Segment:
Mid-size Crossover/Wagon
Target Audience:
Families seeking a versatile and comfortable vehicle.
Competitors:
Chevrolet Equinox, Pontiac Torrent, Honda Pilot, Toyota Highlander, Nissan Murano.
Features:
Spacious interior, comfortable ride, available AWD, flexible seating. Unique for its time, blending SUV and wagon characteristics.
Powertrain:
Engine (3.0L Duratec V6), Transmission (CVT & 6-speed Automatic), Drivetrain (AWD/FWD)
Chassis:
Suspension (Front & Rear), Steering, Brakes (ABS, EBD), Wheels & Tires
Electrical:
Engine Control Module (ECM), Powertrain Control Module (PCM), Body Control Module (BCM), Lighting, Gauges & Instruments, Audio System, Climate Control, Power Accessories, Safety Systems (Airbags, Seatbelts)
Body:
Exterior Body Panels, Interior Trim, Doors, Windows, Seats, Glass
Maintenance:
Oil Change, Filter Replacement, Spark Plug Replacement, Coolant Flush, Brake Fluid Flush, Belt Inspection/Replacement, Wiper Blade Replacement
Diagnostics:
OBD-II Trouble Codes, Symptom-Based Diagnostics, Component Testing, Wiring Diagrams
Repair:
Engine Mechanical Repair, Transmission Overhaul, Suspension Component Replacement, Brake System Repair, Electrical Component Repair, Body Panel Repair
Troubleshooting:
Component-level troubleshooting, diagnostic flowcharts, common issue resolution
Depth:
Comprehensive: From routine maintenance to full engine and transmission rebuilds, including detailed electrical schematics and diagnostic procedures.
Engine Code:
3.0L Duratec 30 V6
Displacement:
2976 cc (181.6 cu in)
Bore X Stroke:
89.0 mm x 79.5 mm (3.50 in x 3.13 in)
Horsepower:
203 hp @ 6000 rpm (2005-2006), 205 hp @ 6000 rpm (2007)
Torque:
207 lb-ft @ 4500 rpm (2005-2006), 209 lb-ft @ 4500 rpm (2007)
Type:
Electronic Fuel Injection (EFI), Sequential Multi-Port Fuel Injection (MPI)
Fuel Type:
Regular Unleaded Gasoline (87 Octane)
Type:
Continuously Variable Transmission (CVT) - ECVT
Type:
6-speed Automatic Transmission
AWD System:
All-Wheel Drive (AWD) optional, electronically controlled
Cvt Fluid:
Mercon V (or equivalent approved fluid)
Automatic Transmission Fluid:
Mercon V (or equivalent approved fluid)
Length:
192.4 in (4887 mm)
Height:
66.2 in (1681 mm)
Wheelbase:
112.9 in (2868 mm)
Passenger Volume:
112.9 cu ft (3197 L)
Seating Capacity:
5-7 (optional third row)
Cargo Volume Behind 2Nd Row:
40.0 cu ft (1133 L)
Cargo Volume Behind 3Rd Row:
12.6 cu ft (357 L) (with optional 3rd row)
Curb Weight:
3,930 lbs (1783 kg) (FWD), 4,100 lbs (1860 kg) (AWD)
Gross Vehicle Weight Rating Gvwr:
5,400 lbs (2450 kg)
Towing Capacity:
N/A (Not recommended for towing)
NHTSA Rollover Resistance:
4/5 stars (AWD models)
ABS:
Standard Anti-lock Braking System (ABS)
Ebd:
Electronic Brake-force Distribution (EBD)
Traction Control:
Available Traction Control System (TCS)
Airbags:
Front driver and passenger airbags, optional side curtain airbags.
Seatbelts:
3-point height-adjustable front seat belts with pretensioners, rear seat belts.
Oil Change Interval:
Every 5,000 miles (8,000 km) or 6 months, whichever comes first (under normal driving conditions).
Engine Coolant Change:
Every 100,000 miles (160,000 km) or 10 years, whichever comes first.
Spark Plug Replacement:
Every 100,000 miles (160,000 km) (long-life iridium plugs).
Transmission Fluid Change:
Refer to manual; often 'lifetime' for CVT, but fluid service recommended at 100,000 miles for automatic.
Engine Oil Capacity:
5.5 US quarts (5.2 L) with filter change (3.0L V6)
Engine Oil Type:
SAE 5W-20, API SN or equivalent
Coolant Type:
Ford Premium Engine Coolant (Orange), or equivalent.
Cvt Reliability:
CVT can be a point of concern; proper fluid maintenance is crucial.
Suspension Wear:
Premature wear of suspension components (struts, bushings) can occur.
Ignition Coils:
Coil-on-plug ignition systems can be prone to failure.
Manufacturer:
Ford Motor Company
Introduction:
Introduced for the 2005 model year, replacing the Ford Taurus wagon.
Platform Sharing:
Shared its platform with the Mazda 6, Ford Fusion, and Mercury Milan (CD3 platform).
Discontinuation:
Discontinued after the 2007 model year, replaced by the Ford Taurus X.
Manufacturing Location:
Oakville Assembly Plant, Ontario, Canada
