2007 Harley Davidson Softail Models Service Repair Manual

Regular price: $16.99
Sale price: $16.99
Regular price
Unit price: per

18 people are viewing this right now

Type: Motorcycle

Vendor:

Sku: 144843

Tags: 2007 Harley Davidson Motorcycle Motorcycles Softail

Product variants

Description

This manual covers the 2007 lineup, encompassing various models such as the Softail Custom (FXSTC), Fat Boy (FLSTF), Softail Deluxe (FLSTN), Springer Classic (FLSTSC), Heritage Softail Classic (FLSTC), Softail Standard (FXST), Softail Night Train (FXSTB), and Softail Deuce (FXSTD). These motorcycles are celebrated for their iconic V-Twin OHV air-cooled engines, primarily featuring the Twin Cam 96 (1584cc) with Sequential Electronic Fuel Injection (ESPFI). The Softail platform itself is renowned for its classic rigid appearance achieved through hidden rear shock absorbers, combined with a 6-speed Cruise Drive transmission and a carbon fiber reinforced V-belt final drive. Established in 1903, it is an iconic American manufacturer known for its focus on rider experience, customization, and heritage, offering these models in the cruiser, luxury cruiser, and custom motorcycle segments. This comprehensive Service Repair Manual provides detailed guidance for owners and professional technicians alike. Its scope includes in-depth coverage of all major systems, from engine disassembly and assembly, fuel and ignition systems, to the electrical system, chassis components including suspension and brakes, and the drive and transmission systems. Procedures detailed within the manual cover scheduled maintenance, engine tuning, fuel system diagnostics, brake system servicing, electrical troubleshooting with high-quality wiring diagrams, and common issue resolution. This resource is designed to facilitate cost-effective repairs and maintenance, offering the same level of information found in official dealer service manuals, ensuring accuracy and completeness for all service tasks.

🏷️ Basic Information

Identification

Make:

Harley-Davidson

Model:

Softail (All Models)

Year:

Model Codes:

• FXSTC (Softail Custom)

• FLSTF (Fat Boy)

• FLSTN (Softail Deluxe)

• FLSTSC (Softail Springer Classic)

• FLSTC (Heritage Softail Classic)

• FXST (Softail Standard)

• FXSTB (Softail Night Train)

• FXSTD (Softail Deuce)

👋 Introduction

Market Position

Target Audience:

Do-it-yourself motorcycle owners and professional technicians.

Key Features

Manual Utility:

Provides the same information as the dealer service manual, enabling cost-effective repairs and maintenance.

Ease Of Use:

Easy-to-read text, top-quality diagrams, and step-by-step instructions with pictures.

Information Source Authenticity:

Directly comparable to official Harley-Davidson dealer service manuals, ensuring accuracy and completeness for all repair and maintenance tasks.

Competitive Analysis

Market Segment:

Cruiser motorcycles, luxury cruisers, and custom motorcycles.

📋 Manual Details

Coverage

Coverage Areas:

• Maintenance

• Chassis

• Engine

• Fuel System

• Electric Starter

• Drive System

• Transmission

• Electrical System

• Appendices A & B

• Index

Format

Manual Type:

Service Repair Manual

File Format:

File Storage:

Can be saved to hard-drive and burned to CD.

Language

Language:

English

Page Count

Page Count:

Not explicitly stated, but typical comprehensive service manuals of this era for multiple models often range from 600 to over 1000 pages.

📖 Manual Coverage

Systems

Systems Covered:

• Engine: Disassembly, assembly, lubrication, cooling, internal components

• Fuel System: Carburetor/Fuel Injection, fuel pump, fuel lines, filters

• Ignition System: Ignition module, coils, spark plugs

• Electrical System: Battery, charging system, starter motor, lighting, instrumentation, wiring diagrams

• Chassis: Frame, suspension (front and rear), steering, wheels, tires, brakes (front and rear)

• Drive System: Primary drive, clutch, final drive (belt)

• Transmission: Gearbox, internal components, shifting mechanisms

• Bodywork: Fenders, fuel tank, seat, handlebars, controls

Procedures

Procedures Included:

• Scheduled maintenance and inspections

• Engine tuning and adjustments

• Fuel system diagnostics and repair

• Brake system bleeding and component replacement

• Suspension setup and fork seal replacement

• Electrical troubleshooting using detailed wiring diagrams

• Transmission oil changes and clutch adjustment

• Belt tension checks and replacement procedures

• Troubleshooting common problems with diagnostic flowcharts

Diagnostics Included:

Detailed troubleshooting procedures, diagnostic flowcharts, and specifications for identifying and resolving mechanical and electrical faults.

Depth

Technical Depth:

Comprehensive professional technical service and repair, suitable for DIY enthusiasts and experienced mechanics.

Technical Depth

Wiring Diagrams Quality:

High-quality, detailed wiring diagrams are included, essential for electrical system troubleshooting.

📊 Manual Specifications

File Quality

File Format Details:

PDF, high resolution, printable.

Print Quality:

Great quality when printing needed pages.

Compatibility

Software Requirements:

• Adobe PDF Reader

• WinZip

Operating Systems:

• All PC based Windows operating systems

• Mac

Delivery

Delivery Method:

Instant download after payment.

Binding Type

Binding Type:

N/A (Digital Download)

Paper Type

Paper Type:

N/A (Digital Download)

⚙️ Engine Specifications

Primary Engine

Engine Type:

V-Twin OHV (Air-Cooled)

Engine Displacement:

Primarily Twin Cam 96 (1584cc) for most models, with potential variations based on specific model variants within the Softail family. The FXSTD Deuce also offered the Twin Cam 88B (1450cc) and later models may have had the Twin Cam 103 (1690cc) as options or in later iterations of the platform, though 2007 primarily focused on 96 cubic inches.

Fuel System

Fuel Delivery:

Sequential Electronic Fuel Injection (ESPFI) for most models, some earlier or specific variants might have had carburetors, but 2007 models predominantly utilize EFI.

Performance

Horsepower Torque:

Horsepower and torque figures vary slightly by specific model and tuning, but the Twin Cam 96 engine typically produced around 90-95 lb-ft of torque at lower RPMs, providing strong low-end grunt characteristic of Harley-Davidson cruisers.

Engine Components

Engine Cooling:

Air-cooled, relying on airflow through cooling fins and fan assist in some extremely low-speed or stationary situations.

🔧 Transmission

Standard

Transmission Type:

6-Speed Cruise Drive Transmission

Features

Transmission Drive:

Primary drive via a wet, multi-plate clutch; final drive via a carbon fiber reinforced V-belt.

📐 Dimensions

Weights

Dry Weight:

Varies by model, typically ranging from approximately 670 lbs (304 kg) for FXST models to over 700 lbs (318 kg) for FLSTC models.

Gross Vehicle Weight Rating:

Varies by model, typically around 1160 lbs (526 kg).

Payload Capacity:

Not typically rated as a payload capacity in the automotive sense, but designed to carry a rider and passenger plus a reasonable amount of luggage.

🛡️ Safety Features

Passive Features

Braking System:

Hydraulic disc brakes front and rear. ABS (Anti-lock Braking System) was an optional feature on some models for 2007.

💡 Technology Features

Infotainment

Infotainment Features:

Base models typically feature analog instrumentation. Optional audio systems (radio, CD player) were available on certain higher-trim models or as dealer-installed accessories.

Driver Assistance

Driver Assistance Features:

Anti-lock Braking System (ABS) was an optional feature on select models for 2007.

🔧 Maintenance

Service Intervals

Oil Change Interval:

Typically every 5,000 miles (8,000 km) or 12 months, whichever comes first, for engine oil. Transmission and primary chain case oil changes have separate intervals.

Belt Drive Tension Check:

Check belt tension at 1,000 miles and then every 5,000 miles or as needed per manufacturer's recommendations.

Spark Plug Replacement:

Recommended replacement intervals vary, typically around 10,000-20,000 miles, with specific torque and gap specifications provided in the manual.

Fluid Specifications

Engine Oil Type:

Harley-Davidson recommended V-Twin specific oil, typically 20W50 (e.g., Harley-Davidson SYN3 or equivalent full synthetic motorcycle oil).

Transmission Oil Type:

Harley-Davidson Formula + Transmission Oil or equivalent.

Primary Chain Case Oil Type:

Harley-Davidson Formula + Transmission Oil or equivalent.

Brake Fluid Type:

DOT 4 brake fluid.

Known Issues

Common Issues 2007 Softail:

While generally robust, common areas for attention on 2007 Softails can include clutch cable adjustment, primary drive chain tension, belt drive inspection, fuel injector cleaning (on EFI models), and occasional speedometer or electrical connector issues. Specific models like the Springer Classic might require attention to the springer front end lubrication and adjustment.
