - 96,000 km) or 2-4 years (typically a long-life coolant)
Transmission Fluid Change Auto:
Every 60,000 - 100,000 miles (96,000 - 160,000 km), or more frequently under severe driving
Brake Fluid Change:
Every 2-3 years or 30,000 miles (48,000 km)
Engine Oil Viscosity:
0W-20 (preferred for fuel economy), 5W-20, or 5W-30 (check manual for specific engine recommendation)
Coolant Type:
Asian Pink Long Life (or equivalent silicate-free, OAT coolant)
Common Complaints:
Catalytic converter failure (especially with early models/certain engine variants), potential for oil consumption (check rings/PCV), some transmission shift quality issues in automatic transmissions, interior rattles and trim pieces.
Brake Wear:
Normal wear and tear on brake pads and rotors, rear drum brake adjustment may be needed periodically.
Suspension Components:
Wear on ball joints, tie rod ends, and bushings due to typical urban driving cycles.
