2005 Volvo S60 Service & Repair Manual Software

Normaler Preis: $17.99
Verkaufspreis: $17.99
Normaler Preis
Grundpreis: pro

🏷️ Basic Information Identification Make: Volvo Model: S60 Year: 2005 Codes Chassis Code: P2 👋 Introduction Market Position Positioning: Premium compact executive sedan targeting a discerning audience valuing safety, comfort,...

27 people are viewing this right now

Typ: Autos

Anbieter:

Art.-Nr: 332613

Stichworte: 2005 Car Cars Featured S60 Volvo

Produktvarianten

Beschreibung

🏷️ Basic Information

Identification

Make:

Volvo

Model:

Year:

Codes

Chassis Code:

👋 Introduction

Market Position

Positioning:

Premium compact executive sedan targeting a discerning audience valuing safety, comfort, and performance.

Competitive Analysis

Competitors:

BMW 3 Series, Mercedes-Benz C-Class, Audi A4, Acura TL, Lexus IS.

Key Features

Safety Focus:

Renowned Volvo safety standards, including advanced crumple zones, side impact protection system (SIPS), and optional WHIPS (Whiplash Protection System).

Design Philosophy:

Scandinavian design emphasizing clean lines, ergonomic interiors, and driver-centric functionality.

Powertrain Options:

Smooth and refined inline-five cylinder engines, known for their balance and durability.

Manual Advantage:

Provides comprehensive factory-derived repair information for DIY enthusiasts and professional technicians, replacing costly printed manuals.

📋 Manual Details

Coverage Areas

Primary Coverage:

All service, repair, maintenance, and diagnostic procedures for the 2005 Volvo S60.

Engine Coverage:

2.4L, 2.4L Turbo (T5), 2.5L Turbo (2.5T).

Transmission Coverage:

5-speed Manual (M56), 5-speed Geartronic Automatic (AW55-50SN).

Page Count

Estimated Page Count:

Extensive, comparable to factory service manuals (exact number not specified, but described as comprehensive).

Manual Type

Type:

Online Service and Repair Manual Software.

Language

Language:

English

Format

Format:

Web-based Software / Online Access.

Access Duration:

1 Year Subscription.

📖 Manual Coverage

Systems Covered

Engine Mechanical:

Engine assembly, cylinder head, valve train, piston and connecting rod assembly, crankshaft and main bearings, lubrication system, cooling system.

Engine Performance:

Fuel injection, ignition system, turbocharging system, emissions control system.

Transmission Manual:

Clutch, transmission assembly, shift mechanisms, gears and shafts.

Transmission Automatic:

Automatic transmission assembly, torque converter, valve body, hydraulic control system, shift solenoids.

Drivetrain:

Front axle, rear axle, driveshafts, constant velocity joints, differentials.

Suspension:

Front suspension, rear suspension, shock absorbers, springs, control arms, bushings.

Steering:

Power steering system, steering rack, steering column, tie rods.

Brakes:

Front and rear brakes, anti-lock braking system (ABS), electronic brake-force distribution (EBD), brake calipers, rotors, pads, hydraulic lines.

Electrical System:

Battery, charging system, starter motor, ignition system, lighting system, power distribution.

Body And Chassis:

Body construction, exterior panels, doors, hood, trunk lid, interior trim, safety cage.

HVAC:

Heating, Ventilation, and Air Conditioning (HVAC) system, climate control, refrigerant system, blower motor, evaporator, condenser.

Wiring Diagrams:

Comprehensive electrical wiring diagrams for all vehicle systems.

Procedures Included

Maintenance:

Routine maintenance, oil changes, filter replacements, fluid checks and changes, spark plug replacement, belt replacement.

Troubleshooting:

Diagnostic procedures for identifying and resolving common and complex issues across all systems.

Repair:

Step-by-step repair instructions for component removal, installation, and adjustment.

Rebuilding:

Complete engine and transmission rebuilding procedures.

Diagnostics:

OBD-II diagnostics, fault code interpretation, live data analysis.

Technical Depth

Depth:

Factory-level technical detail, including specifications, tolerances, torque values, and diagnostic flowcharts.

📊 Manual Specifications

File Format

Digital Format:

Proprietary web-based platform.

Print Quality

Printability:

Content is accessible and viewable on various devices, not designed for direct printing of the entire manual.

Binding Type

Binding:

N/A (Online Access).

Paper Type

Paper Type:

N/A (Online Access).

⚙️ Engine Specifications

Primary Engine

Engine 1:

2.4L Inline-5 (Naturally Aspirated)

Engine 1 Displacement:

2435 cc

Engine 1 Code:

B5244S

Engine 1 Horsepower:

168 hp @ 5800 rpm

Engine 1 Torque:

170 lb-ft @ 4000 rpm

Engine 2:

2.4L Turbocharged Inline-5 (T5)

Engine 2 Displacement:

2435 cc

Engine 2 Code:

B5244T3

Engine 2 Horsepower:

217 hp @ 5000 rpm

Engine 2 Torque:

236 lb-ft @ 2400-4800 rpm

Engine 3:

2.5L Turbocharged Inline-5 (2.5T)

Engine 3 Displacement:

2521 cc

Engine 3 Code:

B5254T2

Engine 3 Horsepower:

208 hp @ 5000 rpm

Engine 3 Torque:

236 lb-ft @ 1500-4500 rpm

Fuel System

Fuel Delivery:

Electronic Fuel Injection (EFI) with multi-point injection.

Fuel Type:

Unleaded Gasoline (91 octane or higher recommended for turbocharged models).

🔧 Transmission

Standard

Standard Transmission:

5-speed Manual (M56H).

Optional

Optional Transmission:

5-speed Geartronic Automatic (AW55-50SN).

Features

Geartronic Functionality:

Allows manual shifting for driver engagement.

AWD Availability:

All-Wheel Drive (AWD) available with 2.5T models (Haldex system).

Fluid Specifications

Manual Transmission Fluid:

Volvo Manual Gearbox Oil (Part No. 1161618 or equivalent GL-4/GL-5 rated fluid).

Automatic Transmission Fluid:

AW-1 (Automatic Transmission Fluid Type 1), e.g., Volvo Transmission Fluid 1161540.

📐 Dimensions

Exterior

Length:

185.8 inches (4720 mm)

Width:

70.0 inches (1778 mm)

Height:

57.4 inches (1458 mm)

Wheelbase:

109.9 inches (2791 mm)

Weights

Curb Weight Approx:

3400 - 3700 lbs (depending on engine and drivetrain)

Gross Vehicle Weight Rating:

Not specified in product info, consult specific VIN documentation.

🛡️ Safety Features

Ratings

NHTSA Front Impact Driver:

5 Stars

NHTSA Front Impact Passenger:

5 Stars

NHTSA Side Impact Front Driver:

5 Stars

NHTSA Side Impact Front Passenger:

5 Stars

NHTSA Side Impact Rear Driver:

5 Stars

NHTSA Side Impact Rear Passenger:

5 Stars

IIHS Frontal Offset:

IIHS Side Impact:

Active Features

Standard Anti-lock Braking System.

Traction Control:

Standard Traction Control System (TCS).

Stability Control:

Optional Electronic Stability Control (ESC).

Passive Features

Airbags:

Dual front airbags, front side airbags, and inflatable side curtain airbags.

Sips:

Side Impact Protection System.

Whips:

Optional Whiplash Protection System.

💡 Technology Features

Infotainment

Audio System:

Available premium audio systems, including Dolby Surround Pro Logic II.

Navigation:

Optional factory navigation system.

Driver Assistance

Cruise Control:

Standard cruise control.

Parking Assist:

Optional rear parking sensors.

Connectivity

Phone Integration:

Optional Bluetooth hands-free phone system.

Auxiliary Input:

Standard auxiliary audio input jack (may require adapter for some devices).

🔧 Maintenance

Service Intervals

Oil Change Interval:

Every 7,500 miles or 12 months, whichever comes first (using synthetic oil).

Timing Belt Interval:

Every 105,000 miles or 7 years (for 2.4L and 2.4L Turbo engines; 2.5T uses a timing chain).

Coolant Replacement:

Every 5 years or 60,000 miles (using Volvo Coolant VCS).

Fluid Specifications

Engine Oil Specification:

SAE 0W-30 or 5W-30 Synthetic Engine Oil meeting Volvo VCC 95200356 specification.

Coolant Type:

Volvo VCS (Vehicle Coolant Specification) - a long-life, orange-colored ethylene glycol-based coolant.

Brake Fluid:

DOT 3 or DOT 4 Brake Fluid.

Known Issues

Pcv System:

Clogged Positive Crankcase Ventilation (PCV) system can lead to oil leaks and engine issues.

Solenoid Issues:

Failure of the CVVT (Continuously Variable Valve Timing) solenoids can cause rough idling and performance problems.

Egr Valve:

The Exhaust Gas Recirculation (EGR) valve can become clogged with carbon, leading to performance issues.

ABS Module:

ABS hydraulic units and control modules can be prone to failure.

📚 Vehicle History

Brand Heritage

Volvo Reputation:

Long-standing reputation for safety, durability, and robust engineering.

Model Evolution

S60 First Gen:

Launched in 2000 for the 2001 model year, the S60 is based on Volvo's P2 platform.

2005 Update:

The 2005 model year received a mild facelift, including revised front and rear styling, updated interior features, and new wheel designs.

Production

Manufacturing Location:

Ghent, Belgium and Uddevalla, Sweden.

🏆 Awards & Recognition

Recognitions

IIHS Top Safety Pick:

Awarded 'Top Safety Pick' by the Insurance Institute for Highway Safety multiple times during its first generation.

Automotive Journal Awards:

Received various accolades from automotive publications for its safety and design.
