Segment:
Supersport / Sportbike segment, positioned as a more accessible yet performance-oriented alternative to the YZF-R1.
Key Competitors:
Ducati Panigale V2, Kawasaki Ninja ZX-6R, Honda CBR650R, Aprilia RS 660.
Design Philosophy:
Emphasizes agility, rider-centric ergonomics, and track-inspired styling, leveraging the acclaimed CP2 engine.
Target Audience:
Enthusiasts seeking a thrilling yet manageable supersport experience, suitable for both street riding and track days.
Manual Value:
Provides technicians and owners with the authoritative technical documentation required for expert maintenance and repair, mirroring dealership-level access.
Engine:
Detailed breakdown of the CP2 engine, including cooling system, lubrication, fuel injection, ignition, and emission control.
Transmission:
Coverage of the 6-speed constant mesh transmission, clutch operation, gear shifting mechanisms, and lubrication.
Chassis And Suspension:
In-depth information on the aluminum frame, front telescopic forks (including adjustment and service), rear suspension (monoshock, linkage, adjustment), and swingarm.
Brakes:
Complete details on the front dual hydraulic disc brakes (calipers, master cylinder, fluid), rear hydraulic disc brake, ABS system integration, and brake bleeding procedures.
Electrical System:
Wiring diagrams, component identification, battery service, charging system, lighting, ignition system troubleshooting, and ECU diagnostics.
Fuel System:
Components of the fuel tank, fuel pump, fuel injectors, throttle body assembly, and pressure regulation.
Cooling System:
Radiator, cooling fan, coolant circulation, thermostat operation, and coolant flush procedures.
Routine Maintenance:
Oil and filter changes, air filter replacement, spark plug inspection/replacement, chain adjustment and lubrication, brake fluid checks, and tire pressure monitoring.
Engine Overhaul:
Detailed steps for engine disassembly, inspection of internal components (pistons, rings, valves, camshafts), cylinder head service, and reassembly.
Suspension Servicing:
Fork seal replacement, fork oil change, rear shock absorber service, and linkage bearing maintenance.
Brake System Repair:
Caliper overhaul, master cylinder replacement, line flushing, and ABS sensor troubleshooting.
Electrical Diagnostics:
Troubleshooting electrical faults using wiring diagrams, testing of sensors, actuators, and ECUs, and common wiring issues.
Troubleshooting:
Systematic diagnostic procedures for common performance issues, starting problems, running irregularities, and warning light diagnosis.
Depth:
Factory-level repair information, suitable for professional technicians and advanced DIY enthusiasts. Includes detailed specifications and torque values.
Printability:
Printable (high-resolution images and text).
Binding Type:
N/A (Digital Download)
Paper Type:
N/A (Digital Download)
Operating Systems:
Compatible with Windows and Mac operating systems.
Searchability:
Text-searchable PDF for quick information retrieval.
Multimedia:
Includes numerous high-quality photographs, detailed diagrams, exploded views, and schematics.
Engine Type:
Liquid-cooled, 4-stroke, DOHC, 4-valve, Parallel-twin ('CP2' engine)
Bore X Stroke:
81.0 mm x 67.5 mm
Compression Ratio:
11.5 : 1
Horsepower Max:
Approx. 90 HP (67.4 kW) @ 10,000 rpm (Varies by market regulation)
Torque Max:
Approx. 68 Nm (49.4 lb-ft) @ 8,000 rpm (Varies by market regulation)
Fuel Induction:
Fuel Injection with Mikuni throttle bodies (41mm twin bore)
Fuel Type:
Unleaded Gasoline (Minimum 91 RON / 87 Octane)
Oil Type Recommendation:
Yamaha Performance Motor Oil 10W-40 (or equivalent API SG, JASO MA or MA2 certified)
Coolant Type:
Yamalube Coolant (50% mixture of ethylene glycol and deionized water)
Coolant Capacity:
Approx. 1.6 Liters (0.42 US gal)
Transmission Type:
6-speed, constant mesh
Clutch Type:
Assist & Slipper Clutch, Wet, Multi-plate
Final Drive:
O-ring sealed chain
Transmission Oil Type:
Yamaha Gear Oil 10W-30 (or equivalent API GL-4, SAE 80 hypoid gear oil)
Transmission Oil Capacity:
Approx. 0.9 Liters (0.95 US qt)
ABS:
Standard (Bosch ABS system)
Traction Control:
Not equipped with traction control as standard.
Lighting:
Full LED lighting (headlight, taillight, turn signals).
Braking Features:
Radial-mount front calipers, high-performance front and rear brake discs.
Display:
Full LCD instrument cluster with gear position indicator, fuel gauge, clock, trip meters, and other essential information.
A Mode Technology:
Features Yamaha's CP2 engine technology, known for its strong low-to-mid range torque and linear power delivery, enhancing rideability.
Connectivity Features:
No integrated smartphone connectivity or Bluetooth features on base models. Information primarily focused on mechanical and electrical systems.
Frame Type:
Lightweight aluminum Deltabox frame for optimal rigidity and handling.
Suspension Type:
Fully adjustable 43mm inverted front forks (KYB) and adjustable Monocross rear suspension (KYB).
First Service:
1,000 km (600 miles) or 1 month, whichever comes first. Includes oil change, filter check, chain adjustment, and general inspection.
Subsequent Oil Change:
Every 5,000 km (3,000 miles) or 6 months, whichever comes first.
Valve Clearance Check:
Every 20,000 km (12,000 miles).
Brake Fluid Type:
DOT 4 (SAE J1703, FMVSS 116)
Fork Oil Type:
Yamaha Fork Oil G10 (or equivalent SAE 10W fork oil)
Fork Oil Quantity:
Approx. 478 ml per fork (check manual for exact specification and level)
Common Wear Items:
Tires, brake pads, chain and sprockets, clutch plates (depending on riding style).
Potential Performance Enhancements:
The manual covers standard configurations, but enthusiasts may refer to it for understanding potential modifications like aftermarket exhausts or tuning, though such modifications void warranty.
Yamaha Sportbike Legacy:
Yamaha has a rich history in motorsport, with iconic models like the YZF-R1, FZR, and RD series shaping the sportbike landscape.
Yzf Heritage:
The YZF designation signifies Yamaha's commitment to performance-oriented sportbikes, with the R7 specifically reviving a legendary racing nameplate for a modern street-focused machine.
Introduction Year:
2021 (for the current model)
Manufacturing Location:
Japan
