Dodge Ram SRT-10 2004 2005 2006 Service Repair Manual SRT10
- Regular price
- $17.99
- Sale price
- $17.99
- Regular price
-
- Unit price
- / per
🏷️ Basic Information Identification Make: Dodge Model: Ram SRT-10 Generation: Second Generation (DR/DH/D2) Model Years Covered: 2004, 2005, 2006 Codes Chassis Code: DR/DH/D2 Engine Codes Mentioned: SRT10 (referring to the...
26 people are viewing this right now
Type: Truck
Vendor:
Sku: 576905
Couldn't load pickup availability
Share
🏷️ Basic Information
Identification
Make:
Dodge
Model:
Ram SRT-10
Generation:
Second Generation (DR/DH/D2)
Model Years Covered:
2004, 2005, 2006
Codes
Chassis Code:
DR/DH/D2
Engine Codes Mentioned:
SRT10 (referring to the performance variant)
👋 Introduction
Market Position
Market Segment:
High-performance pickup truck, aimed at enthusiasts seeking significant power and aggressive styling.
Competitive Analysis
Competitors:
Ford SVT F-150 Lightning, Chevrolet Silverado SS.
Key Features
Unique Selling Proposition:
The Ram SRT-10 is distinguished by its massive 8.3L V10 engine, derived from the Viper supercar, delivering supercar-level performance in a pickup truck format.
Performance Focus:
Engineered by Chrysler's Performance Vehicle Operations (PVO), it emphasizes extreme power, specialized suspension, and braking.
Manual Value Proposition
Target Audience:
Owners, DIY enthusiasts, and professional mechanics working on the Dodge Ram SRT-10.
📋 Manual Details
Coverage Areas
Systems Covered:
• Lubrication and Maintenance
• Suspension
• Differential & Driveline
• Vehicle Quick Reference
• Brakes
• Clutch
• Cooling
• Audio / Video
• Chime / Buzzer
• Electronic Control Modules
• Engine Systems
• Heated Systems
• Horn
• Ignition Control
• Instrument Cluster
• Lamps
• Message Systems
• Power Systems
• Restraints
• Speed Control
• Vehicle Theft Security
• Wipers / Washers
• Navigation/Telecommunication
• Wiring
• Engine
• Exhaust System
• Frame and Bumpers
• Fuel System
• Steering
• Transmission and Transfer Case
• Tires / Wheels
• Body
• Heating and Air Conditioning
• Emissions Control
• Component and System Index
• DTC Index
• Service Manual Comment Forms
Page Count
Page Count:
9267
Manual Type
Manual Type:
Service and Repair Manual
Language
Language:
English
Format
Format:
PDF
📖 Manual Coverage
Systems Covered
Engine Management Systems:
Detailed coverage of engine control modules (ECM), ignition control, fuel system, and emissions control systems for all listed engine variants.
Drivetrain Components:
Comprehensive information on differential and driveline components, clutch system, transmission (including specific types for SRT-10), and transfer case.
Chassis And Suspension:
In-depth coverage of suspension components, steering systems, brakes, wheels, and tires, with specific attention to the performance-oriented suspension of the SRT-10.
Body And Interior:
Detailed sections on body construction, frame, bumpers, doors, glass, and interior trim, including HVAC, audio/video, and restraint systems.
Electrical And Electronics:
Extensive wiring diagrams, coverage of instrument cluster, lamps, power systems, horn, chime/buzzer, message systems, speed control, and vehicle theft security.
Procedures Included
Diagnostic Procedures:
Includes DTC (Diagnostic Trouble Code) index and detailed troubleshooting procedures for various systems and components.
Maintenance Procedures:
Comprehensive lubrication and maintenance schedules, fluid type specifications, and step-by-step guides for routine servicing.
Repair Procedures:
Detailed, step-by-step repair instructions for all major vehicle systems, supported by illustrations, photos, and diagrams.
Component Replacement And Rebuild:
Instructions for removal, installation, and rebuilding of various components, from engine parts to interior modules.
Wiring And Electrical Troubleshooting:
Detailed wiring diagrams and guidance for diagnosing and repairing electrical faults.
Technical Depth
Depth Of Information:
Highly detailed, suitable for professional workshop use, covering everything from basic maintenance to complex diagnostics and major repairs.
Illustrations And Diagrams:
Extensive use of illustrations, photos, and diagrams to clarify procedures and component identification.
Service Bulletins And Technical Notes:
While not explicitly stated, the comprehensive nature suggests inclusion of manufacturer-specific technical notes and potentially referenced service bulletins.
📊 Manual Specifications
File Format
File Format:
PDF (Portable Document Format)
Digital Compatibility:
Compatible with all Windows and Mac computers (including Windows 10, 8, 7, Vista, XP, ME, 98, NT, 2000), tablets, and phones. Supports 32 and 64-bit operating systems.
Print Quality
Printability:
Pages can be printed, allowing for physical reference. The PDF format generally supports high-resolution output for clarity.
Binding Type
Binding Type:
Digital (PDF) - no physical binding
Paper Type
Paper Type:
Digital - N/A (not a physical print product)
⚙️ Engine Specifications
Primary Engine
Engine Variant:
8.3L (505 CID) V10 Viper Engine
Performance
Horsepower:
500 hp @ 5600 rpm (for the 8.3L V10)
Torque:
525 lb-ft @ 4200 rpm (for the 8.3L V10)
Fuel System
Fuel Delivery:
Multi-port Fuel Injection (MPI)
Other Engines Mentioned
Standard Ram Engines:
• 3.7L Magnum V6
• 4.7L Magnum V8
• 5.7L HEMI V8
• 5.9L Cummins Turbo Diesel (available in some Ram models, though less common in SRT-10 context)
Engine Construction
Block Material:
Aluminum alloy (Viper V10)
Head Material:
Aluminum alloy (Viper V10)
🔧 Transmission
Standard
Transmission Type Srt10:
Tremec T-56 6-Speed Manual Transmission (specific to SRT-10)
Optional
Transmission Type Other Ram:
Automatic transmissions (e.g., 4-speed 45RFE, 5-speed 545RFE) were available on other Ram models, but the SRT-10 exclusively featured the manual.
Features
Clutch Type:
Heavy-duty single dry plate clutch (specific to SRT-10)
Driveshaft And Axles:
Performance-oriented driveshaft and axle components designed to handle the V10's torque.
📐 Dimensions
Exterior
Body Style:
Regular Cab (most common for SRT-10), Quad Cab (available later)
Wheelbase Regular Cab:
Approx. 133.0 inches
Wheelbase Quad Cab:
Approx. 140.5 inches
Weights
Curb Weight Approx:
Around 5,000 - 5,300 lbs (depending on configuration)
Towing Capacity:
Limited for SRT-10 due to performance focus, typically around 2,000-4,000 lbs. Standard Ram trucks had higher capacities.
Payload Capacity:
Lower than standard Ram trucks, typically around 1,000 - 1,500 lbs.
🛡️ Safety Features
Ratings
NHTSA Ratings General Ram:
Previous generations of Ram trucks received varying NHTSA ratings. Specific SRT-10 ratings may differ due to performance modifications.
Active Features
Braking System:
Upgraded braking system, often featuring larger rotors and calipers (e.g., Brembo front brakes on SRT-10).
Traction Control:
Traction control system (ASR) and Anti-lock Braking System (ABS) standard.
Passive Features
Airbags:
Front airbags, potentially side airbags depending on trim/options. Manual covers restraint systems.
Seatbelts:
Three-point seatbelts with pretensioners. Manual covers restraint systems.
💡 Technology Features
Infotainment
Audio System:
Factory-installed audio systems, potentially including CD players and premium speaker options. Manual covers Audio/Video systems.
Driver Assistance
Cruise Control:
Speed Control is explicitly covered in the manual, indicating standard cruise control functionality.
Connectivity
Navigation Telecommunication:
Manual covers Navigation/Telecommunication systems, suggesting the availability of these features on some models.
🔧 Maintenance
Service Intervals
Oil Change Interval:
Typically every 3,000-7,500 miles or 6 months, depending on driving conditions and oil type used (refer to manual for specific V10 recommendations).
Tire Rotation:
Recommended every 5,000 - 7,500 miles.
Brake Inspection:
Regular inspections recommended, especially given the performance nature of the SRT-10.
Fluid Specifications
Engine Oil Type:
Specific viscosity grade and API service classification for the 8.3L V10 is critical (likely a high-performance synthetic oil, consult manual).
Coolant Type:
Mopar OAT (Organic Additive Technology) coolant or equivalent specified for V10 engines.
Transmission Fluid:
Specific manual transmission fluid (MTF) or gear oil as per manual for the Tremec T-56.
Differential Fluid:
Specific gear oil for the rear differential, often with limited-slip additive if equipped.
Known Issues
Clutch Wear:
Due to the V10's torque and performance driving, clutch wear can be accelerated.
Suspension Components:
Aggressive tuning can lead to faster wear on certain suspension bushings or dampers under heavy use.
Electrical Gremlins:
As with many performance vehicles of this era, electrical systems can sometimes be complex and prone to minor issues if not maintained properly.
📚 Vehicle History
Brand Heritage
Dodge Performance Legacy:
Dodge has a long history of performance vehicles, notably the Viper sports car, which directly influenced the SRT-10's powertrain.
Model Evolution
Srt Brand Introduction:
SRT (Street and Racing Technology) was a performance division of Chrysler, responsible for creating high-performance versions of existing models like the Ram.
Production
Srt10 Production Years:
2004-2006
Manufacturing Location:
Dodge Ram trucks were primarily manufactured in North America, with specific assembly plants for performance variants.
🏆 Awards & Recognition
Recognitions
Performance Accolades:
The Dodge Ram SRT-10 was widely recognized for its groundbreaking performance as a production pickup truck, often lauded for its immense power and V10 engine.
Ratings
Automotive Journalism Reviews:
Received numerous positive reviews from automotive publications for its performance capabilities, though often critiqued for its firm ride and practicality limitations compared to standard trucks.
