🏷️ Basic Information

Make:

Aprilia

Model:

Mana 850

Model Designation:

NA 850 Mana

Internal Model Code:

AP811

Engine Code Family:

V2 Motori

👋 Introduction

Category:

Sport Touring Motorcycle / Automatic Transmission Motorcycle

Target Audience:

Riders seeking a versatile motorcycle with automatic transmission, ease of use, and Aprilia's performance heritage.

Key Competitors:

Other motorcycles featuring automatic or semi-automatic transmissions, or those offering a comfortable and practical riding experience for commuting and touring.

Unique Selling Proposition:

The Mana 850's standout feature is its unique CVT transmission, offering automatic shifting and a dedicated storage compartment where a traditional fuel tank would be. This manual covers this innovative system in detail.

Design Philosophy:

Designed for accessibility and versatility, blending sporty performance with practical features for daily use and light touring.

📋 Manual Details

Primary Coverage:

Workshop Repair and Maintenance

Additional Coverage:

Troubleshooting, Diagnostics, Schematics

Estimated Pages:

Approximately 300-400 pages (typical for a comprehensive workshop manual)

Type:

Workshop Service Manual / Repair Manual

Language:

English

Format:

Digital (PDF)

📖 Manual Coverage

Engine:

Complete disassembly, assembly, inspection, and repair of the V-twin engine, including valve clearance, timing, lubrication system, cooling system, and fuel injection system.

Transmission:

Detailed procedures for the unique CVT (Continuously Variable Transmission) system, including belt inspection/replacement, variator maintenance, and oil changes. Also covers chain drive maintenance and adjustment.

Chassis And Frame:

Frame inspection, suspension system (front fork overhaul, rear shock absorber service), steering system maintenance, wheel bearing service, and spoke wheel maintenance.

Braking System:

Front and rear brake system service, including caliper overhaul, brake pad replacement, brake fluid flush and bleed, master cylinder service, and ABS system diagnostics and repair (if equipped).

Electrical System:

Wiring diagrams, component testing (starter, alternator, ignition system, lighting, instruments), battery maintenance, fuse box layout, and ECU diagnostics.

Fuel System:

Fuel tank removal/installation, fuel pump inspection, fuel filter replacement, and fuel injector service.

Cooling System:

Radiator service, coolant replacement, thermostat testing, water pump inspection, and cooling fan operation troubleshooting.

Bodywork And Trim:

Fairing removal/installation, seat servicing, luggage compartment access, and cosmetic component maintenance.

Routine Maintenance:

Oil and filter changes, air filter replacement, spark plug replacement, chain adjustment, brake system checks, tire pressure checks.

Troubleshooting:

Step-by-step diagnostic procedures for common problems, symptom-based fault finding, and error code interpretation.

Repair And Rebuild:

Detailed instructions for engine overhauls, transmission component replacement, suspension repairs, brake system rebuilds, and electrical component replacement.

Component Removal Installation:

Comprehensive guides for removing and reinstalling major and minor components for servicing or replacement.

Depth:

Comprehensive, covering all aspects from basic maintenance to full engine and transmission rebuilds, including detailed torque specifications and clearances.

📊 Manual Specifications

File Type:

Portable Document Format (PDF)

Searchability:

Searchable text for quick information retrieval.

Printable:

Printable pages for workshop use.

Image Resolution:

High-resolution images and diagrams for clarity.

Binding:

N/A (Digital format)

Paper:

N/A (Digital format)

⚙️ Engine Specifications

Engine Type:

Liquid-cooled, four-stroke, 90-degree V-twin

Displacement:

839.3 cc

Bore X Stroke:

92 mm x 63 mm

Valve Train:

SOHC, 4 valves per cylinder

Horsepower:

Approximately 76 HP (56 kW) at 8,000 rpm (depending on variant/market)

Torque:

Approximately 75 Nm (55 lb-ft) at 6,000 rpm (depending on variant/market)

Fuel Delivery:

Electronic Fuel Injection (MPI - Multi-Point Injection)

Fuel Type:

Unleaded gasoline (Octane rating typically 95 RON)

Cooling Type:

Liquid-cooled

Oil Type:

Synthetic motorcycle oil, SAE 10W-40 or 15W-50 (refer to specific manual for exact API/JASO rating)

Oil Capacity:

Approximately 2.4 liters (2.5 US qt) for engine oil, 0.4 liters (0.4 US qt) for CVT transmission fluid.

🔧 Transmission

Transmission Type:

Continuously Variable Transmission (CVT) - Automatic

Cvvt Modes:

Automatic and Manual (sequential shifting via handlebar buttons)

Final Drive:

Chain drive (rear sprocked and chain maintenance covered)

Cvvt Fluid Type:

Specific CVT fluid (refer to manual for part number/specification)

📐 Dimensions

Length:

Approximately 2150 mm (84.6 in)

Width:

Approximately 760 mm (29.9 in)

Height:

Approximately 1140 mm (44.9 in)

Wheelbase:

Approximately 1500 mm (59.1 in)

Dry Weight:

Approximately 215 kg (474 lbs)

Wet Weight:

Approximately 230 kg (507 lbs)

Storage Compartment:

Unique under-seat 'tank' storage compartment (approx. 15 liters), with electrical outlet.

🛡️ Safety Features

Crash Test Data:

N/A (Motorcycle safety ratings are generally not comparable to automotive crash tests; focus is on rider protection features).

Braking System:

Dual 320 mm front discs with 4-piston calipers, 280 mm rear disc with 2-piston caliper. Optional ABS available.

Lighting:

Halogen headlight, LED tail light.

Frame Construction:

Steel trellis frame for rigidity.

Ergonomics:

Comfort-oriented riding position designed for longer distances.

💡 Technology Features

Instrument Cluster:

Digital LCD instrument panel with speedometer, tachometer, fuel gauge, gear indicator (for manual mode), clock, and diagnostic indicators.

ABS:

Optional Anti-lock Braking System (ABS) available on some models.

Power Outlet:

12V power outlet located in the storage compartment, useful for charging devices.

🔧 Maintenance

Oil Filter Change:

Every 7,500 km (4,660 miles) or 12 months.

Air Filter Replacement:

Every 15,000 km (9,320 miles).

Spark Plug Replacement:

Every 15,000 km (9,320 miles).

Valve Clearance Check:

Every 20,000 km (12,430 miles).

Cvvt Belt Inspection:

Inspect every 10,000 km (6,215 miles), replacement interval as per manual based on wear.

Engine Oil:

API SG/SH/SJ or higher, JASO MA certified, SAE 10W-40 or 15W-50.

Brake Fluid:

DOT 4 (or DOT 5.1 as per manual for ABS models).

Coolant:

Ethylene glycol based coolant, 50/50 mix with distilled water.

Cvvt System:

While generally robust, CVT belt wear and proper fluid maintenance are critical. Occasional issues with variator operation if not serviced.

Electrical Connectors:

As with many motorcycles, corrosion or loosening of electrical connectors can cause intermittent issues. Manual covers tracing and cleaning.

Fuel Pump:

Some users report potential fuel pump issues over time, detailed testing procedures are in the manual.

📚 Vehicle History

Manufacturer:

Aprilia is an Italian motorcycle manufacturer known for its racing heritage and innovative designs.

Introduction Year:

The Mana 850 was introduced in 2007.

Variants:

Available in standard and GT (Grand Tourismo) versions, with some minor differences in equipment.

Production Period:

Produced from 2007 until approximately 2016.

🏆 Awards & Recognition

Industry Acclaim:

Praised for its innovative automatic transmission and practicality, making motorcycling more accessible.

Rider Reviews:

Generally positive reviews for comfort, ease of use, and unique features, with some critiques on weight and engine refinement compared to competitors.
