KTM 950 990 Repair Manual 2003-2006

Normaler Preis: $16.99
Verkaufspreis: $16.99
Normaler Preis
Grundpreis: pro

This manual covers the 950 Adventure and 990 Adventure models, produced for the 2003 through 2006 model years. These motorcycles, built around the powerful LC8 V-twin engine, are renowned for...

15 people are viewing this right now

Typ: Motorcycle

Anbieter:

Art.-Nr: 136862

Stichworte: 2003 2004 2005 2006 950 990 KTM Motorcycle Motorcycles

Produktvarianten

Beschreibung

This manual covers the 950 Adventure and 990 Adventure models, produced for the 2003 through 2006 model years. These motorcycles, built around the powerful LC8 V-twin engine, are renowned for their robust engineering and impressive off-road capabilities, making them ideal for adventure touring and demanding journeys. The first generation 950 Adventure established presence in the large-displacement adventure segment, while the subsequent 990 Adventure introduced fuel injection and further refinements. Manufactured in Austria, these machines blend performance with durability, reflecting a strong heritage in motorsports. This comprehensive workshop service and repair manual provides detailed instructions for maintaining and repairing your Adventure motorcycle. It covers all essential systems, including engine disassembly and tuning, fuel system servicing for both carburetor and fuel injection models, transmission, suspension, brakes, and the electrical system. The manual also includes procedures for scheduled maintenance, troubleshooting common issues, and in-depth technical specifications such as torque values and fluid capacities. This resource is designed to assist owners, mechanics, and technicians in ensuring the optimal performance and longevity of their 950 and 990 Adventure models.

🏷️ Basic Information

Identification

Make:

Model:

950 Adventure / 990 Adventure

Model Variant:

Adventure Series

Generation

Generation:

First Generation (950), Second Generation (990)

Codes

Chassis Codes:

LC8 V-Twin

👋 Introduction

Market Position

Positioning:

Essential resource for owners and independent workshops maintaining the iconic KTM LC8 Adventure series.

Competitive Analysis

Competitor Comparison:

Offers a cost-effective and readily accessible alternative to expensive OEM factory service manuals or CD-ROMs.

Key Features

Key Features:

Digital delivery, print-on-demand capability, comprehensive coverage of all major systems, detailed diagrams.

📋 Manual Details

Coverage Areas

Applicable Years:

2003, 2004, 2005, 2006

Page Count

Estimated Page Count:

Extensive (typically 500+ pages for a complete factory-style manual)

Manual Type

Manual Type:

Workshop Service / Repair Manual

Language

Language:

English (implied by product description, typical for major service manuals)

Format

Delivery Format:

Digital (PDF)

📖 Manual Coverage

Systems Covered

Engine:

Complete disassembly, assembly, tuning, diagnostics, valve adjustment, timing chain, oil pump, cooling system integration.

Fuel System:

Carburetor tuning and rebuild (950), Fuel Injection system diagnostics and servicing (990), fuel pump, fuel filter replacement.

Transmission:

Gearbox internal inspection, clutch replacement, gear shift mechanism, lubrication, transmission fluid changes.

Suspension:

Front fork (WP Suspension) disassembly, servicing, oil changes, seal replacement, rear shock absorber servicing, linkage maintenance.

Brakes:

Brake system bleeding, pad replacement, caliper service, master cylinder overhaul, disc inspection and replacement.

Electrical System:

Wiring diagrams, component testing, starter motor, alternator, battery charging system, ignition system diagnostics, sensor identification.

Cooling System:

Radiator service, fan operation, coolant flush and refill, thermostat testing, water pump inspection.

Exhaust System:

Exhaust component inspection, gasket replacement, header pipe sealing.

Emission Control Systems:

Catalytic converter function (where applicable), emission control devices, evaporative emission system (EVAP) checks (990).

Body:

Fairing removal and installation, seat servicing, fuel tank removal, luggage system mounting points.

Heating And Air Conditioning:

N/A (Motorcycle)

Procedures Included

Maintenance:

Scheduled maintenance tasks, fluid level checks, lubrication points, filter replacements, chain adjustment.

Troubleshooting:

Diagnostic flowcharts for common performance issues, electrical faults, and mechanical problems.

Repair:

Step-by-step instructions for component repair, replacement, and rebuilding.

Technical Specifications:

Torque values for all fasteners, clearances, fluid capacities, electrical specifications, tuning parameters.

Technical Depth

Depth:

Comprehensive - covers from basic maintenance to complete engine and transmission rebuilds.

📊 Manual Specifications

File Format

File Format:

PDF (Portable Document Format)

Print Quality

Printability:

High - designed for clear printing of text, diagrams, and images.

Binding Type

Binding Type:

N/A (Digital - Printable)

Paper Type

Paper Type For Printing:

Standard printing paper (8.5" x 11" or A4) recommended for optimal viewing.

⚙️ Engine Specifications

Primary Engine

Engine Type:

Liquid-cooled, 75-degree V-twin, four-stroke (LC8)

Engine Displacement 950:

942 cc

Engine Displacement 990:

999 cc

Bore X Stroke 950:

97.5 mm x 65 mm

Bore X Stroke 990:

101 mm x 62.4 mm

Compression Ratio:

Varies by model year, typically around 11.5:1 to 12.5:1

Performance

Horsepower 950:

Approx. 98 HP @ 8,000 RPM

Horsepower 990:

Approx. 105-115 HP @ 7,500-8,000 RPM

Torque 950:

Approx. 95 Nm @ 6,000 RPM

Torque 990:

Approx. 98-102 Nm @ 6,000-6,500 RPM

Fuel System

Fuel System 950:

Carburetor (Keihin 38mm CV)

Fuel System 990:

Electronic Fuel Injection (EFI) with dual injectors per cylinder

Fuel Type:

Unleaded gasoline, minimum 95 RON

🔧 Transmission

Standard

Transmission Type:

6-speed manual gearbox

Optional

Optional Transmission:

Features

Clutch Type:

Wet multi-plate clutch (Hydraulically operated)

Final Drive:

Chain drive

📐 Dimensions

Exterior

Length:

Approx. 2200 mm (varies slightly by model)

Width:

Approx. 850 mm (over handlebars)

Height:

Approx. 1400 mm (to top of windscreen)

Weights

Dry Weight 950:

Approx. 202 kg

Dry Weight 990:

Approx. 207 kg

Wet Weight Approximate:

Approx. 230-240 kg (fully fueled)

Fuel Capacity:

22 liters (approx. 5.8 US gallons)

🛡️ Safety Features

Ratings

Safety Ratings:

N/A (Motorcycle specific safety standards apply)

Active Features

Braking System:

Dual disc front, single disc rear with hydraulic actuation (Brembo components typical).

Available as an option on some 990 models, not present on 950.

Passive Features

Lighting:

Halogen headlight, LED taillight (model dependent), integrated turn signals.

💡 Technology Features

Infotainment

Infotainment Features:

N/A (Basic instrumentation: speedometer, tachometer, odometer, trip meters, fuel gauge, indicator lights).

Driver Assistance

Driver Assistance Features:

ABS (optional on some 990 models).

Connectivity

Connectivity Features:

N/A (No Bluetooth or smartphone integration in this era).

🔧 Maintenance

Service Intervals

Oil Change Interval:

Typically every 5,000 - 10,000 km or annually (refer to specific manual for exact intervals).

Valve Check Interval:

Typically every 10,000 - 15,000 km

Chain Lubrication And Tension Check:

Every 500 - 1,000 km, or as needed based on conditions.

Fluid Specifications

Engine Oil Type And Capacity:

Refer to manual; typically SAE 10W-50 or 15W-50 synthetic motorcycle oil, approx. 2.5-3.0 liters.

Coolant Type:

Ethylene glycol-based antifreeze, typically a 50/50 mix with distilled water.

Brake Fluid Type:

DOT 4

Clutch Fluid Type:

DOT 4 (for hydraulic clutch systems)

Known Issues

Common Issues:

Potential for water pump seal leaks, starter clutch wear, fuel pump issues (990 EFI), cam chain tensioner noise, carburetor synchronization (950).

Common Maintenance Tasks:

Regular fuel injector cleaning (990), spark plug replacement, air filter maintenance.

📚 Vehicle History

Brand Heritage

Brand Focus:

KTM is renowned for its off-road and racing heritage, translating into robust and performance-oriented motorcycles.

Model Evolution

Development Basis:

The 950 Adventure was KTM's groundbreaking entry into the large-displacement adventure touring segment, built around the powerful LC8 V-twin engine.

Introduction Of 990:

The 990 Adventure succeeded the 950, primarily featuring a fuel-injected engine, improved ergonomics, and updated components.

Production

Manufacturing Location:

Austria

🏆 Awards & Recognition

Recognitions

Industry Awards:

The KTM Adventure series is widely recognized for its off-road prowess and long-distance touring capabilities, often praised in motorcycle publications.

Ratings

Reliability Reputation:

Generally considered reliable with proper maintenance; specific component longevity can vary.

Certifications

Certification Type:

N/A (Manufacturer-produced technical documentation).
