Positioning:
A high-performance, utility-focused ATV positioned for serious off-road enthusiasts and work applications.
Competitors:
Competes with models like the Yamaha Grizzly, Honda Foreman/Rancher, and Kawasaki Brute Force within the 400-500cc utility ATV segment.
Engine Power:
Robust 450cc class engine providing ample power for various terrains.
4X4 System:
Advanced 4x4 system for superior traction and off-road capability.
Suspension And Handling:
Independent suspension for a comfortable ride and improved handling.
Durability And Reliability:
Known for Suzuki's reputation for building durable and reliable ATVs.
Value:
Instant digital access provides immediate utility for maintenance and repair, bypassing shipping delays and offering cost-effectiveness compared to physical manuals or dealership service.
Powertrain:
Engine, transmission, clutch, drivetrain components
Chassis And Suspension:
Frame, suspension (front and rear), steering, wheels, tires
Braking System:
Front and rear brakes, hydraulic system
Electrical And Lighting:
Ignition system, charging system, starting system, lighting, wiring diagrams, battery
Fuel And Lubrication:
Fuel delivery, fuel tank, carburetor/fuel injection (if applicable), lubrication system, oil specifications
Body And Controls:
Seats, locks, body panels, controls, handlebars
Maintenance:
Routine maintenance, scheduled service, fluid changes, filter replacements
Troubleshooting:
Diagnostic procedures, common problem identification and resolution
Repair:
Component disassembly, inspection, repair, and reassembly
Overhaul:
Engine, transmission, and other major component overhauls
Wiring Diagrams:
Comprehensive electrical system wiring schematics
Specifications And Tolerances:
Detailed torque specifications, clearances, and wear limits
Depth:
Comprehensive: Covers all aspects from basic maintenance to advanced diagnostics and complete rebuilds, comparable to factory dealership manuals.
Searchability:
Likely searchable text within the PDF, enabling quick navigation.
Printability:
Printable, allowing users to create physical copies or specific sections.
Binding Recommendation:
Ideal for use in 3-ring binders for easy page turning and reference.
Paper Usage:
Printable sections for workshop use to avoid damage to original digital copy.
Engine Type:
4-stroke, DOHC, 4-valve, single-cylinder
Displacement:
447 cm³ (27.28 cu. in.)
Bore X Stroke:
94.0 mm x 81.8 mm (3.70 in x 3.22 in)
Cooling System:
Liquid-cooled
Horsepower:
Estimated 30-35 HP (specific figures not always published by manufacturers for ATVs)
Torque:
Estimated 27-30 lb-ft
Fuel Delivery:
Electronic Fuel Injection (EFI)
Throttle Body Size:
Likely 38mm or similar for this displacement
Fuel Type:
Unleaded gasoline, 87 octane (minimum)
Transmission Type:
Automatic Continuously Variable Transmission (CVT)
Gear Selection:
Hi, Lo, Neutral, Reverse, Park
Drive System:
Shaft drive, 4WD with locking front differential
Engine Braking:
Effective engine braking provided by the CVT system.
Overall Length:
Approx. 2,025 mm (79.7 in)
Overall Width:
Approx. 1,105 mm (43.5 in)
Overall Height:
Approx. 1,140 mm (44.9 in)
Wheelbase:
Approx. 1,295 mm (51.0 in)
Curb Weight:
Approx. 276 kg (608 lbs)
Front Rack Capacity:
Approx. 45 kg (99 lbs)
Rear Rack Capacity:
Approx. 85 kg (187 lbs)
Towing Capacity:
Approx. 297 kg (655 lbs)
Fuel Tank Capacity:
Approx. 16.0 L (4.2 US gal)
Atv Safety Standards:
Designed to meet applicable ANSI standards for recreational ATVs.
4Wd With Locking Differential:
Enhances traction and control in challenging terrain.
Disc Brakes:
Hydraulic disc brakes on all wheels provide strong stopping power.
Handlebars And Controls:
Ergonomically designed for rider control and comfort.
Lighting:
Dual headlights and taillight/brake light for visibility.
Infotainment System:
Basic instrumentation: speedometer, odometer, trip meter, fuel gauge, 2WD/4WD indicator, 4WD lock indicator.
Driving Modes:
Selectable 2WD/4WD with front differential lock.
Charging Port:
Often equipped with a DC power outlet for charging accessories.
Oil Change Interval:
Refer to manual for specific hours/mileage, typically around 1,000 miles or 6 months for typical usage.
Air Filter Cleaning:
Recommended inspection and cleaning at shorter intervals, especially in dusty conditions.
Spark Plug Replacement:
Typically recommended around 3,000-4,000 miles, but check manual for exact spec.
Engine Oil Type:
Suzuki recommends SAE 10W-40 API SG or higher (check manual for precise grade and API classification).
Engine Oil Capacity:
Approx. 2.0 L (2.1 US qt) without filter change; Approx. 2.2 L (2.3 US qt) with filter change.
Coolant Type:
Antifreeze/coolant mixture, typically a 50/50 blend of ethylene glycol based coolant and distilled water.
Brake Fluid Type:
DOT 3 or DOT 4 brake fluid (check manual for specific recommendation).
Common Wear Items:
CVT belt wear, brake pad wear, suspension bushings, wheel bearings, tire wear are common on any ATV of this age.
Efi System:
While generally reliable, EFI systems can be sensitive to fuel quality and can sometimes experience sensor issues. The manual will cover diagnostics.
Suzuki Atv Legacy:
Suzuki has a long-standing reputation for producing reliable and capable ATVs, building upon their automotive and motorcycle expertise.
King Quad Lineage:
The King Quad line is Suzuki's flagship utility ATV series, known for its performance and features. The 450AXi followed earlier King Quad models, offering an updated platform with EFI.
Manufacturing Location:
Typically manufactured in Japan or other Suzuki global facilities.
