🏷️ Basic Information

Make:

Dodge

Model:

Journey

Year:

2015

Product Type:

Complete Workshop Service Repair Manual

👋 Introduction

Vehicle Segment:

Mid-size Crossover SUV / Minivan (often referred to as a 'CUV')

Key Selling Points:

Versatile seating (available 7-seater), practicality, affordability, comfortable ride

Competitors 2015:

Toyota Sienna, Honda Odyssey, Kia Sedona, Chevrolet Traverse, Ford Explorer, Nissan Quest

Flexible Seating:

Available 5 or 7-passenger configurations with Stow 'n Go® seating (on select trims)

Cargo Space:

Ample cargo capacity, especially with second and third rows folded

Powertrain Options:

Choice between fuel-efficient four-cylinder and powerful V6 engines

📋 Manual Details

Comprehensive Coverage:

All mechanical, electrical, diagnostic, and maintenance procedures

Estimated Pages:

1500+

Type:

Factory Service Manual (FSM)

Language:

English

Format:

Digital (PDF)

📖 Manual Coverage

Engine Mechanical:

3.6L Pentastar V6, 2.4L Tigershark I4; Engine assembly, disassembly, cylinder head, block, crankshaft, camshaft, timing, lubrication, cooling, fuel, ignition, exhaust, emission controls, starting, charging

Transmission Mechanical:

6-Speed Automatic (62TE); Overhaul, torque converter, valve body, internal components, fluid service

Drivetrain:

Front Wheel Drive (FWD), All Wheel Drive (AWD) options; Axles, driveshafts, CV joints, differentials, transfer case (AWD)

Suspension Steering:

Front independent suspension (MacPherson struts), Rear independent suspension (Multi-link); Springs, shocks, struts, control arms, ball joints, bushings, steering rack, power steering system, wheel alignment specifications

Brakes:

Front vented discs, Rear solid discs; ABS, EBD, Brake pedal, master cylinder, brake lines, calipers, pads, rotors, parking brake

Electrical Body:

Battery, charging system, starting system, lighting (headlights, taillights, interior), instrumentation, dashboard, power windows, locks, mirrors, seats, wipers, horns, power distribution, wiring diagrams

Climate Control:

HVAC system, A/C compressor, refrigerant, heater core, blower motor, climate control modules, actuators

Safety Restraints:

Airbag system, SRS modules, sensors, seatbelt pre-tensioners, occupant classification system

Maintenance Procedures:

Oil change, filter replacement, fluid checks and top-offs, tire rotation, brake pad inspection, spark plug replacement, belt inspection/replacement, battery testing

Repair Procedures:

Engine component replacement, transmission overhaul, suspension component replacement, brake system repair, electrical component diagnosis and replacement, body panel repair, interior trim removal/installation

Diagnostic Procedures:

Troubleshooting guides, fault code interpretation (OBD-II), component testing, circuit diagnosis, flowcharts

Technical Specifications:

Torque specifications, clearances, measurements, fluid capacities, electrical resistance values, diagnostic parameters

Depth:

Comprehensive from basic maintenance to full engine and transmission rebuilds, including advanced electrical diagnostics and bodywork

📊 Manual Specifications

Digital Format:

PDF (Portable Document Format)

Searchability:

Fully searchable text content for quick information retrieval

Image Quality:

High-resolution diagrams, schematics, and photographs

Binding:

N/A (Digital Format)

Paper Type:

N/A (Digital Format)

⚙️ Engine Specifications

Engine 1:

2.4L Tigershark (KCA) Inline-4

Engine 1 Displacement:

2360 cc (2.36 Liters)

Engine 1 Horsepower:

173 hp @ 6000 rpm

Engine 1 Torque:

166 lb-ft @ 4400 rpm

Engine 1 Fuel Type:

Regular Unleaded Gasoline

Engine 1 Compression Ratio:

10.1:1

Engine 1 Bore X Stroke:

88 mm x 97 mm

Engine 1 Engine Code:

KCA

Engine 2:

3.6L Pentastar V6

Engine 2 Displacement:

3604 cc (3.6 Liters)

Engine 2 Horsepower:

283 hp @ 6400 rpm

Engine 2 Torque:

260 lb-ft @ 4400 rpm

Engine 2 Fuel Type:

Regular Unleaded Gasoline

Engine 2 Compression Ratio:

10.2:1

Engine 2 Bore X Stroke:

96 mm x 83.3 mm

Engine 2 Engine Code:

PENTASTAR

Fuel Delivery:

Multi-port Fuel Injection (MPI)

Fuel Tank Capacity:

20.5 US gallons (77.6 Liters)

🔧 Transmission

Transmission Type:

6-Speed Automatic (62TE)

Transmission Fluid Spec:

ATF+4 (Mopar)

Transmission Fluid Capacity:

Approx. 6.9 US quarts (6.5 Liters) for dry fill

Drivetrain Options:

Front-Wheel Drive (FWD), All-Wheel Drive (AWD)

Transmission Features:

AutoStick® manual shifting capability

📐 Dimensions

Length:

188.8 inches (4795 mm)

Width:

72.5 inches (1841 mm)

Height:

66.5 inches (1689 mm)

Wheelbase:

113.8 inches (2890 mm)

Ground Clearance:

Approx. 7.2 inches (183 mm)

Cargo Volume Behind 3Rd Row:

Approx. 35.4 cubic feet (1002 Liters)

Cargo Volume Behind 2Nd Row:

Approx. 67.0 cubic feet (1897 Liters)

Cargo Volume Behind 1St Row:

Approx. 100.2 cubic feet (2837 Liters)

Curb Weight Min:

Approx. 3880 lbs (1760 kg) for 2.4L FWD

Curb Weight Max:

Approx. 4440 lbs (2014 kg) for 3.6L AWD

Towing Capacity:

Up to 2,000 lbs (907 kg) when properly equipped (3.6L V6 engine required)

🛡️ Safety Features

NHTSA Overall Rating:

4 out of 5 stars (model year dependent, check specific reports)

IIHS Rating:

Good in most categories (check specific year/trim for TOP SAFETY PICK designation)

Traction Control:

Yes (TCS)

Electronic Stability Control:

Yes (ESC)

Anti Lock Brakes:

Yes (ABS)

Electronic Brake Force Distribution:

Yes (EBD)

Brake Assist:

Yes (BAS)

Airbags:

Front airbags, Side curtain airbags (all rows), Front seat-mounted side airbags

Child Seat Anchors:

LATCH (Lower Anchors and Tethers for Children) system

Seatbelts:

3-point seatbelts with pretensioners and load limiters

💡 Technology Features

Infotainment System Available:

Uconnect® system with touchscreens (e.g., 8.4-inch)

Infotainment Features:

AM/FM radio, CD/DVD player, MP3 capability, SiriusXM Satellite Radio, USB/Auxiliary input

Available Driver Assistance:

Backup camera, ParkView® Rear Back Up Camera, ParkSense® Rear Park Assist System

Connectivity Options:

Bluetooth® streaming audio and hands-free calling, available navigation system, available Wi-Fi hotspot.

🔧 Maintenance

Oil Change Interval:

Every 10,000 miles (16,000 km) or 12 months (using synthetic oil), whichever comes first. Severe service may require shorter intervals.

Engine Air Filter Replacement:

Inspect every 15,000 miles (24,000 km), replace as needed or every 30,000 miles (48,000 km).

Cabin Air Filter Replacement:

Inspect every 15,000 miles (24,000 km), replace as needed or every 20,000 miles (32,000 km).

Spark Plug Replacement 2.4L:

Replace every 100,000 miles (160,000 km) (GDI specific plugs)

Spark Plug Replacement 3.6L:

Replace every 100,000 miles (160,000 km) (Iridium plugs)

Transmission Fluid Change Interval:

Every 60,000 miles (96,000 km) or as indicated by the transmission oil change indicator.

Coolant Replacement:

Initial change at 100,000 miles (160,000 km) or 5 years, then every 60,000 miles (96,000 km) or 5 years.

Engine Oil Type 2.4L:

SAE 0W-20 Synthetic (MS-6395)

Engine Oil Type 3.6L:

SAE 0W-20 Synthetic (MS-6395)

Coolant Type:

OAT (Organic Additive Technology) HOAT, Mopar ANTIFREEZE/COOLANT (MS-9769) or equivalent purple coolant

Common Complaints Powertrain:

Transmission shift issues (especially 62TE), potential for intake manifold leaks on Pentastar V6, oil leaks (valve cover gaskets).

Common Complaints Suspension Steering:

Worn suspension components (struts, ball joints), power steering fluid leaks.

Common Complaints Electrical:

HVAC blower motor failures, power window motor failures, CAN bus communication errors.

Common Complaints Body Interior:

Rattles and squeaks, wear on interior trim, issues with Stow 'n Go seat mechanisms.

📚 Vehicle History

Dodge Heritage:

Dodge, a division of Chrysler (now Stellantis), has a long history of producing durable and powerful vehicles, often with a focus on performance and utility.

First Generation Start:

2009

Major Refresh 2011:

Significant interior and exterior redesign, introduction of Pentastar V6 engine.

Mid-Cycle Updates 2015:

Introduction of the 2.4L Tigershark engine, minor feature upgrades.

Production Plant:

Belvidere Assembly Plant, Belvidere, Illinois, USA

Production Years Generation:

2009-2020

🏆 Awards & Recognition

Parent Company Awards:

Stellantis (formerly Fiat Chrysler Automobiles) and its brands, including Dodge, have historically received various industry accolades for design, safety, and value.

Consumer Reports Ratings:

Variable depending on model year and specific components. Often cited for practicality but with mixed reliability scores in certain areas.

Certification Standards:

Adheres to all relevant SAE, ISO, and automotive industry standards for repair and maintenance procedures.
