Vehicle Segment:
Compact hatchback/wagon, known for practicality and reliability due to Toyota's influence
Competitors:
Toyota Matrix, Honda Fit, Mazda3 Hatchback, Ford Focus Hatchback
Key Selling Points:
Practical cargo space, fuel efficiency, Toyota mechanicals, affordable pricing
Manual Benefit:
Empowers owners and independent mechanics to perform all maintenance and repairs accurately and efficiently
Engine:
Detailed engine repair, diagnosis, and overhaul (including specific engine variants)
Transmission:
Service and repair procedures for automatic and manual transmissions
Drivetrain:
Front-wheel drive (FWD) and All-wheel drive (AWD) system service
Suspension:
Front and rear suspension component diagnosis, replacement, and alignment
Brakes:
Brake system inspection, repair, bleeding, and component replacement (ABS included)
Steering:
Power steering system service and diagnosis
Electrical:
Complete electrical system diagnosis, wiring diagrams, component testing
HVAC:
Heating, Ventilation, and Air Conditioning system service and repair
Body And Trim:
Body panel repair, interior trim removal/installation, glass replacement
Climate Control:
Detailed information on A/C refrigerant handling and system repair
Fuel System:
Fuel pump, injectors, lines, and tank service
Exhaust System:
Exhaust component replacement and diagnosis
Cooling System:
Radiator, water pump, thermostat, and coolant service
Ignition System:
Spark plugs, coils, and ignition timing
Emission Control:
Catalytic converter, O2 sensors, and EVAP system troubleshooting
Lighting:
Headlights, taillights, interior lighting repair and replacement
Dashboard And Instruments:
Instrument cluster repair and diagnostic procedures
Seats:
Seat adjustment mechanisms and trim removal
Doors And Windows:
Window regulators, door locks, and power window motor service
Maintenance:
Scheduled maintenance, oil changes, filter replacements, fluid checks
Troubleshooting:
Diagnostic charts, symptom-based troubleshooting, and error code interpretation
Repair:
Step-by-step instructions for component replacement and system repair
Overhaul:
Complete engine and transmission rebuild procedures
Recalibration:
Procedures for electronic component recalibration (e.g., throttle body, steering angle sensor)
Diagnostic Troubleshooting:
Detailed procedures for diagnosing electrical and mechanical faults
Depth:
Professional level, covering basic maintenance to complete engine/transmission overhauls
Diagrams:
Hundreds of detailed photos and exploded diagrams
Instructions:
Step-by-step instructions for all procedures
Engine Option 1:
1.8L 1ZZ-FE Inline-4 (Toyota-sourced)
Engine Option 1 Displacement:
1794 cc (1.8 Liters)
Engine Option 1 Horsepower:
126 hp @ 6000 rpm
Engine Option 1 Torque:
122 lb-ft @ 4200 rpm
Engine Option 2:
2.4L 2AZ-FE Inline-4 (Toyota-sourced) - GT trim only
Engine Option 2 Displacement:
2362 cc (2.4 Liters)
Engine Option 2 Horsepower:
158 hp @ 6000 rpm
Engine Option 2 Torque:
162 lb-ft @ 4000 rpm
Fuel Delivery:
Electronic Fuel Injection (EFI)
Fuel Type:
Unleaded Gasoline (87 octane recommended)
Standard Transmission:
5-speed Manual Transmission (MT)
Optional Transmission:
4-speed Automatic Transmission (AT)
AWD Availability:
Optional All-Wheel Drive (AWD) available on 2.4L GT models
Automatic Transmission Fluid:
Dexron III/VI compatible (refer to manual for specific part numbers like GM 88863424 or equivalent)
Manual Transmission Fluid:
GM Synchromesh Friction Modified Transmission Fluid or equivalent (refer to manual for specific part numbers)
NHTSA Front Impact Driver:
5-Star (2009 Model Year)
NHTSA Front Impact Passenger:
5-Star (2009 Model Year)
NHTSA Side Impact Front Driver:
5-Star (2009 Model Year)
NHTSA Side Impact Front Passenger:
5-Star (2009 Model Year)
NHTSA Side Impact Rear Driver:
5-Star (2009 Model Year)
NHTSA Side Impact Rear Passenger:
5-Star (2009 Model Year)
NHTSA Rollover Rating:
4-Star (2009 Model Year)
ABS:
Standard Anti-lock Braking System (ABS)
Traction Control:
Standard Traction Control System (TCS)
Airbags:
Driver and front passenger airbags, front side-impact airbags, side curtain airbags
Oil Change Interval:
Every 5,000 to 7,500 miles (3000 miles for severe driving conditions) or 6 months, whichever comes first (refer to manual for precise intervals based on driving habits).
Engine Air Filter:
Inspect every 15,000 miles, replace as needed (typically every 30,000 miles).
Cabin Air Filter:
Replace every 15,000 to 30,000 miles, or annually.
Spark Plugs:
Iridium-tipped spark plugs: 100,000 miles (refer to manual for specific part numbers like NGK ILKAR7A11 or equivalent).
Coolant Flush:
First flush at 100,000 miles, then every 50,000 miles thereafter (use GM Super Coolant/Dex-Cool or equivalent pre-mixed).
Engine Oil Type:
SAE 5W-30, API certified (GM dexos1 or dexos2 compatible if available/specified).
Engine Oil Capacity:
4.0 US quarts (3.8 L) for 1.8L, 4.5 US quarts (4.3 L) for 2.4L (with filter).
Power Steering Fluid:
GM Power Steering Fluid or equivalent (refer to manual).
Common Wear Item 1:
Water pump seal leakage (especially on 1ZZ-FE engine).
Common Wear Item 2:
Oil consumption on some 1ZZ-FE engines due to piston ring wear (less common in later models).
Common Wear Item 3:
CV Axle boot degradation leading to premature failure.
Common Wear Item 4:
O2 sensor failures contributing to check engine lights.
Common Wear Item 5:
Catalytic converter issues, often linked to engine oil consumption.
Pontiac Brand Context:
Pontiac was an American automobile division of General Motors (GM) known for performance-oriented vehicles, though the Vibe bridged this with practicality.
Generation 2:
2009-2010 marked the second generation of the Pontiac Vibe, a joint venture with Toyota. This generation was based on the second-generation Toyota Matrix.
Manufacturing Plant:
Fremont, California, USA (GM/Toyota NUMMI plant)
Pontiac Brand Discontinuation:
Pontiac brand was discontinued by GM in 2010, leading to the end of Vibe production.
