🏷️ Basic Information

Make:

Volvo

Model:

C70

Year:

2010

Product Type:

Service & Repair Manual Software

👋 Introduction

Positioning:

The 2010 Volvo C70 is a premium compact convertible positioned in a niche market segment, competing with vehicles like the Audi A3 Cabriolet, BMW 1 Series Convertible, and Mercedes-Benz E-Class Cabriolet (though slightly smaller). It appeals to buyers seeking Scandinavian design, safety, and a refined open-top driving experience.

Key Competitors Comparison:

Compared to competitors, the C70 often offered a more stylish and unique design with its retractable hardtop. Volvo's emphasis on safety is a consistent differentiator. Performance is typically competent rather than overtly sporty.

Model Highlights:

Retractable hardtop (coupe-to-convertible functionality), advanced safety features, distinctive Volvo styling, premium interior materials, comfortable ride.

📋 Manual Details

Coverage Scope:

Comprehensive mechanical, electrical, and body repair for the 2010 Volvo C70.

Estimated Pages:

1500+

Type:

Workshop Manual / Service Manual

Language:

English

Format:

Software (likely digital archive format like PDF, HTML, or proprietary executable)

📖 Manual Coverage

Engine:

Engine mechanicals, cooling system, lubrication system, fuel system, ignition system, emission control systems.

Transmission:

Automatic transmission (AW55-50SN/AW55-51SN), clutch system, manual transmission (if applicable to specific variant).

Drivetrain:

Front-wheel drive, drive shafts, CV joints, differential.

Brakes:

Hydraulic brake system, ABS (Anti-lock Braking System), EBD (Electronic Brake-force Distribution), brake fluid, pads, rotors, calipers, parking brake.

Suspension:

Front and rear suspension components, shock absorbers, struts, springs, bushings, alignment specifications.

Steering:

Power steering system, steering rack, tie rods, steering column.

Electrical System:

Battery, charging system (alternator), starting system, lighting, fuses, relays, wiring diagrams, body control module (BCM).

Comfort Systems:

HVAC (Heating, Ventilation, and Air Conditioning), climate control, power windows, power seats, convertible roof operation.

Bodywork:

Body panel repair, convertible top mechanism, doors, windows, trim, paint repair.

Diagnostics:

OBD-II (On-Board Diagnostics) system, diagnostic trouble codes (DTCs), troubleshooting guides.

Maintenance:

Scheduled maintenance, oil changes, filter replacements, fluid checks and changes, belt inspections and replacements.

Repair:

Engine component repair, transmission overhauls, brake system repairs, suspension and steering component replacement, electrical component diagnosis and repair.

Troubleshooting:

Systematic diagnostic procedures for common and uncommon faults across all vehicle systems.

Disassembly Assembly:

Detailed step-by-step instructions for removing, disassembling, inspecting, repairing, and reassembling components.

Specifications Data:

Torque specifications, clearances, fluid capacities, wiring diagrams, component identification.

Depth:

Factory-level technical detail, suitable for professional technicians and advanced DIY enthusiasts. Covers everything from basic fluid checks to complex electronic system diagnostics and component overhauls.

📊 Manual Specifications

Format Details:

Digital software, likely including searchable text, high-resolution diagrams, and interactive elements. May require specific software to open or run.

Printability:

Designed for digital viewing; printable pages are typically available in PDF format within the software for individual sections.

Binding:

N/A (Digital Software)

Paper:

N/A (Digital Software)

⚙️ Engine Specifications

Engine Code:

B5244S4 (North America)

Engine Type:

Inline 5-cylinder, DOHC (Dual Overhead Camshaft), 20 valves

Displacement:

2.4 Liters (2435 cc)

Bore X Stroke:

83.0 mm x 90.0 mm

Compression Ratio:

10.5:1

Fuel Delivery:

Sequential Multi-Point Fuel Injection (MPI)

Engine Management:

Volvo Engine Control Module (ECM)

Horsepower:

168 hp @ 6000 rpm

Torque:

170 lb-ft @ 4500 rpm

Acceleration 0 60 Mph:

Approx. 9.1 seconds

Recommended Fuel:

Premium Unleaded Gasoline (91 Octane or higher recommended)

Fuel Tank Capacity:

15.8 gallons (60 liters)

Emissions Control:

Catalytic converter, evaporative emission control system (EVAP).

🔧 Transmission

Transmission Type:

Geartronic Automatic

Transmission Model:

AW55-50SN / AW55-51SN

Number Of Gears:

5-speed automatic

Manual Option:

Not commonly available for this model year, primarily automatic.

Geartronic Function:

Allows manual selection of gears via the shifter.

Transmission Fluid Type:

Volvo Fluid 1161540 or equivalent DEXRON-III (check manual for exact spec).

📐 Dimensions

Length:

170.4 inches (4328 mm)

Width:

70.4 inches (1788 mm)

Height:

55.7 inches (1415 mm)

Wheelbase:

103.2 inches (2620 mm)

Front Track:

60.4 inches (1534 mm)

Rear Track:

60.0 inches (1524 mm)

Front Headroom:

38.3 inches (973 mm)

Rear Headroom:

35.2 inches (894 mm)

Front Legroom:

42.0 inches (1067 mm)

Rear Legroom:

31.4 inches (798 mm)

Trunk Volume Convertible:

12.8 cubic feet (362 liters)

Trunk Volume Coupe:

7.0 cubic feet (198 liters)

Curb Weight:

Approx. 3600-3700 lbs (1630-1680 kg)

Gross Vehicle Weight Rating:

Approx. 4500 lbs (2040 kg)

Towing Capacity:

Not Recommended

Wheel Bolt Pattern:

5x108

Tire Size Standard:

215/50R17

Wheel Size Standard:

17 x 7.0 inches

🛡️ Safety Features

NHTSA Front Impact:

5 Stars (2010 Model Year)

NHTSA Side Impact:

5 Stars (2010 Model Year)

IIHS Top Safety Pick:

Yes (for models equipped with optional front crash prevention)

ABS:

Standard Anti-lock Braking System

Traction Control:

Standard Electronic Traction Control (ETC) / Stability Traction Control (STC)

Esp:

Standard Electronic Stability Control (ESC) / Dynamic Stability and Traction Control (DSTC)

Brake Assist:

Standard Emergency Brake Assist (EBA)

Airbags:

Front airbags, side-impact airbags (integrated into seats), Inflatable Curtain (IC) airbags (deploy from roof trim), Roll Over Protection System (ROPS).

Seatbelts:

Pretensioning seatbelts with force limiters.

Convertible Top Safety:

Integrated rollover protection system (ROPS) with pop-up rollover hoops.

💡 Technology Features

Audio System:

Optional premium sound systems by Dynaudio. Standard 6-speaker or optional 10-speaker configurations. SIRIUS satellite radio integration.

Navigation:

Optional integrated navigation system with DVD-ROM or HDD-based maps.

Climate Control:

Electronic Climate Control (ECC) with dual-zone temperature control.

Parking Assist:

Optional rear park assist sensors.

Cruise Control:

Standard cruise control, optional Adaptive Cruise Control (ACC) on some later models (less common for 2010).

Headlights:

Standard halogen headlights, optional Bi-Xenon headlights with Active Bending Lights (ABL).

Bluetooth:

Optional Bluetooth hands-free connectivity for phone calls.

Aux Input:

Standard auxiliary audio input jack.

🔧 Maintenance

Oil Change Interval:

Every 7,500-10,000 miles (12,000-16,000 km) or annually, whichever comes first, depending on driving conditions (refer to manual).

Air Filter Replacement:

Every 30,000 miles (48,000 km) or as needed based on driving environment.

Cabin Air Filter Replacement:

Every 15,000-20,000 miles (24,000-32,000 km) or annually.

Spark Plug Replacement:

Every 60,000 miles (96,000 km).

Timing Belt Replacement:

Not applicable (this engine uses a timing chain).

Transmission Fluid Change:

Recommended every 50,000-70,000 miles (80,000-112,000 km), though Volvo often lists as 'lifetime' (fluid exchange is recommended).

Engine Oil Type:

Synthetic 0W-30 API SN, ACEA A5/B5. (e.g., Castrol Edge Professional OE 0W-30)

Engine Oil Capacity:

6.4 US quarts (6.1 liters) with filter change.

Coolant Type:

Volvo's long-life coolant (Green) or equivalent meeting Volvo VCS spec (e.g., Havoline Dex-Cool Extended Life)

Brake Fluid Type:

DOT 4

Power Steering Fluid:

Volvo Power Steering Fluid or equivalent DEXRON-III compatible fluid.

Convertible Top Mechanism:

Potential issues with hydraulic pump, cylinders, and microswitches causing operation faults. Leaks can occur if seals degrade.

Electronic Modules:

Occasional issues with Body Control Module (BCM) or other electronic modules leading to various system malfunctions.

Power Steering Pump:

Can develop leaks or whining noise over time.

Oxygen Sensors:

Can fail, leading to check engine lights and poor fuel economy.

Pcv System:

Clogged PCV (Positive Crankcase Ventilation) system can lead to oil leaks and internal engine pressure issues.

📚 Vehicle History

Volvo Safety Philosophy:

Volvo has a long-standing reputation for safety innovation, dating back to the introduction of the three-point seatbelt. This commitment is evident in all Volvo models, including the C70.

C70 Generations:

The 2010 C70 is part of the second generation (2006-2013), which replaced the first-generation C70 (1997-2006). The second generation notably features a three-piece retractable hardtop instead of the first generation's fabric softtop.

Manufacturing Location:

Uddevalla, Sweden

Production Years:

Second generation: 2006-2013

🏆 Awards & Recognition

IIHS Award:

The 2010 C70 was recognized as an IIHS Top Safety Pick by the U.S. Insurance Institute for Highway Safety, reflecting its strong performance in crash testing.
