Segment:
Cruiser Motorcycle
Target Audience:
Harley-Davidson owners seeking to perform their own maintenance and repairs, DIY enthusiasts
Competitors:
Other cruiser brands (e.g., Indian, some Japanese models) but specifically targeting Harley-Davidson owners.
Value Proposition:
Cost savings on maintenance and repairs, comprehensive coverage, accessibility for DIY mechanics.
Manual Advantage:
Includes owner's guide, parts catalog, and detailed workshop procedures in a single, integrated set.
Primary Coverage:
Owner's Information, Parts Catalog, Workshop Service and Repair Procedures
Estimated Total Pages:
High (Specific count not provided, but indicated as comprehensive A-Z)
Type:
Combined Owner's, Parts, and Service/Repair Manual Set
Format:
Digital Downloadable (PDF)
Engine:
Twin Cam 103B, fuel injection (EFI), ignition, lubrication, cooling (air-cooled)
Transmission:
6-speed Cruise Drive, clutch, primary drive, final drive (belt)
Chassis:
Frame, front suspension (forks), rear suspension (shocks), steering, wheels, brakes (front and rear disc)
Electrical:
Battery, charging system (alternator, regulator), starting system, lighting, instrumentation, ignition system, security system
Bodywork:
Fuel tank, fenders, seat, handlebars, controls, mirrors, exhaust system
Maintenance:
Scheduled maintenance, oil changes, filter replacements, spark plug service, brake fluid flush, drive belt inspection/adjustment
Repair:
Engine teardown and reassembly, transmission overhaul, suspension repair, brake system service, electrical component troubleshooting and replacement
Troubleshooting:
Diagnostic procedures for common and uncommon issues, symptom-based fault finding
Parts Identification:
Detailed diagrams and part numbers for all components
Depth:
Comprehensive: Covers basic maintenance to full engine and transmission rebuilds. Includes diagnostic trouble codes (DTCs) and repair strategies.
Format:
Portable Document Format (PDF)
Quality:
High-resolution for clear text and images, printable
Binding:
N/A (Digital format)
Paper Type:
N/A (Digital format)
Software Requirements:
Adobe Reader (free, widely available)
Delivery Method:
Instant Email Delivery upon Payment Confirmation
Engine Type:
Air-cooled, 45-degree V-twin, Twin Cam 103B
Bore X Stroke:
3.875 in. x 4.375 in. (98.4 mm x 111.1 mm)
Displacement:
103 cu. in. (1690 cc)
Torque:
Approx. 99.0 ft-lb @ 3,500 rpm (134 Nm @ 3,500 rpm) - may vary slightly by year
Fuel Delivery:
Electronic Sequential Port Fuel Injection (ESPFI)
Ignition System:
Dual spark plug, crank-position sensor ignition
Oil System:
Dry-sump, gear-driven oil pump
Type:
6-speed Cruise Drive
Primary Drive:
Clutch, chain drive to transmission
Final Drive:
Belt drive, 1748-tooth, 130-tooth rear pulley
Gear Ratios:
1st: 9.593, 2nd: 6.650, 3rd: 4.938, 4th: 3.818, 5th: 3.160, 6th: 2.790
Transmission Fluid:
Harley-Davidson Formula + Transmission and Primary Chaincase Lubricant or equivalent
Wheelbase:
Approx. 64.2 in. (1630 mm)
Length:
Approx. 96.2 in. (2445 mm)
Width:
Approx. 33.5 in. (851 mm)
Height:
Approx. 46.1 in. (1171 mm)
Dry Weight:
Approx. 669 lbs (303 kg)
Gross Vehicle Weight Rating:
Approx. 1180 lbs (535 kg)
Brakes:
Dual front 4-piston calipers, single rear 4-piston caliper, dual hydraulic disc brakes
ABS:
Optional (ABS availability may vary by market and specific trim)
Lighting:
Halogen headlight, LED tail light, LED turn signals
Security:
Factory-installed H-D Smart Security System with key fob
Instrumentation:
Analog tachometer, digital speedometer, gear indicator, fuel gauge, clock, trip meter, diagnostic indicators.
ABS:
Anti-lock Braking System available as an option.
Security System:
Integrated keyless fob security system.
First Service:
Typically at 1,000 miles (1,600 km) - includes engine oil and filter change, primary chain adjustment, inspection of all systems.
Subsequent Service:
Generally every 5,000 miles (8,000 km) or annually, whichever comes first, for oil changes and inspections. More detailed services at larger intervals.
Engine Oil:
Harley-Davidson 20W-50 SYN3 Full Synthetic Motorcycle Oil or equivalent.
Engine Oil Capacity:
Approx. 4.0 US quarts (3.8 Liters) with filter change.
Primary Chaincase Oil:
Harley-Davidson Formula + Transmission and Primary Chaincase Lubricant or equivalent.
Primary Chaincase Capacity:
Approx. 1.0 US quart (0.95 Liters)
Brake Fluid:
DOT 4 Hydraulic Brake Fluid
Common Wear Items:
Drive belt, tires (especially the wide rear tire due to riding style), brake pads, clutch plates.
Potential Electrical:
Wiring harness integrity, voltage regulator concerns (more common on earlier Twin Cam models, but covered in diagnostics).
Engine Temperatures:
Air-cooled engines can run hot in slow traffic or extreme heat; proper maintenance is key.
Heritage:
Harley-Davidson, founded in 1903, renowned for its V-twin motorcycles and cruiser culture.
Introduction Year:
The Breakout model was introduced in 2013.
Key Design:
Characterized by its long, low stance, wide rear tire (240mm), Gasser-style cast aluminum wheels, and aggressive styling.
Manufacturing Location:
United States (York, Pennsylvania and Milwaukee, Wisconsin)
