Target Audience:
DIY enthusiasts and experienced motorcycle mechanics
Manual Advantage:
Factory-level detail, comprehensive coverage, immediate download eliminates shipping delays
Content Format:
Step-by-step instructions, diagrams, illustrations, wiring schematics
Ease Of Use:
Designed for both novice and expert mechanics, clear exploded diagrams
Engine And Components:
Engine overhaul, cylinder head, crankshaft, pistons, valves, timing, lubrication, cooling
Fuel System:
Carburetor (Mikuni BS32) tuning and overhaul, fuel pump, fuel lines, fuel tank maintenance
Electrical System:
Wiring diagrams, ignition system, starting system, charging system, lighting, instruments, battery
Drivetrain:
Clutch operation and replacement, gearbox disassembly and assembly, rear wheel drive shaft, sprockets, chain maintenance
Suspension And Steering:
Front fork (conventional telescopic) service, rear shock absorber, steering head bearings, fork seals and oil
Braking System:
Front and rear brake caliper service, master cylinders, brake lines, bleeding procedures, pad replacement
Wheels And Tires:
Wheel bearing inspection and replacement, tire pressure, tube service, spoke maintenance
Frame And Bodywork:
Frame integrity checks, seat removal and installation, body panel maintenance, exhaust system inspection
Routine Maintenance:
Oil changes, filter replacements, chain adjustment, spark plug service, fluid checks, valve clearance adjustment
Troubleshooting:
Diagnostic procedures for common issues, electrical fault finding, engine performance problems
Repair And Rebuild:
Detailed step-by-step instructions for component overhaul and replacement
Technical Data And Specs:
Tightening torques, fluid capacities, specifications for all major components
Electrical Diagnostics:
Wiring diagrams with component identification for troubleshooting
Depth:
Comprehensive - covers everything from routine maintenance to complete engine and transmission rebuilds
Engine Type:
Single-cylinder, four-stroke
Displacement:
652 cc (40 cu. in.)
Bore X Stroke:
100 mm x 83 mm (3.94 x 3.27 in)
Horsepower:
Approximately 45 hp @ 6500 rpm (Varies slightly by market and specific model year)
Torque:
Approximately 52 Nm (38 lb-ft) @ 4500 rpm (Varies slightly)
Carburetor Model:
Mikuni BS32 (CV type)
Fuel Type:
Unleaded gasoline (minimum 91 octane recommended)
Cooling Method:
Liquid-cooled
Oil Type:
SAE 10W-40 motorcycle oil (API SG or higher recommended)
Oil Capacity:
Approximately 2.3 liters (2.4 quarts) with filter change
Length:
Approx. 2185 mm (86.0 in)
Width:
Approx. 880 mm (34.6 in)
Height:
Approx. 1380 mm (54.3 in) (to handlebar grips)
Wheelbase:
Approx. 1470 mm (57.9 in)
Dry Weight:
Approx. 189 kg (417 lbs)
Wet Weight:
Approx. 207 kg (456 lbs) (with fluids)
Gross Vehicle Weight Rating Gvwr:
N/A (Typically not specified for motorcycles in this manner)
Safety Features:
Disc brakes front and rear, robust frame construction, durable suspension components
Active Safety:
Responsive braking system, stable handling characteristics
Passive Safety:
Frame integrity, rider position for visibility
Oil Change Interval:
Every 6,000 km (3,700 miles) or annually
Valve Clearance Check:
Every 12,000 km (7,500 miles)
Spark Plug Replacement:
Every 12,000 km (7,500 miles)
Chain Adjustment:
As needed, check slack regularly (typically 20-30 mm)
Coolant Type:
Ethylene glycol-based antifreeze mixture (50% coolant, 50% distilled water)
Common Maintenance Points:
Regular cleaning and lubrication of the chain, checking fork oil levels and seals, carburetor synchronization and cleaning can be beneficial for optimal performance.
Potential Wear Items:
Clutch plates, brake pads, wheel bearings, fork seals, chain and sprockets.
Bmw Motorcycle Legacy:
BMW has a long history of producing robust and reliable motorcycles, known for engineering excellence and durability.
F650 Introduction:
The F650 was BMW's first single-cylinder motorcycle in decades, designed as an accessible and versatile dual-purpose machine, often referred to as the 'Funduro' or 'Classic'.
F650 Partnerships:
Developed in collaboration with Rotax (Austria), who manufactured the engine.
Manufacturing Location:
Assembly in Berlin, Germany (BMW Motorrad)
