Isuzu D-Max Colorado Complete Workshop Service Repair Manual 2007 2008 2009 2010 2011 2012

Regular price
$16.99
Sale price
$16.99
Regular price
🏷️ Basic Information Identification Make: Isuzu Model: D-Max Colorado Year: 2007, 2008, 2009, 2010, 2011, 2012 Codes Platform: TF/RG Series 👋 Introduction Market Position Segment: Light Commercial Vehicle (LCV) /...
23 people are viewing this right now
Type: Truck
Vendor:
Sku: 164697
Isuzu D-Max Colorado Complete Workshop Service Repair Manual 2007 2008 2009 2010 2011 2012
🏷️ Basic Information
Identification
Make:
Isuzu
Model:
D-Max Colorado
Year:
2007, 2008, 2009, 2010, 2011, 2012
Codes
Platform:
TF/RG Series
👋 Introduction
Market Position
Segment:
Light Commercial Vehicle (LCV) / Pickup Truck
Target Audience:
Commercial operators, fleet managers, and individual owners seeking to perform maintenance and repairs on their Isuzu D-Max Colorado.
Competitive Analysis
Competitors:
Toyota Hilux, Mitsubishi Triton/L200, Ford Ranger, Nissan Navara, Mazda BT-50.
Key Features
Manual Value Proposition:
Enables significant cost savings on repairs and maintenance by empowering owners and independent workshops with expert knowledge and procedures.
Accessibility:
Instantly downloadable and accessible on multiple devices (PC, Mac, tablet, smartphone) via Adobe Reader.
📋 Manual Details
Coverage Areas
Regions:
Global (specific to D-Max Colorado variants)
Models Covered:
All Isuzu D-Max Colorado models, engines, trim levels, and transmission types within the specified years.
Page Count
Estimated Pages:
Likely over 2000 pages (typical for a complete workshop manual covering multiple years and variants)
Manual Type
Type:
Complete Workshop Service Repair Manual
Language
Language:
English
Format
Format:
Downloadable PDF
📖 Manual Coverage
Systems Covered
Engine:
Detailed diagnostics, repair, overhaul, and specifications for all gasoline and diesel engines offered in the D-Max Colorado during these years (e.g., 4JA1, 4JH1, 4JJ1 series diesel engines, potentially gasoline options depending on market).
Transmission:
Manual and automatic transmission repair, overhaul, fluid specifications, and diagnostic procedures.
Drivetrain:
Front and rear differentials, transfer case (if applicable), driveshafts, CV joints, and axle repairs.
Brakes:
Disc and drum brake systems, ABS (Anti-lock Braking System), hydraulic system components, bleeding procedures, and specifications.
Suspension:
Front and rear suspension components (e.g., leaf springs, torsion bars, shocks/struts, control arms), alignment specifications, and troubleshooting.
Steering:
Power steering system, steering rack/box, tie rods, and related components.
Electrical System:
Wiring diagrams, charging system (alternator, battery), starting system (starter motor), lighting, instrumentation, and body electrical components.
Fuel System:
Fuel injection systems (common rail diesel, gasoline injectors), fuel pumps, filters, lines, and tank servicing.
Cooling System:
Radiator, water pump, thermostat, cooling fans, and hoses.
Exhaust System:
Muffler, catalytic converter (if applicable), pipes, and heat shields.
HVAC:
Air conditioning system, heater core, blower motor, and climate control.
Body And Chassis:
Frame, body panels, doors, windows, seats, interior trim, and exterior trim components.
Procedures Included
Maintenance:
Oil changes, filter replacements, fluid checks and top-offs, tire rotations, spark plug replacement (if applicable), belt and hose inspections.
Troubleshooting:
Diagnostic procedures for common and uncommon problems, fault codes interpretation (if applicable for OBD-II), and symptom-based diagnosis.
Repair:
Step-by-step instructions for component removal, installation, adjustment, and replacement for all major systems.
Overhaul:
Complete engine, transmission, differential, and other major component rebuild procedures.
Diagnostics:
Electrical system diagnostics, engine performance troubleshooting, and component testing methods.
Specifications:
Torque specifications, clearances, fluid capacities, pressures, and electrical values for all components.
Technical Depth
Depth:
Comprehensive from basic maintenance to complete engine rebuilds and advanced diagnostics. Suitable for professional technicians and advanced DIY enthusiasts.
📊 Manual Specifications
File Format
Format:
PDF
Searchability:
Likely text-searchable within Adobe Reader for quick information retrieval.
Print Quality
Printability:
Designed to be printed, with clear text and legible diagrams.
Image Resolution:
High-resolution images and diagrams for clarity.
Binding Type
Binding Type:
Not Applicable (Digital Download)
Paper Type
Paper Type:
Not Applicable (Digital Download)
⚙️ Engine Specifications
Primary Engine
Diesel Engine Options:
Commonly includes 4JA1-T (2.5L Turbo Diesel), 4JH1-T (3.0L Turbo Diesel), and 4JJ1-T (3.0L Turbo Diesel with common rail injection depending on market and specific year evolution).
Gasoline Engine Options:
May include 4ZE1 (2.6L SOHC) or other gasoline variants depending on the specific market covered by the manual.
Performance
Hp Range:
Typically ranges from 80-140 hp for diesel engines and 120-130 hp for gasoline engines in this era, depending on specific engine and tuning.
Torque Range:
Torque figures vary widely by engine, but common diesel engines could produce between 200-300 Nm.
Fuel System
Diesel Injection Type:
Indirect Injection (IDI) for older models (e.g., 4JA1) and Direct Injection (DI) with Common Rail (CRDI) for later models (e.g., 4JJ1).
Diesel Fuel Specification:
API CI-4 or CJ-4 rated diesel fuel recommended for common rail systems.
Maintenance
Timing Belt Chain:
Most Isuzu diesel engines of this era utilize timing chains, which are generally considered maintenance-free unless issues arise.
🔧 Transmission
Standard
Manual Transmission:
Multiple manual transmission options available, often 5-speed, with varying gear ratios depending on application and model year.
Optional
Automatic Transmission:
Optional automatic transmissions were available on many D-Max Colorado models, typically 4-speed or 5-speed units.
Features
Transfer Case:
4WD models feature a selectable 2WD/4WD transfer case, often with low-range gearing.
Fluid Specifications
Manual Transmission Fluid:
GL-4 or GL-5 rated gear oil, typically SAE 75W-90 or SAE 80W-90, depending on manufacturer recommendation.
Automatic Transmission Fluid:
Dexron-III or equivalent ATF fluid is commonly specified for models of this era.
📐 Dimensions
Exterior
Body Styles:
Single Cab, Extended Cab (Space Cab), Crew Cab.
Wheelbase:
Varies by cab configuration and model year, typically ranging from 3050mm to 3380mm.
Weights
Curb Weight:
Ranges from approximately 1600 kg to 2000 kg depending on configuration (2WD/4WD, cab type, engine).
🛡️ Safety Features
Ratings
Crash Test Ratings:
Ratings vary by market and specific testing agency (e.g., ANCAP, Euro NCAP). Older models may have lower ratings than contemporary vehicles.
Active Features
ABS:
Anti-lock Braking System (ABS) was available as an option or standard on higher trims.
Traction Control:
Traction control systems (TCS) may be present on later models or higher trim levels.
Passive Features
Airbags:
Driver and passenger airbags were standard or optional depending on trim and market.
💡 Technology Features
Infotainment
Audio System:
Basic AM/FM radio with CD player was common, with potential for auxiliary input or later models offering basic MP3 compatibility.
Driver Assistance
Cruise Control:
Cruise control was often an optional feature on higher trim levels, particularly for models with automatic transmissions.
Connectivity
Bluetooth:
Bluetooth connectivity for hands-free calling or audio streaming was uncommon in base models of this era, appearing on more premium trims or as an aftermarket addition.
🔧 Maintenance
Service Intervals
Engine Oil Change:
Typically every 5,000 - 10,000 km (3,000 - 6,000 miles) or 6-12 months, depending on usage conditions and oil type.
Fuel Filter Replacement:
Recommended every 20,000 - 40,000 km (12,000 - 24,000 miles) for diesel models, crucial for common rail systems.
Air Filter Replacement:
Every 15,000 - 30,000 km (9,000 - 18,000 miles) or as needed based on driving environment.
Fluid Specifications
Engine Oil Specification:
Diesel engines: API CH-4, CI-4, or CJ-4; SAE 15W-40 or 10W-30 depending on climate. Gasoline engines: API SN/SM; SAE 5W-30 or 10W-30.
Coolant Specification:
Isuzu specified Long Life Coolant (LLC) or an equivalent ethylene glycol-based coolant with a 50/50 mix with distilled water.
Known Issues
Diesel Engine Glow Plugs:
Glow plugs can wear out and require replacement, especially in colder climates. The manual would detail testing and replacement procedures.
Common Rail Injectors:
Early common rail systems could be sensitive to fuel quality. The manual would cover diagnostic procedures for injector issues.
Suspension Wear:
Leaf springs and bushings on the rear suspension can experience wear over time due to load carrying and road conditions. The manual would provide replacement and adjustment guidance.
📚 Vehicle History
Brand Heritage
Isuzu Lc History:
Isuzu has a long history in producing robust and reliable diesel engines and commercial vehicles, with the D-Max line tracing its roots back to models like the Faster/Rodeo Pickup.
Model Evolution
D Max Colorado Era:
The D-Max Colorado covered by this manual represents the second generation of the D-Max platform, introduced globally around 2002-2003 and facelifted/updated through these years.
Production
Manufacturing Locations:
Primarily manufactured in Thailand, with assembly plants in other global locations.
🏆 Awards & Recognition
Recognitions
Brand Recognition:
Isuzu is globally recognized for its durable diesel engines and robust commercial vehicle platforms.
Ratings
Reliability Perception:
Generally perceived as reliable and durable, particularly the diesel variants, making them popular in commercial and off-road applications.
Sale
