🏷️ Basic Information

Make:

Dodge

Model:

Journey

Year:

2010

Market Segment:

Mid-size Crossover SUV

👋 Introduction

Positioning:

The 2010 Dodge Journey was positioned as a family-oriented, versatile crossover SUV, offering three-row seating in some configurations and a blend of car-like driving dynamics with SUV utility. It competed with vehicles like the Toyota Highlander, Honda Pilot, and Ford Edge.

Strengths:

Spacious interior, flexible seating options, available AWD, comfortable ride, competitive pricing.

Weaknesses:

Base engine performance (2.4L), CVT transmission smoothness in some conditions, perceived interior material quality compared to some rivals.

Seating:

Optional 7-passenger seating with 2nd-row tilt-and-slide functionality and available integrated child booster seats.

Storage:

Numerous clever storage solutions including under-seat storage bins (front passenger), in-floor cargo bins in the second row, and a dual-level cargo floor.

Design:

Distinctive Dodge styling with a crosshair grille, available R/T sport appearance package.

📋 Manual Details

Primary Coverage:

Mechanical, Electrical, Body, Maintenance, Troubleshooting, Diagnostics

Engine Coverage:

2.4L I4 (World Engine), 3.5L V6 (Pentastar)

Transmission Coverage:

CVT (for 2.4L), 6-speed automatic (for 3.5L)

Trim Level Coverage:

All trims including SE, SXT, R/T

Estimated Pages:

2000-3000

Type:

Factory Service Manual / Repair Manual

Language:

English

Format:

Digital (PDF) - Searchable

📖 Manual Coverage

Powertrain:

Engine mechanical (2.4L, 3.5L), Engine control systems (PCM/ECM), Fuel system, Ignition system, Exhaust system, Cooling system, Lubrication system

Drivetrain:

Front-wheel drive (FWD), All-wheel drive (AWD) system components, CV joints, Driveshafts, Differentials

Transmission:

CVT operation and repair, 6-speed automatic transmission (62TE) operation and repair, Torque converter, Gear shift mechanisms

Suspension:

Front suspension (MacPherson strut), Rear suspension (Multi-link), Springs, Shock absorbers, Bushings, Wheel alignment specifications

Steering:

Power steering system (hydraulic), Steering gear, Power steering pump, Steering column, Tie rods

Brakes:

Front disc brakes, Rear disc brakes, ABS (Anti-lock Braking System), Traction Control, Electronic Stability Control (ESC), Brake fluid specifications

Electrical:

Battery, Charging system, Starting system, Lighting (headlights, taillights, interior), Fuses and Relays, Wiring diagrams, Instrument cluster, Power windows, Power locks, HVAC controls

Body And Interior:

Body panels, Doors, Hood, Liftgate, Bumpers, Seats, Trim panels, Dashboard, HVAC system operation, Body sealant and adhesive specifications

HVAC:

Air conditioning system, Heater core, Blower motor, Refrigerant specifications, HVAC diagnostics

Maintenance:

Oil change, Filter replacement (oil, air, cabin), Spark plug replacement, Fluid checks and top-offs (coolant, brake fluid, power steering fluid, transmission fluid), Tire rotation

Engine Repair:

Head gasket replacement, Timing chain/belt service, Piston and ring replacement, Valve stem seal replacement, Engine assembly/disassembly

Transmission Repair:

CVT fluid and filter replacement, 6-speed automatic transmission fluid and filter replacement, Valve body repair, Clutch pack replacement (if applicable), Transmission removal and installation

Brake Service:

Brake pad and rotor replacement, Brake caliper service, Brake fluid bleeding, ABS module diagnosis and replacement

Electrical Diagnostics:

Troubleshooting wiring issues, Sensor testing, Actuator testing, PCM/ECM diagnostics, Instrument cluster repair

Suspension And Steering Repair:

Strut and shock replacement, Control arm bushing replacement, Ball joint replacement, Tie rod end replacement, Power steering pump replacement, Wheel bearing replacement

Body And Trim:

Door panel removal, Seat removal, Dashboard removal, Liftgate adjustment, Panel alignment procedures

Troubleshooting:

Diagnostic trouble codes (DTCs) interpretation, Symptom-based troubleshooting guides, Component testing procedures

Depth:

Comprehensive from basic maintenance to in-depth component-level repair and overhaul. Includes detailed diagnostic procedures, specifications, and wiring diagrams.

📊 Manual Specifications

Format:

PDF (Portable Document Format)

Searchability:

Fully text-searchable for quick information retrieval.

Printability:

Printable for workshop use.

Quality:

High-resolution scans ensuring clarity of diagrams and text.

Binding:

N/A (Digital PDF)

Paper Type:

N/A (Digital PDF)

⚙️ Engine Specifications

Base Engine:

2.4L 'World Engine' DOHC 16-valve Inline-4

Optional Engine:

3.5L SOHC 24-valve V6 (Pentastar evolution)

2.4L Hp:

173 hp @ 6000 rpm

2.4L Torque:

165 lb-ft @ 4400 rpm

3.5L Hp:

235 hp @ 6400 rpm

3.5L Torque:

232 lb-ft @ 4000 rpm

2.4L Fuel Delivery:

Electronic Multi-Port Fuel Injection (MPI)

3.5L Fuel Delivery:

Sequential Electronic Fuel Injection (SEFI)

2.4L Code:

ED7 (World Engine)

3.5L Code:

EGD (Chrysler 3.5L High Output V6)

Coolant Capacity:

Approx. 8.0 quarts (7.6 liters) with V6 / 7.3 quarts (6.9 liters) with 4-cyl

2.4L Oil Type:

SAE 5W-20

3.5L Oil Type:

SAE 5W-20

2.4L Oil Capacity:

4.5 quarts (4.3 liters)

3.5L Oil Capacity:

6.0 quarts (5.7 liters)

🔧 Transmission

2.4L Transmission:

CVT (Continuously Variable Transmission)

3.5L Transmission:

6-speed automatic (62TE)

Cvt Features:

Simulated gear shifts for a more conventional feel.

62Te Features:

Auto Stick manual shifting mode.

Cvt Fluid Type:

Mopar CVTF+4 (or equivalent)

62Te Fluid Type:

Mopar ATF+4 (or equivalent)

62Te Capacity:

Approx. 4.6 quarts (4.4 liters) for fluid change only

📐 Dimensions

Length:

192.4 inches (4887 mm)

Width:

72.5 inches (1842 mm)

Height:

66.1 inches (1679 mm)

Wheelbase:

113.8 inches (2890 mm)

Passenger Volume:

Approx. 108.5 cu ft (3072 liters)

Cargo Volume Behind 1St Row:

Approx. 68.1 cu ft (1928 liters)

Cargo Volume Behind 2Nd Row:

Approx. 39.6 cu ft (1121 liters)

Curb Weight Min:

Approx. 3900 lbs (1769 kg) for 2.4L FWD

Curb Weight Max:

Approx. 4500 lbs (2041 kg) for 3.5L AWD

Towing Capacity:

Up to 2000 lbs (907 kg) for 3.5L models.

🛡️ Safety Features

NHTSA Front Impact:

4 Stars (Driver and Passenger)

NHTSA Side Impact:

5 Stars (Front and Rear Seat)

NHTSA Rollover:

4 Stars

Stability Control:

Standard Electronic Stability Control (ESC) with Traction Control

Braking Assist:

Standard Anti-lock Braking System (ABS)

Airbags Front:

Advanced multi-stage front airbags

Airbags Side:

Front seat-mounted side airbags

Airbags Curtain:

Full-length side-curtain airbags for all rows

Seatbelts:

3-point seat belts in all seating positions, front seat belt pretensioners.

💡 Technology Features

Infotainment System:

Available Uconnect infotainment system with touchscreen, AM/FM radio, CD/MP3 player, and optional navigation.

Audio Options:

Boston Acoustics premium audio system available on higher trims.

Parking Assist:

Available ParkView Rear Back-Up Camera and rear parking assist sensors.

Tire Pressure Monitoring:

Standard Tire Pressure Monitoring System (TPMS)

Bluetooth:

Available Uconnect Bluetooth hands-free communication.

Usb:

Available USB port for media playback and device charging.

🔧 Maintenance

Oil Change Interval:

Every 6,000 to 8,000 miles (9,600 to 12,800 km) or 6 months, using synthetic oil; follow oil change indicator if equipped.

Air Filter Replacement:

Every 30,000 miles (48,000 km)

Cabin Filter Replacement:

Every 15,000 to 20,000 miles (24,000 to 32,000 km)

Spark Plug Replacement:

2.4L: 100,000 miles (160,000 km) (Long-life iridium); 3.5L: 100,000 miles (160,000 km) (Long-life iridium)

Cvt Fluid Change:

Recommended every 60,000 miles (96,000 km) or as indicated by the oil change indicator.

Automatic Transmission Fluid Change:

Recommended every 60,000 miles (96,000 km) or as indicated by the oil change indicator.

Coolant Type:

Mopar OAT (Organic Acid Technology) 5/150 Antifreeze/Engine Coolant, Pink

Brake Fluid Type:

DOT 3

Power Steering Fluid:

Mopar Power Steering Fluid or equivalent Dexron III ATF

Cvt Issues:

Some models experienced CVT judder or premature wear, particularly with inadequate fluid maintenance.

Suspension Issues:

Early models could experience worn front suspension components, particularly ball joints and control arm bushings.

HVAC Issues:

Blend door actuator failures leading to improper temperature control are not uncommon.

Engine Mounts:

Engine mount degradation can lead to increased vibration felt in the cabin.

📚 Vehicle History

Dodge Legacy:

Dodge has a long history of producing robust and functional vehicles, often with an emphasis on performance and value. The Journey aimed to leverage this by offering a practical yet stylish SUV.

Platform:

Based on the Chrysler D-segment platform, sharing components with other Chrysler and Dodge vehicles of the era.

First Generation:

The 2009 model year marked the debut of the Dodge Journey, designed to compete in the growing crossover SUV market.

Manufacturing Location:

Toluca Assembly Plant, Mexico

Production Years:

2009-2020 (North America)

🏆 Awards & Recognition

Safety Award IIHS:

Insurance Institute for Highway Safety (IIHS) Top Safety Pick ratings were generally good for this model year, though some specific ratings varied by test and year. The 2010 model received 'Good' in frontal offset and side impact tests.

Fuel Economy Epa:

2.4L FWD: Approx. 17 MPG city / 24 MPG highway; 3.5L FWD: Approx. 16 MPG city / 23 MPG highway; 3.5L AWD: Approx. 16 MPG city / 22 MPG highway.

Emission Standards:

Meets EPA emission standards for the model year.
