Mitsubishi Outlander 2003-2006 Factory Service Repair Manual

Regular price: $16.99
Sale price: $16.99
Regular price
Unit price: per

This manual covers the Outlander, a compact crossover SUV produced from the 2003 to 2006 model years. Built on the CU chassis, shared with the Airtrek, this first-generation Outlander was...

26 people are viewing this right now

Type: Car

Vendor:

Sku: 60385

Tags: 2003 2004 2005 2006 Car Cars Mitsubishi Outlander

Product variants

Description

This manual covers the Outlander, a compact crossover SUV produced from the 2003 to 2006 model years. Built on the CU chassis, shared with the Airtrek, this first-generation Outlander was designed as a practical, family-friendly vehicle offering car-like handling and the option of all-wheel drive. Available with either a 2.4-liter four-cylinder engine or an optional 3.0-liter V6, it provided a balance of efficiency and capability, competing with popular models like the Honda CR-V and Toyota RAV4. Its engineering emphasizes robust construction and reliable performance, reflecting a heritage of durable vehicles. This comprehensive factory service repair manual provides detailed information for all styles and trims of the Outlander from 2003-2006. It serves as an essential resource for owners, technicians, and mechanics, covering a wide array of systems including powertrain components, chassis systems, and electrical systems. Within its hundreds of pages, you will find step-by-step repair and rebuild procedures, maintenance schedules, troubleshooting guides, and technical specifications. The manual is presented in English and is fully printable, ensuring accessibility for all diagnostic, maintenance, and repair needs.

🏷️ Basic Information

Identification

Make:

Mitsubishi

Model:

Outlander

Generation:

First Generation

Model Years Covered:

2003-2006

Codes

Platform Code:

CU chassis (shared with Mitsubishi Airtrek/Warrior)

👋 Introduction

Market Position

Vehicle Segment:

Compact Crossover SUV

Competitive Analysis

Key Competitors 2003-2006:

Honda CR-V, Toyota RAV4, Ford Escape, Nissan Xterra, Subaru Forester

Key Features

Vehicle Proposition:

Practicality, available all-wheel drive, family-friendly SUV with car-like handling

📋 Manual Details

Coverage Areas

Manual Coverage Scope:

All styles and trims for the specified model years

Page Count

Estimated Page Count:

Hundreds of pages (specific count not provided, but described as comprehensive)

Manual Type

Manual Type:

Factory Service Repair Manual

Language

Language:

English

Format

Digital Format:

PDF Download

📖 Manual Coverage

Systems Covered

Powertrain Systems:

Engine service/repair, Transmission service/repair, Fuel Injection/Fuel System, Emission System, Cooling System, Engine Control System

Chassis Systems:

Brake System, Suspension, Steering, Differential/Drive, Axle, Chassis/Body

Electrical Systems:

Electrical System, Wiring Diagram, Restraint System (Airbag, Seatbelts)

Comfort And Convenience:

Heater/Air Conditioning, Interior

Procedures Included

Repair Procedures:

Step-by-step repair procedures, rebuild procedures, refurbishment, restoration

Maintenance Procedures:

General Maintenance, Periodic Lubrication

Diagnostic Procedures:

Troubleshooting guide, diagnosing and correcting problems

Technical Depth

Technical Depth:

Complete official factory information, suitable for professional technicians and owners alike

📊 Manual Specifications

File Format

File Format:

Print Quality

Printability:

Fully printable (entire manual or selected pages)

Binding Type

Binding Type:

Digital download, printable for manual binding

Paper Type

Paper Type:

N/A (Digital)

Software Requirements

Software Requirements:

Adobe PDF Reader

⚙️ Engine Specifications

Primary Engine

Engine Type 2003-2004:

2.4L 4-cylinder (4G64)

Engine Type 2005-2006:

2.4L 4-cylinder (4G69 'MIVEC')

Engine Type Optional:

3.0L V6 (6G72) - found in some markets and trims

Performance

Horsepower 2.4L:

Approx. 148-160 hp (depending on year and MIVEC inclusion)

Torque 2.4L:

Approx. 150-162 lb-ft

Horsepower 3.0L V6:

Approx. 200-205 hp

Torque 3.0L V6:

Approx. 215-220 lb-ft

Fuel System

Fuel System Type:

Multi-point Fuel Injection (MPI)

Recommended Fuel:

87 Octane Unleaded Gasoline

🔧 Transmission

Standard

Transmission Type 2.4L:

5-speed Manual

Optional

Transmission Type Optional:

4-speed Automatic (INVECS-II)

Transmission Type V6:

4-speed Automatic (INVECS-II)

Features

Drive System:

Front-Wheel Drive (FWD) or All-Wheel Drive (AWD) with Sportronic Shifting (on automatics)

📐 Dimensions

Exterior

Length:

Approx. 179.7 inches

Width:

Approx. 70.1 inches

Height:

Approx. 65.6 inches

Wheelbase:

Approx. 103.3 inches

Weights

Curb Weight Typical:

Approx. 3,400 - 3,700 lbs (depending on drivetrain and engine)

🛡️ Safety Features

Ratings

NHTSA Front Crash Test Rating:

Generally good for its era, consult NHTSA records for specifics. Typically 4-star or 5-star.

Active Features

Active Safety Features Available:

Anti-lock Braking System (ABS), Electronic Brake-force Distribution (EBD), Traction Control System (TCS), Active Stability Control (ASC) on some trims

Passive Features

Passive Safety Features:

Front airbags, front side-impact airbags, three-point seatbelts with pretensioners, LATCH child seat anchor system

💡 Technology Features

Infotainment

Infotainment System Typical:

AM/FM/CD player with optional premium audio system, 6-disc CD changer (optional)

Driver Assistance

Driver Assistance Features Available:

Cruise control, fog lights

Connectivity

Connectivity Options Typical:

Auxiliary input for audio (later models/trims), power outlets

🔧 Maintenance

Service Intervals

Oil Change Interval:

Every 3,750 miles or 3 months (severe service) / 7,500 miles or 6 months (normal service) - consult owner's manual for specific recommendations.

Engine Air Filter Replacement:

Every 30,000 miles

Cabin Air Filter Replacement:

Every 15,000 miles or annually

Spark Plug Replacement 2.4L:

Approx. 100,000 miles (iridium-tipped)

Transmission Fluid Change:

Every 45,000 - 60,000 miles (automatic and manual)

Fluid Specifications

Engine Oil Spec 2.4L:

SAE 5W-30 (API SJ or higher)

Engine Oil Spec V6:

SAE 5W-30 or 5W-40 (API SJ or higher)

Coolant Type:

Mitsubishi DiaQueen Super Long Life Coolant (or equivalent P-HOAT coolant)

Automatic Transmission Fluid:

DIA QUEEN ATF-J2 or equivalent SP-III

Brake Fluid Spec:

DOT 3 or DOT 4

Known Issues

Common Problems 2.4L Engine:

Occasional oil consumption, timing belt inspection (if applicable to specific year/engine configuration - check manual for timing chain vs belt), intake manifold leaks

Common Problems Transmission:

Hesitation in automatic transmissions, occasional clutch wear in manual transmissions

Common Problems Suspension:

Wear in sway bar links, worn control arm bushings, early strut failure

Common Problems Electrical:

Window regulator failures, HVAC blower motor issues, intermittent dashboard warning lights

📚 Vehicle History

Brand Heritage

Mitsubishi Brand Focus:

Known for robust engineering, rally heritage, and distinctive styling (e.g., Lancer Evolution)

Model Evolution

First Generation Introduction:

Introduced in 2001 (as Mitsubishi Airtrek in Japan), launched as Outlander in North America for the 2003 model year.

Design Inspiration:

Based on the Mitsubishi ASX concept, designed as a compact SUV with coupe-like styling elements.

Production

Manufacturing Location:

Japan (Okazaki Plant)

🏆 Awards & Recognition

Recognitions

Industry Awards:

Not widely recognized with major individual awards during this specific period, but generally considered a competent and practical choice in its segment.
