2010 Kawasaki Teryx 750 FI Workshop Service Repair Manual Download PDF

Regular price: $16.99
Sale price: $16.99
Regular price
Unit price: per

🏷️ Basic Information Identification Make: Kawasaki Model: Teryx 750 FI Year: 2010 Generation: First Generation 📋 Manual Details General Manual Type: Workshop Service Repair Manual Language: English Format: PDF Compatibility...

27 people are viewing this right now

Type: Utv

Vendor:

Sku: 39697

Tags: 2010 Kawasaki Powersports Teryx 750 FI Teryx Models UTV

Product variants

Description

🏷️ Basic Information

Identification

Make:

Kawasaki

Model:

Teryx 750 FI

Year:

Generation:

First Generation

📋 Manual Details

General

Manual Type:

Workshop Service Repair Manual

Language:

English

Format:

Compatibility

Compatible Os:

Windows/Max

⚙️ Engine Specifications

Engine

Engine Type:

V-twin, 4-stroke, liquid-cooled, SOHC, 4 valves per cylinder

Displacement:

749 cc

Fuel System

Fuel Delivery:

Fuel Injection (FI)

Ignition

Ignition:

Digital CDI

Cooling System

Cooling Method:

Liquid-cooled

🔧 Transmission

Drivetrain

Transmission Type:

Automatic CVT (Continuously Variable Transmission)

Drive Select:

2WD/4WD selectable with variable front differential lock

Final Drive:

Shaft drive

🔧 Maintenance

Periodic Maintenance

Oil Type:

API SG, SH, SJ or SL SAE 10W-40

Oil Capacity With Filter:

2.6 L (2.7 US qt)

Spark Plug Gap:

0.7 - 0.8 mm (0.028 - 0.031 in)

Valve Clearance Intake:

0.10 - 0.15 mm (0.0039 - 0.0059 in)

Valve Clearance Exhaust:

0.15 - 0.20 mm (0.0059 - 0.0079 in)

📄 Suspension

Front

Front Suspension Type:

Double wishbone, oil-damped, coil spring

Front Wheel Travel:

8.7 in (221 mm)

Rear Suspension Type:

Independent, Semi-trailing arm, oil-damped, coil spring

Rear Wheel Travel:

9.1 in (230 mm)

📄 Brakes

Front

Front Brake Type:

Dual hydraulic discs with 2-piston calipers

Rear Brake Type:

Dual hydraulic discs with 1-piston calipers

📄 Wheels Tires

Front

Front Tire Size:

26x8-12

Rear Tire Size:

26x11-12

📄 Electrical System

Battery

Battery Type:

12V, 14 Ah

Charging System

Charging System:

Alternator

📄 Frame

Chassis

Frame Type:

Steel, ladder-type frame
