🏷️ Basic Information

Make:

Pontiac

Model:

Aztek

Year:

2004

Body Style:

Mid-size Crossover SUV / Minivan

Segment:

Mid-size Crossover SUV

Platform:

GM U-body

👋 Introduction

Positioning:

Targeted at DIY mechanics and owners seeking to perform their own repairs and maintenance.

Value Proposition:

Provides dealership-level technical information to empower vehicle owners, reducing reliance on professional mechanics and saving costs.

Advantage Over Generic:

Strictly vehicle-specific, unlike generic repair guides, ensuring accuracy for the 2004 Aztek.

Digital Vs Print:

Offers advantages over traditional print manuals by being searchable, allowing selective printing, and preventing physical damage.

Feature 1:

Factory-quality technical data and procedures.

Feature 2:

Comprehensive system coverage from basic maintenance to advanced diagnostics.

Feature 3:

Printable pages for convenient workshop use.

Feature 4:

Integrated diagrams, illustrations, and wiring schematics.

📋 Manual Details

Primary Coverage:

All 2004 Pontiac Aztek models and trim levels

Repair Scope:

A-Z, covering maintenance, diagnostics, and complete repairs

Estimated Pages:

Comprehensive (specific count not provided, but described as 'complete' and 'everything you will ever need')

Type:

Service and Repair Manual

Origin:

Factory-equivalent, used by dealership technicians

Language:

English

Format:

Digital (PDF)

Compatibility:

Windows (Vista 32/64, XP, ME, 98, NT, 2000) and Mac

📖 Manual Coverage

Powertrain:

Engine, Control System, Fuel Service Specifications, Emission Control, Intake Exhaust Cooling, Lube, Ignition Starting Charging, Auto Transmission, Manual Transmission, Transfer Propeller Shaft, Drive Shaft, Differential, Axle

Chassis:

Suspension, Tire & Wheel, Brake Control, Brake, Parking Brake, Steering Column, Power Steering

Body And Interior:

Air Condition, Suppl Restraint System, Seat Belt, Engine Immobilizer, Cruise Control, Wiper & Washer, Door Lock, Meter Audio/Visual, Horn, Windshield/Glass Mirror, Instrument Panel, Seat, Engine Hood/Door, Exterior & Interior

Electrical And Electronics:

Electrical, Multiplex/CAN Communication

Diagnostic Procedures:

Diagnostic trouble code (DTC) retrieval, troubleshooting flowcharts, symptom-based diagnostics

Maintenance Procedures:

Scheduled maintenance, fluid changes, filter replacements, lubrication

Repair Procedures:

Component removal and installation, adjustments, calibration, seal replacement, overhaul procedures

Wiring And Schematics:

Complete wiring diagrams, electrical component locations, circuit descriptions

Depth:

Vehicle-specific, detailed, step-by-step instructions

Visual Aids:

Diagrams, illustrations, blow-up images

Data Types:

Specifications, torque values, clearances, fluid types and capacities

📊 Manual Specifications

File Format:

PDF

File Size:

Typically large for comprehensive manuals; download speed noted

Printability:

All pages printable

Image Scaling:

Images can be blown up and printed enlarged

Binding:

Digital (no physical binding)

Paper Type:

N/A (digital format)

PDF Reader:

Adobe PDF Reader (free online)

Unzipping Tool:

Winzip (free online)

⚙️ Engine Specifications

Engine Type:

3.4L V6 (LA3)

Displacement:

3.4 Liters (3350 cc)

Configuration:

Overhead Valve (OHV), 60-degree V6

Bore X Stroke:

3.50 in x 3.54 in (88.9 mm x 89.9 mm)

Compression Ratio:

9.4:1

Horsepower:

185 hp @ 5200 rpm (approximate)

Torque:

210 lb-ft @ 4000 rpm (approximate)

Fuel Delivery:

Sequential Electronic Fuel Injection (SEFI)

Fuel Type:

Unleaded Regular (87 octane)

Coolant Capacity:

12.1 quarts (11.5 liters) with heater (V6)

Oil Capacity:

4.5 quarts (4.3 liters) with filter change (V6)

Recommended Oil Viscosity:

SAE 5W-30

Emissions System:

Catalytic converter, EGR, PCV, Onboard diagnostics (OBD-II)

🔧 Transmission

Transmission Type:

4-speed automatic overdrive (4T65-E)

Transmission Type:

N/A (Only automatic offered)

Drive Type:

Front-Wheel Drive (FWD) standard, All-Wheel Drive (AWD) optional

Automatic Transmission Fluid:

Dexron III (or equivalent specification, e.g., Dexron VI)

Transmission Fluid Capacity:

Approximately 9.5 quarts (9.0 liters) for initial fill (4T65-E)

📐 Dimensions

Length:

182.5 inches (4635 mm)

Width:

73.4 inches (1864 mm)

Height:

66.1 inches (1679 mm)

Wheelbase:

104.4 inches (2652 mm)

Front Track:

62.4 inches (1585 mm)

Rear Track:

62.0 inches (1575 mm)

Curb Weight FWD:

Approximately 3,784 lbs (1716 kg)

Curb Weight AWD:

Approximately 3,988 lbs (1809 kg)

Gross Vehicle Weight Rating:

Approximately 5,032 lbs (2282 kg) for FWD

Cargo Volume Behind 1St Row:

Approximately 94.0 cubic feet (2662 liters)

Cargo Volume Behind 2Nd Row:

Approximately 20.0 cubic feet (566 liters)

Standard Tire Size:

P215/65R16

Optional Tire Size:

P215/60R17

Wheel Bolt Pattern:

5 x 115 mm

Lug Nut Torque:

100 lb-ft (135 Nm)

🛡️ Safety Features

NHTSA Front Crash Test:

4-star driver, 4-star passenger (2004 model year specific ratings may vary slightly)

IIHS Side Impact Test:

Good (for models equipped with side airbags)

Braking System:

4-wheel Anti-lock Braking System (ABS)

Traction Control:

Available Traction Control System (TCS)

Airbags:

Frontal airbags (driver and passenger), Available front side-impact airbags

Seatbelts:

3-point front and rear seatbelts, Pretensioners, Load limiters

Child Safety:

LATCH (Lower Anchors and Tethers for CHildren) system

💡 Technology Features

Audio System:

Standard AM/FM stereo with CD player, optional premium audio system with amplifier and subwoofer, optional rear-seat entertainment system.

Climate Control:

Manual climate control standard, optional automatic climate control.

Cruise Control:

Standard cruise control.

Parking Assist:

Optional rear parking assist sensors.

Connectivity Features:

Limited in 2004; primarily focused on audio input. OnStar telematics system was available.

🔧 Maintenance

Oil And Filter Change:

Every 7,500 miles (12,000 km) or 6 months, whichever comes first (under normal driving conditions). Refer to manual for severe conditions.

Engine Air Filter Replacement:

Every 30,000 miles (48,000 km) or as needed based on inspection.

Cabin Air Filter Replacement:

Every 15,000 miles (24,000 km) or annually.

Transmission Fluid Change:

Every 100,000 miles (160,000 km) or every 5 years, whichever comes first. Inspect fluid condition periodically.

Spark Plug Replacement:

Every 100,000 miles (160,000 km) (using recommended iridium or platinum plugs).

Engine Coolant:

GM P/N 12346290 (or equivalent Dex-Cool orange coolant), mixture of 50/50 with distilled water.

Brake Fluid:

DOT 3

Power Steering Fluid:

GM P/N 1050339 (or equivalent Dexron III/VI ATF)

Common Issue 1:

Cracked dashboard (due to material expansion/contraction), often addressed with UV protectants or replacement.

Common Issue 2:

Transmission issues, particularly with the 4T65-E, which can include rough shifting or failure to engage gears if not maintained.

Common Issue 3:

Water pump leaks or bearing failure, common on the 3.4L V6 engine.

Common Issue 4:

Evaporative Emission Control (EVAP) system leaks, often leading to check engine lights.

📚 Vehicle History

Pontiac Legacy:

Pontiac was a performance-oriented division of General Motors, known for models like the Firebird, GTO, and Grand Prix. The Aztek represented a departure towards the crossover segment.

Aztek Introduction:

The Pontiac Aztek was introduced for the 2001 model year and produced until 2005. It was designed to be a versatile 'activity vehicle'.

2004 Updates:

For the 2004 model year, the Aztek received minor updates, often including revised option packages and trim level adjustments. The core mechanicals remained largely consistent with previous years.

Assembly Location:

Ramos Arizpe, Coahuila, Mexico

Production Years:

2001-2005

🏆 Awards & Recognition

Controversial Design:

While not a typical 'award', the Aztek is widely recognized and often cited for its distinctive and polarizing design, which was a significant talking point during its production.

Popular Culture Feature:

Gained pop culture fame through its appearance in the TV series 'Breaking Bad', where it was driven by the protagonist Walter White.
