🏷️ Basic Information

Make:

BMW

Model:

R 1150 R / R 1150 GS

Year:

2000

Chassis Codes:

R22 (R 1150 R), R21 (R 1150 GS)

👋 Introduction

Segment:

Premium adventure touring / sport-touring motorcycles.

Target Audience:

BMW motorcycle owners, independent repair shops specializing in BMW motorcycles, enthusiast DIY mechanics.

Competitors:

Honda VFR800, Triumph Tiger 955i, Yamaha TDM850/900.

Bmw Distinctiveness:

Boxer-twin engine, Telelever front suspension, robust build quality, extensive touring capabilities.

Value For Owner:

Enables owners to perform routine maintenance and more complex repairs, saving on dealership costs and extending the motorcycle's lifespan. Crucial for accurate diagnostics and troubleshooting.

📋 Manual Details

Engines Covered:

All R 1150 R and R 1150 GS variants for the 2000 model year

Transmissions Covered:

All transmission types and configurations

Trim Levels Covered:

All trim levels and model designations

Estimated Page Count:

~600-800 pages (typical for comprehensive workshop manuals of this era)

Type:

Workshop Repair Service Manual

Language:

English

Format:

PDF Download

📖 Manual Coverage

Engine:

Complete engine disassembly, assembly, diagnostics, tuning, component testing (e.g., oil pressure, compression), fuel injection system, ignition system, exhaust system.

Transmission And Drivetrain:

Gearbox overhaul, clutch service and replacement, driveshaft maintenance, final drive unit service and inspection.

Chassis And Suspension:

Front fork (Telelever) service and repair, rear shock absorber (Paralever) maintenance and replacement, steering head bearing service, wheel bearing replacement, swingarm service.

Brakes:

Brake system diagnostics, fluid replacement, bleeding procedures, caliper overhaul, master cylinder service, ABS system troubleshooting (if applicable).

Electrical System:

Wiring diagrams, component testing (alternator, starter, battery), lighting system, ignition switch, instrument cluster, diagnostic fault codes (DTC) interpretation.

Fuel System:

Fuel tank removal and installation, fuel pump service, fuel filter replacement, fuel injectors cleaning and testing.

Cooling System:

Oil cooler service, oil circulation system diagnostics and maintenance.

Bodywork And Fittings:

Fairing removal and installation, seat service, luggage system mounting, chassis component inspection and replacement.

Routine Maintenance:

Oil change intervals and specifications, spark plug replacement, air filter cleaning/replacement, brake fluid flush, final drive oil change.

Troubleshooting:

Diagnostic flowcharts for common and uncommon issues, symptoms and probable causes, step-by-step troubleshooting guides for electrical and mechanical problems.

Repair And Rebuild:

Detailed instructions for component disassembly, cleaning, inspection, measurement, part replacement, and reassembly. Includes critical torque specifications.

Diagnostic Procedures:

Methods for checking system operation, component testing using multimeters and specialized tools, interpretation of diagnostic indicators.

Depth Of Coverage:

Comprehensive, covering from basic rider maintenance to full engine and gearbox rebuilds, electrical system diagnostics, and chassis component overhauls.

📊 Manual Specifications

PDF Quality:

High-resolution scans or digital creation, enabling clear text readability and sharp image reproduction. Searchable text is a strong possibility for professionally created PDFs.

Print Quality:

Designed to be printable for workshop use, with clear diagrams and legible text.

Binding:

Not applicable for PDF download; however, if printed, would typically be spiral-bound or saddle-stitched for lay-flat usability.

Paper Type:

Not applicable for PDF download; however, original manuals often used durable, coated paper stock.

⚙️ Engine Specifications

Type:

Four-stroke, two-cylinder, boxer engine

Displacement:

1130 cc (1130cc)

Bore X Stroke:

98 mm x 74.5 mm

Valvetrain:

4 valves per cylinder, OHC (Overhead Camshaft), actuated by pushrods and rocker arms.

Horsepower Peak:

~85-90 hp (approx. 63-67 kW) at ~6750 rpm

Torque Peak:

~98-100 Nm (approx. 72-74 lb-ft) at ~5250 rpm

Injection Type:

Bosch Motronic MA 2.4 fuel injection with electronic ignition

Fuel Type:

Unleaded gasoline, minimum 95 RON (Research Octane Number)

Cooling Method:

Air-cooled with oil cooler

ECU Type:

Bosch Motronic MA 2.4

🔧 Transmission

Type:

6-speed, constant mesh gearbox

Clutch Type:

Single dry plate, diaphragm spring clutch (actuated by hydraulic cable)

Transmission Options:

N/A for 2000 model year.

Final Drive:

Shaft drive to rear wheel

Gear Ratios:

Specific gear ratios are detailed in the manual for each gear.

Gearbox Oil Type:

SAE 75W/90 API GL-5 gear oil

Final Drive Oil Type:

SAE 80W/90 API GL-5 gear oil

Gearbox Oil Capacity:

~0.9 liters (approx. 0.95 US quarts)

Final Drive Oil Capacity:

~0.25 liters (approx. 0.26 US quarts)

📐 Dimensions

Wheelbase Gs:

~1488 mm (58.6 inches)

Wheelbase R:

~1472 mm (57.9 inches)

Seat Height Gs Unladen:

~840 mm (33.1 inches)

Seat Height R Unladen:

~800 mm (31.5 inches)

Dry Weight Gs:

~232 kg (511 lbs)

Dry Weight R:

~215 kg (474 lbs)

Gross Vehicle Weight Rating:

Detailed in manual based on specific model variant.

Fuel Tank Capacity Gs:

25 liters (6.6 US gallons), including 4-liter reserve.

Fuel Tank Capacity R:

20 liters (5.3 US gallons), including 3-liter reserve.

🛡️ Safety Features

Crash Test Information:

Motorcycles of this era did not typically undergo standardized crash testing like automobiles. Safety is primarily addressed through design and component integrity.

ABS System:

Optional BMW Motorrad Integral ABS (Anti-lock Braking System) was available and is covered in detail.

Braking System:

Dual disc front brakes with 4-piston calipers (R 1150 GS typically has larger discs than R), single disc rear brake. Specific diameter and specifications found in manual.

Frame Construction:

Trellis frame (steel tubing) offering excellent rigidity and rider feedback.

Lighting:

Halogen headlight, clear lens turn signals, LED taillight (typical configuration).

💡 Technology Features

Audio System:

N/A (No factory-integrated infotainment system; aftermarket options exist).

ABS:

Optional BMW Motorrad Integral ABS system.

Traction Control:

N/A for the 2000 model year.

Smartphone Integration:

N/A (No factory connectivity features).

Gauge Cluster:

Analog speedometer and tachometer, LCD display for odometer, trip meters, clock, fuel level, gear indicator (on some models/updates), warning lights.

🔧 Maintenance

Oil Change Interval:

Typically every 10,000 km (6,000 miles) or annually, whichever comes first. Check manual for exact intervals.

Spark Plug Replacement Interval:

Check manual; typically around 20,000-30,000 km (12,000-18,000 miles).

Valve Clearance Check Interval:

Typically every 20,000 km (12,000 miles). Critical for boxer engines.

Engine Oil Type:

SAE 15W/50 or 20W/50 API SG or higher motorcycle-specific engine oil.

Brake Fluid Type:

DOT 4 brake fluid.

Coolant Type:

N/A (Air-cooled engine with oil circulation).

Engine Oil Capacity:

~4.0 liters (4.2 US quarts) with filter change.

Common Wear Items:

Clutch wear, fuel pump issues (especially with ethanol fuels), alternator brushes, paralever boot wear, input shaft spline lubrication, starter motor solenoid.

Diagnostic Challenges:

Intermittent electrical gremlins, fuel injection mapping sensitivity, ABS sensor issues.

Input Shaft Spline Lubrication:

Crucial periodic lubrication to prevent wear and seizing. Covered in detail in the manual.

Telelever Pivot Bearings:

Inspection and lubrication as per service schedule.

📚 Vehicle History

Bmw Motorcycle Legacy:

BMW has a long history of producing innovative and durable motorcycles, particularly known for its boxer engines and pioneering adventure bikes.

Predecessors:

R 1100 R and R 1100 GS models.

Successors:

R 1150 R Rockster, R 1200 GS, R 1200 R.

Manufacturing Location:

Berlin, Germany (BMW Motorrad plant).

Production Years For Platform:

The R 1150 platform was produced from 1999 to 2006.

🏆 Awards & Recognition

Motorcycle Of The Year:

While specific 'Motorcycle of the Year' awards for this exact model year are not readily documented, the R 1150 GS series was highly acclaimed and considered a benchmark in the adventure touring segment for its era.

Performance Reviews:

Consistently praised by motorcycle publications for its versatility, comfort, and robust engineering.

Emissions Standards:

Compliant with European emissions standards for motorcycles of the period (e.g., Euro 1).
