Market Position:
The 2010 Toyota FJ Cruiser is positioned as a rugged, off-road capable SUV with distinctive retro styling, appealing to a niche market seeking utility, durability, and character.
Competitive Analysis:
Competes with other mid-size SUVs focused on off-road prowess and unique styling, such as the Jeep Wrangler, Land Rover Defender (where available), and less rugged but similarly capable options like the Nissan Xterra and Jeep Grand Cherokee.
Key Features:
Iconic retro styling, robust body-on-frame construction, excellent off-road capability with available A-TRAC and locking rear differential, powerful V6 engine, unique C-pillar design with suicide doors for rear access.
Coverage Areas:
Engine, Drivetrain, Suspension, Steering, Brakes, Electrical Systems, HVAC, Bodywork, Interior, Diagnostics, Maintenance, Troubleshooting, Repair
Page Count:
Thousands (estimated for comprehensive digital manual)
Manual Type:
Service and Repair Manual Software
Format:
Digital Download (PDF via Web Browser Access)
Systems Covered:
Engine Mechanical (including timing, valvetrain, lubrication, cooling), Fuel System, Ignition System, Exhaust System, Emission Control Systems, Transmission (Automatic), Transfer Case, Driveline (Front and Rear Axles, Driveshafts), Suspension (Front and Rear), Steering System, Brake System (Hydraulic, ABS), Power Steering, Electrical System (Wiring Diagrams, Components, ECUs), Climate Control (HVAC), Body Control Modules, Lighting, Instrumentation, Audio System, Security System, Chassis Components, Exterior Trim, Interior Trim
Procedures Included:
Scheduled Maintenance (oil changes, filter replacements, fluid checks), Component Removal and Installation (engine, transmission, suspension parts, brakes, steering components, interior/exterior panels), Diagnostic Procedures (OBD-II scanning, trouble code interpretation, component testing), Repair Procedures (engine overhaul, transmission service, brake caliper replacement, suspension alignment, electrical component repair), Wiring Harness Repair, HVAC System Diagnosis and Repair, Body Panel Repair, Fluid Capacities and Specifications, Torque Specifications for all fasteners, Lubrication Points
Technical Depth:
Comprehensive; Covers basic maintenance to full mechanical and electrical diagnostics and repairs. Includes detailed component descriptions, operating principles, troubleshooting flowcharts, and step-by-step repair instructions with illustrations/diagrams where applicable.
Primary Engine Details:
4.0L DOHC 24-Valve V6 (1GR-FE)
Horsepower:
239 hp @ 5200 rpm
Torque:
278 lb-ft @ 3700 rpm
Fuel Induction:
Electronic Fuel Injection (EFI)
Fuel Type:
87 Octane Unleaded Gasoline
Cooling System Type:
Liquid-Cooled
Oil Capacity With Filter:
7.4 US quarts (7.0 liters)
Recommended Oil Viscosity:
SAE 5W-30
Emission System:
California Emission Standards (where applicable), Federal Tier 2 Bin 5
Transmission Type:
5-Speed Electronically Controlled Automatic Overdrive (A750F)
Transmission Type Optional:
5-Speed Manual Transmission (RA5R)
Transmission Features:
Full-time 4WD with Active Traction Control (A-TRAC) and locking rear differential (optional), 2-speed transfer case with 4WD (4H, 4L) modes.
Automatic Transmission Fluid Type:
Toyota Genuine ATF WS (World Standard)
Automatic Transmission Fluid Capacity:
Approx. 10.8 US quarts (10.2 liters)
Manual Transmission Fluid Type:
Toyota Genuine Gear Oil GL-4 75W-90
Length:
175.0 inches (4445 mm)
Width:
75.0 inches (1905 mm)
Height:
72.2 inches (1835 mm)
Wheelbase:
107.0 inches (2718 mm)
Ground Clearance:
9.6 inches (244 mm)
Curb Weight:
4,500 - 4,650 lbs (2041 - 2109 kg)
Gross Vehicle Weight Rating:
5,950 lbs (2700 kg)
Cargo Volume Behind Front Seats:
72.0 cu ft (2.04 m³)
Cargo Volume Behind Rear Seats:
24.6 cu ft (0.70 m³)
Towing Capacity:
5,000 lbs (2268 kg)
NHTSA Rollover Resistance:
4/5 Stars
IIHS Frontal Offset Score:
Good
IIHS Side Impact Score:
Good
Active Safety Features:
Anti-lock Braking System (ABS), Electronic Brake-force Distribution (EBD), Brake Assist (BA), Vehicle Stability Control (VSC), Active Traction Control (A-TRAC), Hill-Start Assist Control (HAC), Downhill Assist Control (DAC) (on automatic transmission models)
Passive Safety Features:
Driver and front passenger airbags, Front and rear side curtain airbags, Front seat-mounted side-impact airbags, Active headrests, Three-point seatbelts with pretensioners and force limiters, Child seat anchors (LATCH)
Infotainment System:
Standard AM/FM/CD stereo with MP3 capability, auxiliary audio jack, and six speakers. Optional JBL premium audio system with subwoofer and steering wheel audio controls.
Navigation:
Optional touch-screen navigation system with voice recognition and integrated backup camera.
Driver Assistance Features:
Backup camera (optional with navigation), rear parking assist sensors (optional).
Connectivity Features:
Bluetooth hands-free phone system and audio streaming (available on some trims/packages), USB input (optional).
Oil Change Interval:
Every 5,000 miles (8,000 km) or 6 months, whichever comes first (under normal driving conditions); consider every 3,000 miles (5,000 km) under severe conditions.
Engine Air Filter Replacement:
Every 30,000 miles (48,000 km) or as needed based on inspection.
Cabin Air Filter Replacement:
Every 15,000 miles (24,000 km) or annually.
Coolant Replacement:
First replacement at 100,000 miles (160,000 km), then every 50,000 miles (80,000 km) thereafter.
Transmission Fluid Change Automatic:
Check every 30,000 miles (48,000 km); recommended replacement around 60,000-100,000 miles (96,000-160,000 km), especially for off-road use.
Engine Oil Part Number Example:
Toyota 0W-20 Synthetic (check manual for specific PN, but 5W-30 is also common for the 1GR-FE)
Coolant Type:
Toyota Super Long Life Coolant (Pink)
Known Issues:
While generally robust, common issues can include frame rust (especially in areas with road salt), potential for starter motor failure, exhaust manifold cracking (less common on later models), and occasional ABS/VSC sensor issues. Some owners report a less refined ride quality compared to unibody SUVs.
Standard Tire Size:
P265/70R17
Wheel Bolt Pattern:
6x139.7 mm (6x5.5 inches)
Brand Heritage:
Toyota has a long-standing reputation for building reliable, durable, and capable vehicles, particularly in the SUV segment with models like the Land Cruiser and 4Runner.
Model Evolution:
The FJ Cruiser was introduced for the 2007 model year, directly inspired by the classic FJ40 Land Cruiser. It blended retro styling with modern SUV underpinnings and off-road capability. The 2010 model received minor updates and continued its niche appeal.
Production Location:
Hino Motors, Hamura Plant, Tokyo, Japan
Production Years:
2007-2014
