The Mazda MPV, specifically the second generation (LW) produced from 2003 to 2006, offers a blend of practicality and a comfortable driving experience, making it a versatile choice for families and those needing flexible cargo space. This generation, manufactured in Hofu, Yamaguchi, Japan, features a robust V6 engine, typically a 3.0-liter unit producing around 195-200 horsepower, paired with a 4-speed automatic transmission. Known for its car-like handling and a well-appointed interior, the MPV was designed with passenger comfort and convenience in mind, incorporating features like standard cruise control and available automatic climate control. Safety was also a key consideration, with 5-star NHTSA frontal impact ratings and standard Anti-lock Braking System (ABS) on many models.
This comprehensive Factory Service Repair Manual, written in English and presented in a searchable format, provides detailed information for the maintenance and repair of the Mazda MPV. It covers all essential systems, including the powertrain (engine, transmission, differential), chassis (brakes, suspension, steering), electrical systems, HVAC, and interior components. The manual offers step-by-step repair procedures, advanced troubleshooting guides, and essential technical specifications, mirroring the information available to professional technicians. Its purpose is to empower Mazda MPV owners, DIY mechanics, and professional repair shops with the knowledge needed to maintain the vehicle's reliability and performance, potentially leading to significant cost savings on labor.
Generation:
Second Generation (LW)
Model Years Covered:
2003, 2004, 2005, 2006
Chassis Code:
LW3W (typically for 2.3L)
Target Audience:
Mazda MPV owners (2003-2006), DIY mechanics, professional technicians, auto repair shops
Type Of Manual:
Official Factory Service Repair Manual (contrasted with third-party manuals)
Diagnostic Tools:
Includes advanced troubleshooting guides to diagnose and correct problems
Instructional Format:
Step-by-step instructions, detailed illustrations, diagrams, photos, notes, cautions, and warnings
Cost Savings:
Potential savings of $50-$60 per hour on shop labor costs
Regions Covered:
Global (specific variations may apply to North American market as is common with factory manuals)
Estimated Page Count:
Several hundred pages (stated as 'hundreds of pages')
Type:
Factory Service Repair Manual
Powertrain:
Engine (service/repair, fuel injection, cooling, emission system, engine control), Transmission (service/repair), Differential/Drive, Axle
Chassis:
Brake System, Suspension, Steering, Chassis/Body
Electrical And HVAC:
Wiring Diagram, Electrical System, Heater/Air Conditioner
Interior And Safety:
Restraint System, Interior
Maintenance:
General Maintenance, Periodic Lubrication
Diagnostics And Repair:
Troubleshooting, Step-by-step repair procedures for all covered systems, Advanced troubleshooting guide
Depth:
Comprehensive (covers fundamentals to complete rebuilds, diagnostic and repair procedures in great detail, same information as professional technicians)
Readability Software:
Adobe PDF Reader
Searchability:
Searchable text for easy information retrieval
Printability:
Fully printable (individual pages, chapters, or entire manual)
Resolution:
High resolution
Binding:
N/A (Digital Download, user prints and binds)
Paper Type:
N/A (Digital Download)
Engine Type:
V6 (most common for this generation in North America)
Engine Displacement Usdm:
3.0 Liters (3000cc)
Engine Code Usdm:
AJ-DE (or similar Mazda V6 codes)
Engine Power Usdm:
Approximately 195-200 horsepower (varies slightly by model year)
Engine Torque Usdm:
Approximately 200-205 lb-ft (varies slightly by model year)
Fuel Delivery:
Electronic Fuel Injection (EFI)
Fuel Type:
Unleaded Gasoline
Transmission Type:
Automatic
Number Of Gears:
4-speed automatic (common for this generation)
Transmission Type Optional:
Not typically offered with manual transmission in North America for this generation.
Transmission Control:
Electronically controlled
Length Approx In:
180.5 inches
Width Approx In:
71.7 inches
Height Approx In:
65.7 inches
Wheelbase Approx In:
106.1 inches
Curb Weight Lbs Approx:
3,800 - 4,000 lbs (depending on configuration)
NHTSA Front Impact Driver:
5-Star (for 2003 models, testing may vary by year and test criteria)
NHTSA Front Impact Passenger:
5-Star (for 2003 models)
IIHS Front Offset Score:
Good (for models tested, generally performed well)
ABS:
Standard Anti-lock Braking System (ABS)
Traction Control:
Available Traction Control System (TCS)
Airbags Front:
Driver and Front Passenger Airbags
Airbags Side:
Available Front Side-Impact Airbags (optional/depending on trim)
Audio System:
Factory fitted AM/FM stereo with CD player, optional premium audio systems available on higher trims.
Climate Control:
Manual or Automatic Climate Control (depending on trim level).
Cruise Control:
Standard Cruise Control
Power Ports:
12V power outlets for accessory charging.
Oil Change Interval:
Refer to manual (typically 5,000-7,500 miles or 6-12 months for synthetic blend)
Engine Air Filter Replacement:
Refer to manual (e.g., every 30,000 miles)
Cabin Air Filter Replacement:
Refer to manual (e.g., every 15,000 miles)
Spark Plug Replacement:
Refer to manual (e.g., iridium plugs at 100,000 miles)
Engine Oil Type:
Refer to manual (typically SAE 5W-20 or 5W-30 API SN/ILSAC GF-5)
Transmission Fluid Type:
Refer to manual (e.g., Mazda ATF Type T-IV or equivalent)
Coolant Type:
Refer to manual (typically silicate-free, long-life coolant, often green or blue)
Brake Fluid Type:
Refer to manual (typically DOT 3 or DOT 4)
Transmission Shifting:
Some reports of rough shifting or transmission issues over time, proper fluid maintenance is key.
Engine Mounts:
Worn engine mounts can lead to vibration or knocking noises.
Exhaust System:
Corrosion and leaks can occur in the exhaust system over time.
Suspension Components:
Wear on ball joints, tie rods, and bushings can affect handling and ride quality.
Manufacturer:
Mazda Motor Corporation
Generation Transition:
Second generation MPV (LW) launched in 1999, received significant updates and styling refresh for the 2003 model year, which is covered by this manual.
Production Period:
1999-2006 (for LW generation)
Manufacturing Location:
Hofu, Yamaguchi, Japan
Segment Awards:
The Mazda MPV was often praised for its car-like handling and flexible interior for its class, though it competed in a segment with strong rivals.
Safety Accolades:
Received 5-star ratings in NHTSA frontal crash tests for the period.
