Positioning:
A digital service and repair manual for the DIY enthusiast and professional mechanic, providing factory-derived information.
Comparison:
Offers a modern, convenient, and often more affordable alternative to traditional printed service manuals. Provides instant access and searchability.
Licensing:
Officially licensed, derived from OE (Original Equipment) materials.
Software Provider:
RepairSurge
Access Duration:
1 Year included, with discounts for renewal.
Primary Coverage:
1996 GMC C1500 Suburban
Secondary Coverage:
May include general diagnostic procedures applicable to other GMT400 platform vehicles of similar vintage.
Estimated Pages:
N/A (Software based, dynamic content)
Type:
Service and Repair Manual (Software)
Format:
Online access via web browser; PC, laptop, smartphone, tablet compatible
Engine:
All Gasoline Engine Variants (e.g., 5.0L V8, 5.7L V8)
Drivetrain:
Transmission (Automatic), Transfer Case (4WD), Axles, Driveshafts, Differentials
Brakes:
Front Disc, Rear Drum/Disc (depending on configuration), ABS System
Steering:
Power Steering System, Steering Column
Suspension:
Front Independent Suspension (Torsion Bar), Rear Leaf Spring Suspension
Electrical:
Full Electrical Schematics, Lighting, Ignition System, Starting System, Charging System, Body Control Modules, Accessories
Climate Control:
Heating, Ventilation, and Air Conditioning (HVAC)
Body:
Body and Chassis Repair, Doors, Windows, Seats, Interior Trim
Maintenance:
Scheduled Maintenance, Fluid Changes, Filter Replacements, Lubrication
Diagnostics:
Troubleshooting Guides, Symptom-Based Diagnostics, Diagnostic Trouble Codes (DTCs) interpretation
Repair:
Component Removal and Installation, System Overhauls, Component Rebuilding
Specifications:
Torque Specifications, Clearances, Adjustments, Dimensional Data
Depth:
Comprehensive, from basic maintenance to complex engine and transmission repairs, electrical system troubleshooting.
Engine 1:
5.0L (305 cu. in.) Vortec V8 (L31)
Engine 2:
5.7L (350 cu. in.) Vortec V8 (L31)
Horsepower 5.0L:
Approx. 205 hp @ 4400 RPM
Torque 5.0L:
Approx. 275 lb-ft @ 3200 RPM
Horsepower 5.7L:
Approx. 255 hp @ 4600 RPM
Torque 5.7L:
Approx. 330 lb-ft @ 3200 RPM
Injection:
Multi-port Fuel Injection (MPFI)
Fuel Type:
Unleaded Gasoline
NHTSA Ratings 1996:
While specific NHTSA ratings for 1996 models are not readily available in a standardized format from that era, GM implemented passive safety features typical for the time.
ABS:
Anti-lock Braking System (ABS) available/standard on certain trims.
Airbags:
Driver and Passenger Airbags (standard)
Seatbelts:
Three-point front seat belts, lap belts in rear.
Oil Change:
Every 3,000 - 7,500 miles or 6-12 months, depending on oil type and driving conditions (refer to manual for exact OE recommendations).
Air Filter Replacement:
Every 15,000 - 30,000 miles or as needed based on visual inspection.
Spark Plugs Replacement:
Typically around 100,000 miles for dedicated platinum or iridium plugs, but check manual for specific recommendations.
Engine Oil:
SAE 5W-30 or 10W-30 (depending on climate), API Service SG or SH classification. Check manual for precise viscosity and API requirements.
Coolant:
GM Pre-mixed 50/50 Ethylene Glycol Coolant (Green)
Transmission Fluid:
Dexron III Automatic Transmission Fluid
Brake Fluid:
DOT 3 (or higher rated) Brake Fluid
Intake Manifold Gaskets:
Leaking intake manifold gaskets, particularly on the 5.0L and 5.7L Vortec engines, causing coolant leaks and potential misfires.
Heater Core:
Heater core leaks are a common failure, often requiring dashboard removal for replacement.
Rear Main Seal:
Rear main crankshaft seal leaks can occur over time.
Heritage:
GMC (General Motors Truck Company) has a long history of producing robust trucks and utility vehicles, including the Suburban, one of the longest-running nameplates in automotive history.
Generation:
This 1996 model is part of the GMT400 platform (1992-1999), representing a significant redesign with more rounded styling and updated powertrains compared to previous generations.
Manufacturing Location:
Primarily Janesville, Wisconsin, USA.
