Engine:
Detailed coverage of engine mechanical systems, tuning, and diagnostics.
Fuel System:
Fuel injection, fuel pump, injectors, fuel tank, lines, and evaporative emissions control.
Cooling System:
Radiator, fan, thermostat, water pump, hoses, and coolant specifications.
Ignition System:
Spark plugs, coils, distributor (if applicable), timing, and diagnostics.
Exhaust System:
Manifolds, catalytic converter, mufflers, pipes, and emissions control.
Transmission Automatic:
Operation, diagnosis, overhaul, fluid specifications, and control systems.
Transmission Manual:
Operation, diagnosis, overhaul, fluid specifications, and gear shift mechanisms.
Drivetrain:
Axles, CV joints, differentials, and drive shaft components.
Suspension System:
Front and rear suspension components, alignment, struts, shocks, and springs.
Steering System:
Power steering pump, rack and pinion, steering column, and components.
Brake System:
Hydraulic system, ABS, disc brakes, calipers, rotors, pads, and fluid.
Electrical System Lighting:
Headlights, taillights, interior lighting, and bulb specifications.
Electrical System Instruments:
Dashboard instruments, gauges, warning lights, and their operation.
Electrical System Accessories:
Power windows, locks, mirrors, sunroof, and other powered accessories.
Body Interior:
Trim removal, seat components, dashboard, and interior paneling.
Body Exterior:
Body panels, doors, fenders, hood, trunk, bumpers, and glass.
HVAC System:
Air conditioning, heating, ventilation, blower motor, and controls.
Safety Systems:
Airbags, seatbelts, and related components.
Maintenance:
Scheduled maintenance, fluid checks, filter replacements, tune-ups.
Disassembly:
Step-by-step instructions for removing and disassembling components.
Assembly:
Step-by-step instructions for reassembling components.
Cleaning:
Procedures for cleaning various engine and vehicle parts.
Repair:
Detailed repair procedures for all major vehicle systems.
Troubleshooting:
Diagnostic procedures and common problem identification.
Technical Depth:
Suitable for professional technicians and advanced DIY mechanics.
Diagnostics:
Includes diagnostic trouble codes (DTCs) and testing procedures.
Manual Type Clarification
Manual Reference Type:
Factory service manual equivalent, also covering owner's manual topics.
Oil Change Interval:
Typically every 3,750 - 5,000 miles, or 6 months, depending on driving conditions and oil type used.
Timing Belt Replacement:
For 4G64 and 6G72 engines, replacement is crucial, typically around 60,000 - 90,000 miles. The manual will specify the exact interval and procedure.
Engine Oil:
Typically API SG or SH, SAE 5W-30 or 10W-30, depending on ambient temperature. Refer to manual for exact specification.
Transmission Fluid Automatic:
Mitsubishi Diamond ATF SP-III or equivalent.
Coolant:
Ethylene glycol-based coolant, typically a 50/50 mix with distilled water. Manual will specify type and capacity.
Common Wear Items:
Considered relatively robust, but common wear items include suspension bushings, wheel bearings, and occasional power steering leaks.
Engine Performance:
Potential for carbon buildup in older engines; some reports of oil pressure sensor failures.
Electrical Issues:
Less common, but intermittent electrical gremlins can occur over time with age.
