Segment:
Mid-size pickup truck
Competitors:
Toyota Hilux, Ford Ranger, Mitsubishi Triton, Nissan Navara, Isuzu D-Max
Vehicle Strengths:
Robust construction, capable off-road performance, strong towing capacity, availability of various body styles (single cab, dual cab, space cab) and powertrains.
Value Proposition:
Enables owners to perform routine maintenance and complex repairs, saving significant costs on labor at dealerships or independent workshops. Provides the knowledge to keep the vehicle in optimal condition.
Applicable Years:
2012, 2013, 2014, 2015, 2016, 2017
Models Covered:
All Chevrolet Colorado and Holden Colorado models, all engines, all trim levels, all transmission types
Estimated Pages:
Thousands (Exact count varies with digital format, but implies comprehensive coverage)
Type:
Workshop Service Repair Manual
Format:
Digital Download (PDF)
Powertrain:
Engine mechanical, fuel system, ignition system, exhaust system, cooling system, lubrication system, engine control systems (ECU/ECM), transmission (manual and automatic), drivetrain (driveshafts, differentials, axles).
Chassis:
Suspension (front and rear), steering system, braking system (ABS, discs, drums), wheels and tires.
Electrical:
Body electrical systems, lighting, instruments, infotainment, power windows, locks, mirrors, charging system (battery, alternator), starting system, fuses, relays, wiring diagrams.
Body:
Body panels, doors, windows, seats, interior trim, exterior trim, HVAC (heating, ventilation, air conditioning), collision repair, structural components.
Maintenance:
Scheduled maintenance, fluid changes (oil, coolant, brake fluid, transmission fluid), filter replacements, lubrication, inspections.
Diagnostics:
Troubleshooting guides, diagnostic trouble codes (DTCs), symptom-based diagnostics, electrical system diagnostics, mechanical system diagnostics.
Repair:
Step-by-step repair instructions for all major and minor components, engine overhaul, transmission overhaul, brake caliper replacement, suspension component replacement, body panel repair.
Installation:
Instructions for component installation and replacement.
Depth:
Comprehensive (A-Z coverage), suitable for DIY enthusiasts and professional technicians. Includes detailed exploded views, torque specifications, and diagnostic procedures.
Quality:
High quality, with clear images and diagrams.
Binding:
Not applicable (Digital Download)
Paper:
Not applicable (Digital Download)
Required Software:
Adobe Reader (or compatible PDF reader)
Engine Family North America:
GM LLM (2.8L Duramax Turbo-Diesel), GM Atlas (2.5L Ecotec, 2.4L Ecotec)
Engine Family Global:
Isuzu 4J series (e.g., 4JJ1-TC 3.0L Turbo-Diesel, 4JK1-TC 2.5L Turbo-Diesel)
2.8L Duramax Turbo-Diesel (Lwn) Output:
Approximately 181 hp (135 kW) and 369 lb-ft (500 Nm) of torque (varies by region and specific tune).
3.0L Isuzu Turbo-Diesel Output:
Approximately 174 hp (130 kW) and 369 lb-ft (500 Nm) of torque (varies by region and specific tune).
2.5L Isuzu Turbo-Diesel Output:
Approximately 150 hp (112 kW) and 258 lb-ft (350 Nm) of torque (varies by region and specific tune).
Injection Type:
Common Rail Direct Injection (CRDI) for diesel engines; Port Fuel Injection (PFI) for gasoline engines.
Emission Controls:
Diesel Particulate Filter (DPF), Selective Catalytic Reduction (SCR) systems (depending on market and model year).
Manual Transmission:
6-speed manual transmission (e.g., MGT-6 for Isuzu-derived models, similar GM designs for North America).
Automatic Transmission:
6-speed automatic transmission (e.g., 6L50 for North American models, Aisin derivatives for global models).
Drivetrain Options:
Rear-wheel drive (RWD) and 4-wheel drive (4WD) with selectable or full-time systems.
Automatic Transmission Fluid Spec:
Dexron VI (for GM transmissions), or specific Aisin/Isuzu specifications as detailed in the manual.
Manual Transmission Fluid Spec:
API GL-4 or GL-5 gear oil, specific viscosity (e.g., 75W-90) as per manufacturer recommendation.
Body Styles:
Single Cab, Extended Cab (Space Cab), Crew Cab (Dual Cab)
Wheelbase Range:
Varies by body style and region, typically from approx. 3096 mm to 3645 mm.
Bed Length Range:
Varies by body style and region, typically from approx. 1530 mm to 2230 mm.
Max Towing Capacity:
Up to 3,500 kg (7,700 lbs) in many configurations, depending on engine, drivetrain, and market regulations.
Payload Capacity:
Varies significantly, often in the range of 800 kg to 1,200 kg (1,760 lbs to 2,650 lbs).
Ancap Rating:
Varies by year and specific model tested, often achieving 4 or 5 stars (Australasian New Car Assessment Program).
Braking Systems:
Anti-lock Braking System (ABS), Electronic Brake-force Distribution (EBD), Brake Assist (BA).
Stability Control:
Electronic Stability Control (ESC), Traction Control System (TCS), Hill Descent Control (HDC), Trailer Sway Control (TSC) - availability varies by trim and market.
Airbags:
Front airbags for driver and passenger, optional side-impact airbags and curtain airbags.
Infotainment System:
Chevrolet MyLink or Holden MyLink infotainment system with touchscreen display, Bluetooth connectivity, USB ports, and optional navigation. Features varied by trim level and market.
Assistance Features:
Rearview camera, parking sensors (availability varies), Hill Start Assist (HSA).
Connectivity Options:
USB ports, auxiliary input, Bluetooth for hands-free calling and audio streaming.
Engine Oil Change:
Typically every 10,000 - 15,000 km (6,000 - 10,000 miles) or 6-12 months, depending on usage and engine type. Check manual for specific recommendations.
Transmission Fluid Change:
Automatic: every 60,000 - 100,000 km (37,000 - 60,000 miles). Manual: inspection advised, replacement typically at higher mileages or if issues arise.
Engine Oil Spec Diesel:
API CJ-4 or CK-4, SAE 5W-30 or 15W-40 (specific viscosity depends on climate and engine variant). Refer to manual for exact specification and capacity.
Engine Oil Spec Gasoline:
API SN/SP, SAE 5W-20 or 5W-30 (specific viscosity depends on engine variant and climate). Refer to manual for exact specification and capacity.
Coolant Spec:
GM 6277M (blue), or equivalent OAT (Organic Acid Technology) coolant. Capacity around 9-10 liters for diesel models.
Brake Fluid Spec:
DOT 3 or DOT 4.
Common Problems:
Potential for DPF regeneration issues in diesel models under specific driving conditions, EGR valve problems, possible injector issues with high-sulfur fuel (less common with modern fuels), water pump leaks, and some electrical gremlins. Manual provides detailed diagnostic procedures for these.
Manufacturer Origin:
Chevrolet (USA), Holden (Australia, historically rebadged GM vehicles)
Generation:
This manual covers the second generation of the global Chevrolet Colorado/Holden Colorado platform (RG series), which replaced the previous Holden Rodeo/Chevrolet Colorado (TF series).
Manufacturing Locations:
Thailand (primary global production), United States (for North American market).
