Vehicle Type:
Compact MPV (Multi-Purpose Vehicle)
Target Audience:
Families, individuals seeking versatile and practical transportation.
Key Competitors:
Citroรซn Evasion, Peugeot 806, Fiat Ulysse (as part of the Eurovan platform).
Platform Sharing:
Based on the Sevel Nord platform, shared with other PSA Group and Fiat vehicles.
Design Philosophy:
Emphasis on practicality, spacious interior, modular seating, and comfortable ride.
Main Coverage:
Complete vehicle service and repair
Specific Systems:
Engine, Transmission, Drivetrain, Suspension, Brakes, Electrical, Body, HVAC, Fuel System, Cooling System, Exhaust System, Steering, Interior, Exterior components.
Estimated Pages:
Likely over 1000 pages (typical for comprehensive workshop manuals)
Type:
Workshop Service Repair Manual
Engine Mechanical:
Detailed engine disassembly, assembly, overhaul procedures, component identification, specifications, torque values, timing belt replacement, cylinder head, pistons, crankshaft, camshafts.
Engine Management:
Fuel injection system, ignition system, emission control systems, diagnostic trouble codes (DTCs), sensor testing, ECU troubleshooting.
Transmission:
Manual transmission service, clutch replacement, gearbox overhaul, fluid types and capacities, shift linkage adjustment.
Brakes:
Front and rear brake system service, hydraulic components, brake fluid specifications, bleeding procedures, parking brake adjustment, ABS system troubleshooting.
Suspension And Steering:
Front and rear suspension overhaul, shock absorbers, springs, control arms, steering rack service, power steering system, wheel alignment specifications.
Electrical System:
Wiring diagrams for all systems, component location, fuse and relay identification, battery service, starter motor, alternator, lighting systems, power windows, central locking.
Body And Chassis:
Body panel removal and installation, door mechanisms, bumper service, glass replacement, chassis lubrication, corrosion protection.
Heating Ventilation And Air Conditioning HVAC:
HVAC system components, refrigerant types and capacities, blower motor, heater core, evaporator, diagnostic and repair procedures.
Interior Appointments:
Seat removal and installation, dashboard components, trim panel replacement, audio system service, instrument cluster.
Maintenance:
Scheduled maintenance, oil changes, filter replacements, fluid level checks, spark plug replacement, belt inspections.
Troubleshooting:
System diagnostic procedures, fault finding, common problems and solutions, symptom-based troubleshooting charts.
Repair And Overhaul:
Step-by-step instructions for component disassembly, repair, reassembly, and replacement of all major vehicle systems.
Diagnostics:
On-board diagnostics (OBD-II) information, diagnostic tool usage, sensor readings, actuator testing.
Depth:
Comprehensive, from basic maintenance to complex engine and transmission rebuilds, electrical diagnostics, and bodywork.
โ๏ธ Engine Specifications
Engine Code:
Likely ES9 J4 or similar variant of the Peugeot EW10 engine family
Engine Type:
Inline 4-cylinder, naturally aspirated
Displacement:
2.2 Liters (2179 cc)
Valvetrain:
DOHC, 16 valves
Horsepower:
Approximately 136-138 hp (depending on exact tuning)
Torque:
Approximately 200-210 Nm (depending on exact tuning)
Injection Type:
Multi-point fuel injection (MPI)
Fuel Type:
Unleaded gasoline
Euro Ncap Rating:
Euro NCAP crash test results for the Zeta (and its platform siblings) generally showed moderate to good protection for its era, likely achieving 3 or 4 stars depending on equipment.
ABS:
Anti-lock Braking System (ABS) standard on most trims.
Esp Or Asr:
Electronic Stability Programme (ESP) or Anti-Slip Regulation (ASR) may have been optional on higher trims.
Airbags:
Front airbags for driver and front passenger, side airbags may have been optional.
Seat Belts:
Three-point inertia-reel seat belts for all seating positions, pre-tensioners for front seats.
Audio System:
Factory fitted radio/cassette or CD player, often with auxiliary inputs. Speaker configurations vary by trim level.
Cruise Control:
Available as an option on higher trim levels.
Remote Central Locking:
Standard on most models, with key fob operation.
Instrument Cluster:
Includes speedometer, tachometer, fuel gauge, coolant temperature gauge, and various warning lights. Some models may feature a multi-function display.
Oil Change Interval:
Typically 15,000 km or 1 year, whichever comes first (consult manual for exact specification).
Timing Belt Replacement:
Critical interval, usually around 90,000-120,000 km or 5-7 years (consult manual for exact specification).
Engine Oil:
API SJ/SL or ACEA A3/B3/B4, viscosity typically 10W-40 or 5W-40 (consult manual for specific grade).
Coolant:
Ethylene glycol based antifreeze, typically OAT or HOAT formulation. Capacity approximately 7-8 liters (consult manual).
Brake Fluid:
DOT 4 specification (consult manual for any specific updates).
Transmission Fluid:
For manual transmission: API GL-4, SAE 75W-80 or 75W-90. For automatic transmission (if applicable): ATF Dexron III or equivalent (consult manual).
Common Wear Items:
Suspension components (bushings, ball joints), exhaust system wear, occasional electronic sensor faults, clutch wear.
Engine Specific Considerations:
Timing belt integrity is paramount; ensure timely replacement. Valve cover gasket leaks can occur. Check for oil consumption on higher mileage examples.
Brand Focus:
Lancia is known for its distinctive Italian design, innovative engineering, and often luxurious interiors.
Platform Development:
The Lancia Zeta was part of the Eurovan project, a collaboration between Fiat, PSA Peugeot Citroรซn, and Lancia, aimed at developing a shared platform for large MPVs.
Production Period:
1994-2004 (for the Eurovan project vehicles, including the Zeta).
Manufacturing Location:
Sevel Nord plant in Hordain, France.
