🏷️ Basic Information

Make:

Subaru

Model:

Forester

Model Years Covered:

1999, 2000, 2001, 2002

Chassis Codes:

SF Series (First Generation)

Engine Codes Covered:

EJ253 (2.5L SOHC NA), EJ255 (2.5L DOHC Turbo - XT models)

👋 Introduction

Vehicle Segment:

Compact Crossover SUV / Station Wagon

Target Audience:

Families, outdoor enthusiasts, drivers seeking all-wheel drive capability and practicality.

Key Competitors:

Honda CR-V, Toyota RAV4, Ford Escape, Mazda Tribute, Nissan Xterra.

Drivetrain Advantage:

Standard Symmetrical All-Wheel Drive (AWD) across most trims, providing superior traction and stability compared to many front-wheel-drive competitors.

Practicality:

Spacious interior for its class, generous cargo volume, good ground clearance for light off-roading and adverse weather conditions.

Engine Performance:

Reliable Subaru Boxer engines known for their low center of gravity, contributing to balanced handling.

📋 Manual Details

Main Coverage Areas:

Engine Mechanical, Engine Control System, Fuel System, Exhaust System, Transmission (Manual & Automatic), Drivetrain (AWD System), Suspension, Steering, Brakes (ABS), Body & Chassis, HVAC System, Electrical System, Body Electronics, Diagnostics, Troubleshooting, Specifications

Estimated Page Count:

1000-1500 (typical for comprehensive FSM)

Manual Type:

Factory Service Manual (FSM) / Repair Manual / Workshop Manual

Language:

English

Digital Format:

ZIP archive containing PDF files

📖 Manual Coverage

Engine Mechanical:

Detailed disassembly, assembly, inspection, and torque specifications for EJ253 and EJ255 engines, including cylinder heads, pistons, crankshaft, camshafts, timing belt/chain, oil pump, and lubrication system.

Engine Control System:

ECU operation, sensor diagnostics (MAF, O2, TPS, CKP, CMP), actuator control (injectors, ignition coils), emissions control systems (EGR, PCV), diagnostic trouble codes (DTCs) and their interpretation.

Fuel System:

Fuel pump, fuel filter, fuel injectors, fuel pressure regulator, evaporative emission control (EVAP) system, fuel tank and lines.

Transmission Drivetrain:

Manual transmission (5-speed) and automatic transmission (4-speed) operation, maintenance, diagnostics, and repair. Includes transfer clutch, differentials (front and rear), and driveshafts.

Suspension Steering:

Front and rear suspension components (struts, springs, control arms, bushings), alignment specifications, power steering system (pump, rack and pinion, hoses).

Brakes:

Disc brake systems (front and rear), ABS system (sensors, modulator, hydraulic unit), brake fluid specifications, bleeding procedures, parking brake.

Electrical System:

Battery, charging system (alternator), starting system (starter motor), ignition system, lighting system, fuses, relays, wiring diagrams, component locations.

HVAC Body:

Air conditioning system (refrigerant, compressor, evaporator, condenser), heating system, ventilation, body panel removal/installation, interior trim, door mechanisms, glass replacement.

Routine Maintenance:

Oil change intervals and specifications, filter replacement (oil, air, cabin), spark plug replacement, coolant flush, brake fluid replacement, drive belt inspection and replacement.

Diagnostics Troubleshooting:

Step-by-step diagnostic flowcharts for common symptoms, electrical troubleshooting using wiring diagrams, component testing procedures, OBD-II diagnostic scanner usage.

Major Repairs:

Engine rebuilds, cylinder head removal and repair, transmission overhaul, brake caliper replacement, suspension component replacement, turbocharger (if applicable) servicing.

Component Replacement:

Detailed instructions for replacing common wear items and major components such as alternators, water pumps, radiators, fuel pumps, clutch assemblies, CV joints, and body panels.

Depth Of Coverage:

Comprehensive from basic maintenance to advanced engine and transmission diagnostics and repair. Includes detailed specifications, torque values, and schematics.

📊 Manual Specifications

File Format Details:

PDF (Portable Document Format). High-resolution scans of original factory documents, ensuring clarity and readability. Likely includes searchable text capabilities if OCR was applied during conversion.

Scan Quality:

High Quality. Implies clear text, legible diagrams, and accurate reproduction of original content.

Binding Type:

Digital (Not applicable for physical binding).

Paper Type:

Digital (Not applicable for physical paper type).

⚙️ Engine Specifications

Engine Displacement:

2.5 Liters (2457 cc)

Engine Configuration:

Horizontally Opposed (Boxer) Four-Cylinder

Valve Mechanism:

SOHC (Single Overhead Camshaft) for NA models (EJ253), DOHC (Dual Overhead Camshaft) for Turbo models (EJ255).

Horsepower Na:

Approx. 165 hp @ 5,600 rpm (EJ253)

Torque Na:

Approx. 166 lb-ft @ 4,000 rpm (EJ253)

Horsepower Turbo Xt:

Approx. 177 hp @ 5,600 rpm (EJ255 - specific model/year variations apply)

Torque Turbo Xt:

Approx. 177 lb-ft @ 3,200 rpm (EJ255 - specific model/year variations apply)

Fuel Delivery:

Electronic Fuel Injection (EFI)

Fuel Type:

Unleaded Gasoline

Oil Capacity Quarts:

4.7 quarts (4.5 liters) with filter change (EJ253/EJ255)

Recommended Oil Viscosity:

5W-30 (check manual for specific temperature ranges)

Spark Plug Type:

NGK Platinum or Iridium recommended (e.g., PFR5BG-11)

🔧 Transmission

Standard Transmission Type:

5-Speed Manual Transmission

Optional Transmission Type:

4-Speed Electronically Controlled Automatic Transmission

AWD System:

Symmetrical All-Wheel Drive (AWD) with viscous coupling center differential and rear differential.

Manual Transmission Fluid Capacity:

Approx. 2.0 liters

Manual Transmission Fluid Type:

GL-5 Gear Oil (e.g., 75W-90)

Automatic Transmission Fluid Capacity:

Approx. 3.8 liters (drain and fill)

Automatic Transmission Fluid Type:

Subaru ATF-HP (or equivalent Dexron III/Mercon compatible)

📐 Dimensions

Length:

Approx. 175.6 inches (4460 mm)

Width:

Approx. 69.7 inches (1770 mm)

Height:

Approx. 63.0 inches (1600 mm)

Wheelbase:

Approx. 103.0 inches (2615 mm)

Ground Clearance:

Approx. 7.7 inches (196 mm)

Passenger Volume:

Approx. 99.7 cu ft

Cargo Volume Behind Rear Seat:

Approx. 35.1 cu ft

Cargo Volume With Rear Seat Folded:

Approx. 68.4 cu ft

Curb Weight Approx:

3200 - 3400 lbs (depending on trim and transmission)

Towing Capacity:

Typically rated up to 2000 lbs (check specific year/trim for confirmation)

🛡️ Safety Features

NHTSA Frontal Impact:

Likely received 4-star ratings for driver and passenger in frontal impact tests (based on era standards).

IIHS Side Impact:

Ratings varied by year; 'Acceptable' or 'Good' was common for vehicles of this era.

Active Safety Features:

Standard Symmetrical AWD, Anti-lock Braking System (ABS), Electronic Brake-force Distribution (EBD).

Passive Safety Features:

Dual front airbags, front side-impact airbags (optional on some trims), three-point seatbelts with pretensioners, crumple zones, reinforced passenger cage.

💡 Technology Features

Audio System:

Factory fitted radio/CD player, with optional premium sound systems. Manual will cover speaker replacement, head unit removal, and wiring.

Driver Assistance Features:

Limited by modern standards. Primarily ABS and AWD. Cruise control is standard on most models.

Connectivity Options:

None from the factory in terms of Bluetooth or USB. Manual will detail basic wiring for aftermarket installations.

🔧 Maintenance

Oil And Filter Change:

Every 3,750 miles (6,000 km) or 3.75 months, or 7,500 miles (12,000 km) or 7.5 months under severe driving conditions (consult manual for specifics).

Air Filter Replacement:

Every 15,000 miles (24,000 km) or 15 months.

Spark Plug Replacement:

Every 30,000 miles (48,000 km) for platinum plugs.

Timing Belt Replacement:

Every 60,000 miles (96,000 km) or 60 months is a critical interval for EJ series engines to prevent catastrophic failure.

Coolant Replacement:

Initial replacement at 60,000 miles (96,000 km), then every 30,000 miles (48,000 km) or 30 months thereafter.

Coolant Type:

Subaru Super Coolant (Blue) or equivalent ethylene glycol-based coolant.

Brake Fluid Type:

DOT 3 or DOT 4

Power Steering Fluid:

ATF (Automatic Transmission Fluid)Dexron II/III

Head Gasket Leaks:

While more prevalent in EJ25 DOHC engines of later generations, some earlier EJ25 SOHC engines could experience head gasket issues, particularly external coolant leaks. This manual would detail diagnostic procedures.

Timing Belt Wear:

Critical to adhere to the timing belt replacement interval to prevent interference engine damage. Manual will provide correct component part numbers and procedures.

Automatic Transmission Behavior:

Some reports of rough shifting or delayed engagement may occur over time; manual covers diagnostic procedures for the valve body and solenoids.
