Description

🏷️ Basic Information

Identification

Make:

Model:

Festiva

Year:

Codes

Platform:

DA1 (Mazda 121)

👋 Introduction

Market Position

Segment:

Subcompact, economy car

Target Audience:

Budget-conscious car buyers seeking reliable and efficient transportation

Competitive Analysis

Competitors:

Hyundai Excel, Kia Pride (Mazda 121 platform), Chevrolet Sprint, Geo Metro

Key Features

Distinctive Features:

Compact size, fuel efficiency, affordability, Mazda-derived platform

Software Advantages

Convenience:

Instant access, searchable content, portability, no physical storage needed

Cost Effectiveness:

Less expensive than traditional printed manuals, saves on shop labor costs

Accuracy:

Licensed information derived from OE (Original Equipment) materials

📋 Manual Details

Coverage Areas

Primary Coverage:

Mechanical, Electrical, Body, Maintenance, Diagnostics, Troubleshooting, Repair

Secondary Coverage:

HVAC, Suspension, Steering, Brakes, Drivetrain, Wiring Diagrams

Page Count

Estimated Page Count:

Varies by software version; typically equivalent to 500+ pages of printed manual

Manual Type

Type:

Service and Repair Manual Software

Language

Language:

English

Format

Format:

Online/Software (Web Browser Accessible)

📖 Manual Coverage

Systems Covered

Engine:

1.3L (79 cu in) Inline-4 (GA13DS)

Drivetrain:

Front-wheel drive (FWD)

Suspension:

Front: MacPherson struts, Rear: Coil springs with trailing arms

Brakes:

Front: Ventilated discs, Rear: Drums

Steering:

Rack and pinion (manual or power assisted depending on trim)

Electrical:

Charging system, Starting system, Ignition system, Lighting, Instrumentation, Power accessories

Body:

Body panel removal/installation, Glass, Seals, Interior trim

Procedures Included

Maintenance:

Oil changes, Filter replacements, Spark plug replacement, Fluid checks and top-offs, Belt inspections and replacement

Repair:

Engine overhaul, Transmission servicing, Brake caliper/wheel cylinder replacement, Suspension component replacement, Steering rack repair, Electrical component diagnosis and replacement

Diagnostics:

Troubleshooting guides for common drivability issues, electrical faults, and mechanical problems

Specifications:

Torque specifications for critical fasteners, component clearances, and alignment data

Technical Depth

Depth:

Comprehensive, from routine maintenance to complete engine and transmission rebuilds

📊 Manual Specifications

File Format

Accessibility:

Web browser compatible across PC, laptop, smartphone, and tablet

Print Quality

Readability:

High-resolution, clear text and diagrams

Binding Type

Binding:

N/A (Digital Format)

Paper Type

Paper:

N/A (Digital Format)

⚙️ Engine Specifications

Primary Engine

Engine Code:

GA13DS

Displacement:

1.3 liters (1324 cc)

Configuration:

Inline-4 cylinder, SOHC (Single Overhead Cam)

Bore X Stroke:

71.0 mm x 83.6 mm (approx.)

Compression Ratio:

9.3:1 (approx.)

Horsepower:

64 hp @ 5500 rpm (approx.)

Torque:

71 lb-ft @ 3500 rpm (approx.)

Fuel System

Fuel Delivery:

Electronic Fuel Injection (EFI)

Fuel Type:

Unleaded gasoline

Fuel Octane Rating:

87 octane (minimum)

🔧 Transmission

Standard

Type:

5-speed manual

Optional

Type:

3-speed automatic

Features

Clutch:

Dry, single plate, diaphragm spring

Transmission Fluid Type:

API GL-4, SAE 75W-90 (Manual); ATF DEXRON-II (Automatic)

📐 Dimensions

Exterior

Length:

3740 mm (approx. 147.2 inches)

Width:

1610 mm (approx. 63.4 inches)

Height:

1370 mm (approx. 53.9 inches)

Wheelbase:

2300 mm (approx. 90.6 inches)

Ground Clearance:

140 mm (approx. 5.5 inches)

Weights

Curb Weight:

800-850 kg (approx. 1760-1870 lbs), depending on transmission and equipment

Gross Vehicle Weight Rating:

1200 kg (approx. 2645 lbs) (approx.)

🛡️ Safety Features

Ratings

NHTSA Frontal Crash Rating:

Not comprehensively tested by NHTSA in the modern sense; generally considered basic for its era

Active Features

Braking System:

Front ventilated discs, rear drum brakes

Parking Brake:

Handbrake operating rear brakes

Passive Features

Seat Belts:

3-point front, 2-point rear lap belts

Child Seat Anchors:

Not standard; may have provision for aftermarket installation

💡 Technology Features

Infotainment

Audio System:

Basic AM/FM radio with cassette player

Driver Assistance

Not typically available on the 1990 model year

🔧 Maintenance

Service Intervals

Oil Change:

Every 5,000 miles or 6 months, whichever comes first

Air Filter Replacement:

Every 15,000 miles or 12 months

Spark Plug Replacement:

Every 30,000 miles

Timing Belt Replacement:

Every 60,000 miles or 4 years (critical maintenance)

Fluid Specifications

Engine Oil:

API SG, SAE 10W-30 or 10W-40

Coolant:

Ethylene glycol-based coolant, 50/50 mixture with distilled water

Brake Fluid:

DOT 3 or DOT 4

Known Issues

Common Problems:

Timing belt failure (if not replaced on schedule), carburetor issues (on earlier non-EFI models), rust susceptibility in certain climates, minor electrical gremlins

Common Issues

Engine Performance:

Can be sluggish; regular maintenance is key to optimal performance.

📚 Vehicle History

Brand Heritage

Ford Strategy:

Expansion into global markets, offering affordable and efficient vehicles

Model Evolution

Platform Origin:

Based on the Mazda 121 (DA platform), showcasing Ford's collaboration with Mazda

First Generation:

Introduced globally in the late 1980s, with the US market debut in 1987 for the 1988 model year.

Production

Manufacturing Location:

Primarily South Korea (Kia Motors)

🏆 Awards & Recognition

Recognitions

Industry Awards:

No significant industry awards reported for this specific model year, recognized more for value and economy.
