🏷️ Basic Information

Make:

Cadillac

Model:

Escalade

Year:

2010

Trim Levels Covered:

All (e.g., Base, Luxury, Platinum)

Body Styles Covered:

All (e.g., Standard Wheelbase, ESV Extended Wheelbase)

Platform:

GMT900 (shared with Chevrolet Tahoe/Suburban, GMC Yukon/Yukon XL)

👋 Introduction

Market Position:

The 2010 Cadillac Escalade is a full-size luxury SUV, positioned as a premium offering with robust towing capabilities and a comfortable, well-appointed interior. It competes with other luxury SUVs like the Lincoln Navigator, Lexus LX, and Mercedes-Benz GL-Class.

Competitive Analysis:

In 2010, the Escalade offered a blend of American luxury and power, often appealing to buyers seeking a commanding presence and significant towing capacity. Its interior amenities and available advanced features were key selling points against its competitors.

Key Features:

Powerful V8 engine, Magnetic Ride Control suspension, available All-Wheel Drive, luxurious interior appointments, advanced safety features, substantial towing and cargo capacity.

📋 Manual Details

Areas:

Complete Service and Repair, Diagnostics, Maintenance, Troubleshooting, Wiring Schematics, Specifications, Component Removal/Installation, Overhaul Procedures

Estimated Page Count:

Extensive (typically 2000+ pages for full factory service manuals, digital format implies comprehensive content)

Type:

Factory Service Manual (FSM) / Workshop Manual

Language:

English

Format:

PDF (digital)

Operating Systems:

Compatible with Windows (Vista 32/64, XP, ME, 98, NT, 2000) and Mac operating systems.

Additional Features:

Printable pages, ability to blow up images, searchable text (typical for high-quality PDF manuals), easy navigation.

📖 Manual Coverage

Systems:

Engine Mechanical, Engine Control System (ECM/PCM), Fuel System, Emission Control System, Intake and Exhaust Systems, Cooling System, Lubrication System, Ignition System, Starting and Charging System, Automatic Transmission, Transfer Case (if applicable), Drive Axles, Suspension System, Steering System, Brake System (including ABS and StabiliTrak), Power Steering, HVAC (Heating, Ventilation, and Air Conditioning), Supplemental Restraint System (SRS - Airbags), Seat Belt Systems, Engine Immobilizer System, Cruise Control System, Wiper and Washer Systems, Door Locks and Security, Instrument Panel and Gauges, Audio and Visual Systems, Horn, Windshield, Glass, Mirrors, Instrument Panel, Seats, Engine Hood and Doors, Exterior and Interior Trim, Electrical Systems, Multiplex/CAN Communication Systems, Body Control Modules (BCM), Powertrain Control Modules (PCM), Diagnostic Procedures, Trouble Codes (DTCs)

Procedures:

Scheduled Maintenance, Routine Inspections, Component Removal and Installation, Disassembly and Reassembly, Adjustment Procedures, Diagnostic Flowcharts, Troubleshooting Guides, Wiring Harness Repair, Sensor Testing, Actuator Testing, Software Updates/Programming (as applicable for dealer tools), Fluid Flushes and Replacements, Filter Replacements, Brake Pad/Rotor Replacement, Suspension Component Replacement, Steering Component Replacement, HVAC System Servicing, Airbag System Diagnostics and Replacement, Electrical Component Testing, Body Panel Alignment and Repair

Depth:

Comprehensive and Vehicle-Specific. Covers basic maintenance to in-depth engine and transmission overhauls, advanced electrical diagnostics, and body component repairs. Provides step-by-step instructions, torque specifications, diagnostic parameters, and wiring diagrams.

Wiring Schematics Availability:

Includes detailed, system-specific wiring diagrams for all major electrical components, power distribution, and communication networks. Essential for diagnosing electrical faults.

📊 Manual Specifications

File Format:

PDF

Print Quality:

High-resolution, suitable for printing individual pages or sections with clarity. Images and diagrams are detailed.

Binding Type:

N/A (Digital PDF format)

Paper Type:

N/A (Digital PDF format - printable on user-selected paper)

⚙️ Engine Specifications

Engine Type:

6.2L V8 SOHC VVT

Engine Code:

L92 (common for this generation)

Horsepower:

403 hp @ 5700 rpm

Torque:

417 lb-ft @ 4300 rpm

Fuel Delivery:

Sequential Fuel Injection (SFI)

Recommended Fuel:

Premium Unleaded (91 octane or higher recommended for optimal performance)

Coolant Type:

Dex-Cool (Orange Long-Life, 50/50 mix with distilled water)

Oil Type:

SAE 5W-30 Synthetic

Oil Capacity:

7.0 US quarts (6.6 liters)

Emission Standards:

Meets Tier 2 Bin 5 emission standards

Engine Code Variants:

While L92 is primary for the 6.2L, ensure the specific engine RPO code is cross-referenced for absolute accuracy if minor variations exist within the model year for specific markets.

🔧 Transmission

Transmission Type:

6-Speed Automatic Transmission

Transmission Model:

6L80E

Drivetrain:

Available in RWD and AWD configurations

Transmission Features:

Active Fuel Management (AFM) on some models, Tow/Haul mode, manual shift mode (Driver Shift Control)

Transmission Fluid Type:

Dexron-VI (Mercon LV compatible)

Transmission Fluid Capacity:

Approximately 8.4 US quarts (7.9 liters) for initial fill

Clutch Type:

N/A (automatic transmission only)

📐 Dimensions

Wheelbase Standard:

116.1 inches (2950 mm)

Wheelbase Esv:

130.0 inches (3302 mm)

Length Standard:

200.0 inches (5080 mm)

Length Esv:

224.5 inches (5702 mm)

Width:

79.1 inches (2009 mm)

Height:

75.7 inches (1923 mm)

Cargo Volume Behind 3Rd Row Standard:

16.9 cu ft (479 liters)

Cargo Volume Behind 2Nd Row Standard:

45.6 cu ft (1291 liters)

Cargo Volume Behind 1St Row Standard:

97.1 cu ft (2749 liters)

Curb Weight Rwd:

Approx. 5,525 lbs (2506 kg)

Curb Weight AWD:

Approx. 5,721 lbs (2595 kg)

Towing Capacity:

Up to 8,300 lbs (3765 kg) (when properly equipped with trailering package)

Wheel Bolt Pattern:

6 x 139.7 mm (6 x 5.5 inches)

Standard Tire Size:

P275/55R20

🛡️ Safety Features

NHTSA Rollover Resistance:

4/5 stars (for 2010 model year typically)

Active Safety:

ABS, Traction Control, StabiliTrak Electronic Stability Control, Tire Pressure Monitoring System (TPMS), Rear Vision Camera, Front and Rear Park Assist

Passive Safety:

Driver and front passenger front airbags, Driver and front passenger side-impact airbags, Head curtain side-impact airbags for all rows, Front seat belt pretensioners, LATCH (Lower Anchors and Tethers for Children) system

💡 Technology Features

Infotainment System:

Cadillac CUE (often referred to by dealer technicians as the AV system or infotainment system), typically featuring touchscreen interface, navigation, Bluetooth, USB/auxiliary inputs, and premium audio systems (e.g., Bose).

Driver Assistance Features:

Rearview camera, parking assist, available adaptive cruise control (on some trims/packages).

Connectivity Features:

OnStar system, Bluetooth connectivity for hands-free calling and audio streaming.

🔧 Maintenance

Oil Change Interval:

Every 7,500 miles or 12 months, or as indicated by the Oil Life Monitoring System.

Tire Rotation Interval:

Every 7,500 miles

Transmission Fluid Change Interval:

Refer to manual for severe vs. normal use. Typically every 50,000-100,000 miles, but often recommended for inspection at 45,000 miles.

Coolant Flush Interval:

First flush at 5 years or 150,000 miles, then every 5 years or 150,000 miles thereafter (for Dex-Cool).

Brake Fluid Type:

DOT 3

Power Steering Fluid Type:

Dexron-VI Automatic Transmission Fluid

Common Issues:

Potential for ABS sensor failures, catalytic converter issues, fuel pump failures, transmission solenoid failures, and sometimes issues with the magnetic ride control system. Interior electronics can also be prone to minor glitches.

Oil Filter Part Number:

Commonly AC-Delco PF48 or equivalent (actual part number may vary based on sub-model and production date, consult manual for precision).

📚 Vehicle History

Brand Heritage:

Cadillac, a division of General Motors, has a long history of producing luxury vehicles in the United States, known for comfort, style, and technological innovation.

Model Evolution:

The Escalade, introduced for the 1999 model year, was Cadillac's first truck-based SUV. The third generation (GMT900 platform, 2007-2014) saw significant styling updates, a more powerful engine, and enhanced technology, with the 2010 model year representing a mid-cycle enhancement with refreshed features and design cues.

Production Location:

Arlington, Texas, USA

🏆 Awards & Recognition

Recognitions:

The Escalade typically received positive reviews for its luxury, comfort, and performance, often appearing on 'most luxurious SUV' lists. Specific awards for the 2010 model year would be noted in automotive reviews of that period.
