🏷️ Basic Information

Make:

GMC

Model:

Terrain

Model Years Covered:

2016, 2017

Generation Identifier:

First Generation (2010-2017)

Platform Code:

GM Theta Platform

👋 Introduction

Segment:

Compact Crossover SUV

Target Audience:

DIY enthusiasts, independent repair shops, fleet maintenance.

Key Competitors 2016 2017:

Honda CR-V, Toyota RAV4, Ford Escape, Mazda CX-5, Nissan Rogue, Subaru Forester.

Unique Selling Proposition Of Manual:

Enables users to perform their own repairs, saving significant costs compared to dealership service. Offers step-by-step guidance with illustrations for ease of use.

Vehicle Appeal:

Known for its distinctive styling, comfortable interior, and available all-wheel drive system.

📋 Manual Details

Vehicle Variants Covered:

All Models, Engines, Trim Levels, and Transmission Types

Estimated Page Count:

Extensive (Specific number not provided, but implied to be comprehensive A-Z)

Type:

Complete Workshop Service Repair Manual

Language:

English

Delivery Format:

Downloadable Digital File

Compatible Devices:

All PC & MAC Computers, Tablets, Mobile Phones

Required Software:

Adobe Reader (Free Download)

📖 Manual Coverage

Powertrain:

Engine mechanical, cooling system, fuel system, exhaust system, engine control systems (ECM), transmission mechanical, transmission control systems (TCM).

Chassis:

Front suspension, rear suspension, steering system, brake system (ABS, ESC included), wheel alignment specifications.

Electrical:

Battery, charging system, starting system, lighting, instrumentation, body control modules (BCM), infotainment system wiring, power distribution, diagnostic connectors (OBD-II).

Body:

Exterior body panels, interior trim, doors, windows, seats, roof system, HVAC system, body sealing, structural components.

Maintenance:

Oil and filter changes, fluid checks and top-offs, tire rotation, brake pad inspection, belt inspection/replacement, spark plug replacement, air filter replacement.

Repair:

Engine component replacement (e.g., alternator, starter, water pump), brake caliper replacement, suspension component replacement (e.g., struts, ball joints), exhaust system repair, window regulator replacement, door handle replacement.

Diagnostics:

Troubleshooting common faults, diagnostic trouble codes (DTCs) interpretation and resolution, circuit testing, component testing procedures.

Troubleshooting:

Step-by-step troubleshooting guides for various systems and symptoms, electrical schematic interpretation.

Depth:

Comprehensive: Covers basic maintenance to advanced engine and transmission rebuilds, including diagnostic procedures and electrical system fault finding.

Visuals:

Includes step-by-step instructions with pictures, enhancing clarity for repair tasks.

📊 Manual Specifications

Format:

PDF (Portable Document Format)

Searchability:

Likely searchable text content for quick navigation to specific topics.

Printable:

Yes, printable by page, chapter, or entire document.

Binding:

N/A (Digital Download)

Paper Quality:

N/A (Digital Download)

⚙️ Engine Specifications

Engine Option 1:

2.4L Ecotec Inline-4 (LAF)

Displacement 2.4L:

2384 cc (145.5 cu in)

Bore X Stroke 2.4L:

88.0 mm x 98.0 mm (3.46 in x 3.86 in)

Compression Ratio 2.4L:

10.3:1

Horsepower 2.4L:

182 hp @ 6700 rpm (approx.)

Torque 2.4L:

172 lb-ft @ 4400 rpm (approx.)

Engine Option 2:

3.6L V6 (LFX) - Optional on certain trims

Displacement 3.6L:

3649 cc (222.7 cu in)

Bore X Stroke 3.6L:

94.0 mm x 85.6 mm (3.70 in x 3.37 in)

Compression Ratio 3.6L:

11.3:1

Horsepower 3.6L:

301 hp @ 6500 rpm (approx.)

Torque 3.6L:

272 lb-ft @ 4800 rpm (approx.)

Fuel Delivery:

Sequential Port Fuel Injection (PFI)

Recommended Fuel:

87 Octane Regular Unleaded Gasoline

Emissions Certification:

Tier 2 Bin 5 (EPA) / LEV II (CARB) in California-emissions states

🔧 Transmission

Transmission Type Standard:

6-speed Automatic (M3U for 2.4L)

Transmission Type Optional:

6-speed Automatic (MH9 for 3.6L V6)

Drive Type Options:

Front-Wheel Drive (FWD) or Available All-Wheel Drive (AWD)

Transmission Fluid Type:

Dexron-VI Automatic Transmission Fluid (ATF)

Transmission Fluid Capacity 2.4L:

Approximately 8.5 quarts (8.0 Liters) for 2WD, 9.3 quarts (8.8 Liters) for AWD

Transmission Fluid Capacity 3.6L:

Approximately 9.3 quarts (8.8 Liters) for AWD

📐 Dimensions

Length:

179.1 inches (4550 mm)

Width:

72.8 inches (1849 mm)

Height:

65.3 inches (1659 mm)

Wheelbase:

107.6 inches (2733 mm)

Curb Weight 2.4L FWD:

Approximately 3530 lbs (1601 kg)

Curb Weight 2.4L AWD:

Approximately 3715 lbs (1685 kg)

Curb Weight 3.6L AWD:

Approximately 3913 lbs (1775 kg)

Cargo Volume Behind 2Nd Row:

31.4 cu ft (889 liters)

Cargo Volume With 2Nd Row Folded:

63.3 cu ft (1792 liters)

🛡️ Safety Features

NHTSA Overall Rating 2016:

4 out of 5 stars (Overall Safety Rating)

IIHS Top Safety Pick:

Good ratings in most IIHS tests for these model years, potential for Top Safety Pick designation depending on specific equipment and year.

Active Safety Systems:

Anti-lock Braking System (ABS), Traction Control System (TCS), Electronic Stability Control (ESC), Available All-Wheel Drive (AWD).

Airbags:

Frontal airbags (driver and passenger), front side-impact airbags, roof rail airbags (side curtain for front and rear occupants).

Seat Belts:

3-point seat belts with pretensioners and load limiters.

💡 Technology Features

Infotainment System:

GMC IntelliLink system with touch screen interface (sizes varied by trim, typically 7-inch or 8-inch).

Features Included:

Bluetooth connectivity for phone and audio streaming, USB ports, auxiliary input jack, optional navigation system, Pandora and Stitcher app integration.

Available Features:

Rearview camera, available Forward Collision Alert, Lane Departure Warning, Side Blind Zone Alert, Rear Cross-Traffic Alert (often bundled in packages).

Onboard Diagnostics:

OBD-II compliant, providing access to vehicle diagnostic data via the diagnostic connector.

🔧 Maintenance

Oil Change Interval:

7,500 miles (12,000 km) or 12 months, whichever comes first (using synthetic oil).

Engine Air Filter:

Inspect every 15,000 miles (24,000 km), replace as needed or every 45,000 miles (72,000 km).

Cabin Air Filter:

Replace every 15,000 miles (24,000 km) or annually.

Spark Plugs 2.4L:

Replace every 97,500 miles (157,000 km).

Transmission Fluid Change:

Under normal driving conditions, no scheduled fluid change is recommended by GM. However, severe driving conditions may necessitate changes every 45,000-90,000 miles. The manual will provide detailed guidance.

Engine Oil Type:

SAE 0W-20 Full Synthetic (for both 2.4L and 3.6L engines)

Engine Oil Capacity 2.4L:

Approximately 4.8 quarts (4.5 Liters) with filter change.

Engine Oil Capacity 3.6L:

Approximately 5.5 quarts (5.2 Liters) with filter change.

Coolant Type:

GM Dex-Cool (Orange, Extended Life) - silicate and borate-free, P-OAT (Phosphate Organic Acid Technology) coolant.

Coolant Capacity:

Approximately 7.6 quarts (7.2 Liters) for 2.4L, 9.2 quarts (8.7 Liters) for 3.6L.

Common Complaints:

Potential for minor oil leaks from valve cover or oil pan, occasional transmission shifting concerns, HVAC system issues (blend door actuators), early generation torque converter issues (addressed in later models/updates).

Diagnostic Aid:

The manual's detailed troubleshooting sections are invaluable for diagnosing and rectifying these common issues.

📚 Vehicle History

Gm Crossover Lineage:

Part of General Motors' extensive SUV and crossover portfolio, building on platforms shared with other GM brands like Chevrolet (Equinox).

Generation Focus:

This manual covers the latter part of the first generation (2010-2017), which received a significant mid-cycle refresh for the 2013 model year.

Assembly Location:

Cami Automotive in Ingersoll, Ontario, Canada.

🏆 Awards & Recognition

Previous Model Awards:

While specific awards for the 2016-2017 models are not detailed in the product info, earlier versions of the Terrain received recognition for styling and value.

Dependability Ratings:

Generally average to above-average dependability ratings from sources like J.D. Power for this generation, though specific year variations exist.
