Vehicle Segment:
Compact SUV
Target Audience:
DIY mechanics, enthusiast owners, professional repair shops
Key Competitors:
Honda CR-V, Toyota RAV4, Ford Escape, Nissan X-Trail
Manual Value Proposition:
Enables owners to perform maintenance, diagnostics, and repairs, saving money on labor costs.
Manual Accuracy:
Represents factory-level service information for accuracy and completeness.
Primary Coverage:
Factory service and repair procedures
All Engines Included:
Yes
Estimated Page Count:
Varies by specific OEM manual; typically 2000+ pages for comprehensive coverage
Type:
Service Repair Workshop Manual
Compatibility:
All Versions of Windows & Mac
Reader Requirement:
Adobe PDF Reader
Extraction Requirement:
WinZip (or similar archive utility)
Download Type:
Instant Download
Printability:
All pages are printable
Major Systems:
Engine Mechanical, Engine Electrical, Emission Control, Fuel System, Clutch, Transaxle (Manual & Automatic), Transfer System, Driveshaft & Axle, Suspension, Steering, Restraint System, Brakes, Body (Interior & Exterior), Body Electrical, HVAC
Repair Procedures:
All repair procedures covered, step-by-step instructions
Diagnostic Procedures:
Diagnostic procedures included
Maintenance Procedures:
Maintenance and service procedures
Depth Of Information:
Factory level detail, equivalent to dealer/mechanic manuals
Visual Aids:
Highly detailed exploded pictures and diagrams
Engine 1 Displacement:
2.7L (2656 cc)
Engine 1 Configuration:
V6 (likely G6CU variant)
Engine 1 Fuel Delivery:
Electronic Fuel Injection (MPI)
Engine 1 Aspirated:
Naturally Aspirated
Engine 2 Displacement:
2.0L (1991 cc)
Engine 2 Configuration:
Inline 4-Cylinder
Engine 2 Fuel Delivery:
Common Rail Direct Injection (CRDI)
Engine 2 Aspirated:
Turbocharged (likely Variable Geometry Turbocharger - VGT)
2.7L V6 Horsepower Est:
Approximately 170-175 hp
2.7L V6 Torque Est:
Approximately 175-180 lb-ft
2.0L Diesel Horsepower Est:
Approximately 110-115 hp
2.0L Diesel Torque Est:
Approximately 190-200 lb-ft
Standard Transmission Type:
Manual (5-speed for 2.0L Diesel, potentially 6-speed for later models/engines)
Optional Transmission Type:
Automatic (4-speed for 2.7L V6, potentially 5-speed for later models/engines)
Drive Type:
Front-Wheel Drive (FWD) or All-Wheel Drive (AWD)
Length Est:
Approximately 176.5 inches
Width Est:
Approximately 71.3 inches
Height Est:
Approximately 65.5 inches
Wheelbase Est:
Approximately 103.1 inches
Curb Weight Est:
Approximately 3,500 - 3,900 lbs (depending on engine and drivetrain)
NHTSA Front Impact Driver Est:
5 Stars (for 2007 model year)
NHTSA Front Impact Passenger Est:
5 Stars (for 2007 model year)
IIHS Side Impact Rating Est:
Good (for 2007 model year)
Standard Safety Features:
Front airbags, front side-impact airbags, anti-lock braking system (ABS), electronic brakeforce distribution (EBD), brake assist (BA)
Optional Safety Features:
Traction Control System (TCS), Electronic Stability Control (ESC) - availability varies by trim and year
Infotainment System Features Est:
Base models likely had AM/FM radio with CD player, optional premium sound systems, and potentially MP3 capability on later iterations.
Driver Assistance Features:
Limited driver assistance technologies compared to modern vehicles. Primarily focused on ABS, EBD, and optional TCS/ESC.
Connectivity Options:
Auxiliary audio input jack on some models; Bluetooth hands-free connectivity was not widely standard in the early part of this generation.
Oil Change Interval:
Typically 5,000-7,500 miles or 6-12 months, depending on oil type and driving conditions (consult manual for specifics).
Engine Air Filter Replacement Interval:
Approximately 30,000 miles or as needed based on inspection.
Cabin Air Filter Replacement Interval:
Approximately 15,000-30,000 miles or annually.
Spark Plug Replacement Interval:
Gasoline: ~60,000-100,000 miles (depending on plug type), Diesel: Glow plugs inspected as needed.
Engine Oil Type 2.7L V6:
SAE 5W-30 (API SM or higher, ILSAC GF-4 or higher)
Engine Oil Type 2.0L Diesel:
API CJ-4 or ACEA C3 (check manual for exact specification)
Coolant Type:
IAT (Inorganic Additive Technology) Long Life Antifreeze/Coolant (e.g., Hyundai/Kia Green Coolant)
Automatic Transmission Fluid Type:
SP-III (or equivalent ATF)
Manual Transmission Fluid Type:
Gear oil (API GL-4 or GL-5, check manual for viscosity)
Power Steering Fluid Type:
Automatic Transmission Fluid (ATF) SP-III or equivalent
Common Wear Items:
Brake pads/rotors, suspension components (bushings, ball joints, tie rod ends), exhaust system, catalytic converter (especially on higher mileage vehicles).
Engine Specific Concerns 2.7L V6:
Some reports of oil consumption, occasional camshaft position sensor issues.
Engine Specific Concerns 2.0L Diesel:
Potential for turbocharger issues if not maintained, DPF (Diesel Particulate Filter) regeneration problems if city driving is predominant.
Transmission Concerns:
Occasional issues with automatic transmission shifting or solenoids; manual clutch wear.
Electrical Concerns:
Window regulators, power lock actuators, and occasional body control module (BCM) issues are reported.
Kia Heritage:
Kia Motors Corporation, a South Korean manufacturer, has a history dating back to 1944, initially producing motorcycle parts and later expanding into automobiles.
Sportage First Generation:
Launched in 1993 as a compact SUV, built on a body-on-frame chassis.
Sportage Second Generation:
Introduced in 2004 (for model year 2005) as a complete redesign, adopting a unibody construction for improved ride comfort and handling. This generation (JE/KM) is covered by the manual.
Production Period For This Generation:
2004-2010 (model years 2005-2009 represent a significant portion of this generation's lifecycle)
Manufacturing Locations Est:
South Korea (primarily), with some assembly in other regions.
