🏷️ Basic Information

Make:

Infiniti

Model:

QX60 Hybrid

Model Code:

L50

Year:

2018

Chassis Code:

L50

👋 Introduction

Segment:

Mid-size Luxury Crossover SUV

Target Audience:

Families seeking luxury, comfort, practicality, and advanced hybrid technology

Key Competitors:

Acura MDX Sport Hybrid, Lexus RX 450h, BMW X5 xDrive40e (when applicable)

Hybrid Powertrain:

Combination of a gasoline engine and electric motors for improved fuel efficiency and performance

Luxury Appointments:

Premium interior materials, advanced comfort features, sophisticated design

Practicality:

Three-row seating, ample cargo space, versatile interior configuration

Advanced Technology:

Infotainment systems, driver-assistance features, connectivity options

📋 Manual Details

Primary Coverage:

Maintenance, Repair, Diagnostics, Wiring Diagrams

Secondary Coverage:

Troubleshooting, Specifications, Technical Data

Estimated Page Count:

Likely over 1000 pages (typical for comprehensive service manuals)

Manual Type:

Workshop Service and Repair Manual with Wiring Diagrams

Language:

English

Format:

PDF

📖 Manual Coverage

Engine Mechanical:

Complete overhaul, timing, cooling, lubrication, fuel delivery (internal combustion engine componentry)

Hybrid Powertrain:

Hybrid control system, electric motor, battery management, regenerative braking, power control unit

Transmission Drivetrain:

Continuously Variable Transmission (CVT) operation, maintenance, and repair, differential, axles, AWD system

Brakes:

Hydraulic system, ABS, EBD, VDC, brake pad/rotor replacement, bleeding procedures

Suspension Steering:

Front and rear suspension components, steering system, power steering, alignment specifications

Electrical Electronics:

Complete vehicle wiring diagrams, ECU functions, sensors, actuators, lighting, power windows, seats, etc.

HVAC:

Air conditioning system, heating, ventilation, climate control module

Body Interior Exterior:

Body panel removal/installation, door mechanisms, interior trim, seating systems, body seals

Safety Restraints:

Airbag system, seat belts, SRS module diagnostics and replacement

Diagnostics:

OBD-II codes, diagnostic trouble codes (DTCs), guided troubleshooting flowcharts

Routine Maintenance:

Oil changes, filter replacements, fluid checks and top-offs, tire rotation

Engine Repair:

Component replacement (e.g., spark plugs, ignition coils, fuel injectors), head gasket repair, internal engine component overhaul

Hybrid Component Service:

High-voltage battery diagnostics, electric motor assembly service, inverter repair

Transmission Service:

CVT fluid replacement, solenoid replacement, valve body diagnosis and repair

Brake System Service:

Brake caliper, rotor, and pad replacement, brake fluid flush and bleed

Suspension Steering Repair:

Shock absorber/strut replacement, ball joint replacement, power steering pump/rack replacement

Electrical Troubleshooting:

Wiring harness repair, component testing, circuit diagnosis using wiring diagrams

Climate Control Repair:

AC compressor replacement, refrigerant recharge, blower motor replacement

Body Panel Replacement:

Fender, hood, door, bumper cover replacement and alignment

Airbag System Service:

SRS component replacement, airbag module calibration

Diagnostic Troubleshooting:

Step-by-step diagnostic procedures for common and complex issues

Depth Level:

Comprehensive (from basic maintenance to in-depth engine and hybrid system overhauls)

Diagnostic Capability:

Advanced diagnostic procedures, including reading and interpreting live data, component testing, and troubleshooting DTCs

Wiring Diagram Detail:

High detail, including component locations, wire colors, connector pinouts, and circuit descriptions

Torque Specifications:

Detailed torque values for all critical fasteners

Alignment Specifications:

Front and rear wheel alignment specifications

Special Tools:

Identification and usage of specialized tools required for specific repair procedures

📊 Manual Specifications

File Format:

PDF

Searchability:

Likely searchable text within the PDF for efficient information retrieval

Print Quality:

High-resolution, suitable for clear printing of diagrams and text

Binding Type:

N/A (Digital PDF format)

Paper Type:

N/A (Digital PDF format)

⚙️ Engine Specifications

Engine Type:

2.5L Inline-4 (MG2) + Electric Motors (MG1/MG2)

Engine Code:

QR25DER (2.5L Atkinson cycle gasoline engine)

Hybrid System Output:

Combined system horsepower: 250 hp (approximate)

Gasoline Engine Horsepower:

182 hp @ 6000 rpm

Gasoline Engine Torque:

177 lb-ft @ 4400 rpm

Hybrid Battery Type:

Lithium-ion

Fuel Delivery:

Electronic Fuel Injection (EFI)

Fuel Type:

Premium Unleaded Gasoline

Emission Control:

Catalytic Converter, On-Board Diagnostics (OBD-II)

🔧 Transmission

Transmission Type:

Electronically Controlled Continuously Variable Transmission (E-CVT)

Drive Type:

Intelligent All-Wheel Drive (AWD)

Hybrid Integration:

Seamless integration of electric motors for torque fill, regenerative braking, and electric-only driving

Manual Mode:

Virtual shift points (simulated gears) for driver engagement

📐 Dimensions

Length:

192.3 inches

Width:

75.2 inches

Height:

67.3 inches

Wheelbase:

111.2 inches

Seating Capacity:

7 Passengers (2+3+2 configuration)

Cargo Volume Behind 3Rd Row:

15.8 cubic feet

Cargo Volume Behind 2Nd Row:

40.8 cubic feet

Cargo Volume Behind 1St Row:

76.5 cubic feet

Curb Weight:

Approx. 4,600 - 4,700 lbs

Towing Capacity:

1,000 lbs (unbraked), 1,500 lbs (braked) - Check specific configurations

🛡️ Safety Features

NHTSA Overall Rating:

Likely 4 or 5 Stars (typical for this class, check specific model year ratings)

IIHS Rating:

Likely 'Good' in most categories, check specific model year ratings

ABS:

Anti-lock Braking System

Ebd:

Electronic Brake force Distribution

Vdc:

Vehicle Dynamic Control (Traction Control & Stability Control)

Bdw:

Brake Drying

Hill Start Assist:

Hill Start Assist

Driver Assistance Suite:

Available: Intelligent Cruise Control (ICC), Forward Emergency Braking (FEB) with Pedestrian Detection, Blind Spot Warning (BSW), Rear Cross Traffic Alert (RCTA), Backup Collision Intervention (BCI)

Airbags:

Driver and front-passenger airbags, front side-impact airbags, roof-mounted curtain airbags for all rows

Seatbelts:

Three-point ELR seat belts with pretensioners and load limiters for all seating positions, LATCH system for child seats

Tire Pressure Monitoring System:

TPMS with Easy-Fill Tire Alert

💡 Technology Features

Display System:

Infiniti InTouch system with an 8-inch color touchscreen display

Audio System:

Bose® Premium Audio System with 13 speakers (standard on most trims)

Navigation:

Voice Recognition, Bluetooth Hands-Free Phone System, Streaming Audio via Bluetooth, USB and Auxiliary Input Jacks

Parking Assistance:

Around View® Monitor with Moving Object Detection (MOD)

Adaptive Features:

Intelligent Cruise Control (ICC), Predictive Forward Collision Warning (PFCW)

Smartphone Integration:

Limited smartphone integration; Bluetooth connectivity for calls and audio. Apple CarPlay/Android Auto not standard on this model year.

Remote Access:

Optional: Infiniti Connection™ services for remote vehicle diagnostics and location services

🔧 Maintenance

Oil Change Interval:

Every 5,000 miles or 6 months (whichever comes first) for synthetic oil (refer to manual for specific recommendations based on driving conditions)

Engine Air Filter Replacement:

Every 30,000 miles or as needed

Cabin Air Filter Replacement:

Every 15,000 miles or 1 year

Cvtf Fluid Change:

Refer to manual for specific CVT fluid change intervals, typically around 30,000-60,000 miles for optimal performance.

Spark Plug Replacement:

NGK Platinum or Iridium type, typically around 100,000 miles

Engine Oil Type:

SAE 0W-20 API SN or ILSAC GF-5 certified synthetic motor oil

Engine Oil Capacity:

Approx. 5.1 US quarts (with filter change)

Coolant Type:

Nissan Genuine Super Long Life Coolant (Blue) or equivalent (50/50 mixture with distilled water)

Cvtf Fluid Type:

Nissan Genuine NS-3 CVT Fluid (or specified equivalent)

Brake Fluid Type:

SAE J1703 or FMVSS No. 116 DOT 3

Cvt Reliability:

Some CVT models across various manufacturers can experience issues related to fluid degradation or component wear over time. Regular fluid maintenance is crucial.

Hybrid Battery Longevity:

While generally robust, hybrid battery longevity is a consideration for any hybrid vehicle. The manual will detail diagnostic procedures for battery health.

Infotainment System:

Occasional software glitches or connectivity issues can arise, often addressable through software updates or system resets.

📚 Vehicle History

Infiniti Genesis:

Infiniti was launched by Nissan in 1989 as a luxury division to compete with established luxury brands.

Qx60 Lineage:

The QX60 replaced the Infiniti JX35. The hybrid variant was introduced as part of the JX35/QX60 model cycle.

L50 Generation:

The L50 chassis represents the first generation of the QX60, which debuted for the 2013 model year as the JX35, with a refresh and rebranding to QX60 for 2014. The hybrid variant was part of this generation.

Manufacturing Location:

Smyrna, Tennessee, USA (Nissan North America Manufacturing Plant)

🏆 Awards & Recognition

Safety Awards:

Often received good ratings from IIHS and NHTSA for safety, contributing to its appeal as a family vehicle.
