Segment:
Compact Crossover SUV.
Uniqueness:
Known for its boxy, utilitarian design, flexible 'Magic Seat' rear seating system, and durable interior materials.
Key Competitors:
Toyota RAV4, Ford Escape, Mazda Tribute, Nissan Rogue.
Manual Advantage:
Licensed OE (Original Equipment) materials, instant online access, user-friendly interface, comprehensive coverage.
Vehicle Advantage:
Practicality, cargo versatility, fuel efficiency, Honda reliability, all-wheel-drive availability.
Primary Coverage:
2009 Honda Element
Secondary Coverage:
All trim levels and engine configurations for the 2009 model year.
Estimated Pages:
Extensive (Digital format, equivalent to several hundred printed pages).
Type:
Online Service and Repair Manual Software
Format:
Web-based software, accessible via browser.
Access Duration:
1 Year subscription (with discounts for renewal).
Engine Mechanical:
Engine assembly, cylinder head, block, pistons, crankshaft, camshaft, timing system, lubrication system, cooling system.
Engine Performance:
Fuel injection, ignition, emissions control, turbocharging (if applicable), engine diagnostics.
Transmission Drivetrain:
Automatic transmission (5-speed), clutch system (if applicable), driveshafts, differentials, axles.
Brakes:
Front and rear disc brakes, ABS, EBD, brake system hydraulics, parking brake.
Suspension Steering:
Front suspension (MacPherson struts), rear suspension (multi-link beam axle), power steering system, steering gear, wheel alignment.
Electrical Lighting:
12V battery, charging system, starting system, ignition system, lighting (headlights, taillights, interior), fuses, relays.
HVAC:
Heating, ventilation, and air conditioning (HVAC) system diagnosis and repair, refrigerant handling.
Body Chassis:
Body structure, doors, windows, roof (including features like sunroof if equipped), interior trim, exterior panels, chassis components.
Safety Restraints:
Airbag system, seat belts, SRS module, occupant restraint systems.
Maintenance:
Scheduled maintenance, oil changes, filter replacements, fluid checks and top-offs, spark plug replacement, belt inspection/replacement.
Diagnostics:
Troubleshooting guides for common problems, diagnostic trouble codes (DTCs) interpretation, wiring diagrams for electrical system analysis.
Repair:
Step-by-step repair instructions for all major components and systems, including engine rebuild, transmission overhaul, brake caliper replacement, suspension component replacement.
Installation:
Component removal and installation procedures for various parts and systems.
Specifications:
Torque specifications for fasteners, clearances, fluid capacities, diagnostic specifications.
Depth:
Comprehensive (from routine maintenance to major component overhauls and advanced diagnostics).
Engine Code:
K24A1 (for most North American models)
Engine Type:
Inline 4-cylinder, DOHC, i-VTEC
Displacement:
2.4 Liters (2354 cc)
Horsepower:
Approx. 166 hp @ 5800 rpm
Torque:
Approx. 161 lb-ft @ 4400 rpm
Fuel Delivery:
Electronic Fuel Injection (PGM-FI)
Recommended Fuel:
87 Octane Unleaded Gasoline
Oil Type:
SAE 5W-20 (API Certified)
Oil Capacity:
Approx. 4.4 US quarts (with filter change)
NHTSA Front Crash Test:
5-Star (Driver and Passenger)
NHTSA Side Impact Crash Test:
5-Star (Front and Rear Passengers)
IIHS Moderate Overlap Front Crash Test:
Good
IIHS Side Impact Crash Test:
Good
IIHS Rear Impact Crash Test:
Good
ABS:
Standard (Anti-lock Braking System)
Ebd:
Standard (Electronic Brake-force Distribution)
Traction Control:
Standard (TCS)
Stability Control:
Standard (Vehicle Stability Assist - VSA)
Airbags:
Front airbags, front side airbags, side curtain airbags (front and rear).
Seat Belts:
3-point seat belts with pretensioners for all occupants.
Oil Change Interval:
Every 5,000-7,500 miles or 6 months, based on driving conditions (refer to manual for specific recommendations).
Air Filter Replacement:
Typically every 15,000-30,000 miles, or as needed based on inspection.
Spark Plug Replacement:
Approx. 100,000 miles (Long-life iridium-tipped spark plugs).
Transmission Fluid Change:
Recommended every 60,000 miles (severe service) or as indicated by maintenance minder system.
Coolant Type:
Honda Genuine Long Life Antifreeze/Coolant (Blue).
Coolant Capacity:
Approx. 7.1 US quarts (FWD), 7.4 US quarts (AWD).
Brake Fluid Type:
Honda Genuine DOT 3 Brake Fluid.
Power Steering Fluid Type:
Honda Genuine Power Steering Fluid.
Common Complaints:
Occasional reports of minor oil leaks, HVAC blower motor issues, and rear hatch strut wear. The plastic body panels can be prone to scratching.
Honda Reputation:
Known for engineering excellence, reliability, fuel efficiency, and high resale value.
Generation:
First Generation (2003-2011).
Design Philosophy:
Characterized by its distinctive, nearly flat roofline and large, suicide-style rear doors for easy access.
Assembly Location:
East Liberty, Ohio, USA.
