Positioning:
Premium compact luxury sports sedan, competing with BMW 3 Series, Audi A4, Mercedes-Benz C-Class.
Segment Competitors:
BMW 3 Series, Audi A4, Mercedes-Benz C-Class, Lexus IS, Acura ILX.
Platform:
Alpha platform, rear-wheel drive biased (with optional all-wheel drive).
Design Philosophy:
Emphasis on driving dynamics, lightweight construction, and driver-focused interior.
Coverage Summary:
Comprehensive service and repair for all models and all repairs A-Z.
Model Variants Covered:
All trim levels and configurations of the 2013-2017 Cadillac ATS.
Estimated Page Count:
Extensive (exact count not specified, but implies comprehensive dealership-level detail).
Type:
Factory Service Manual / Repair Manual
File Delivery:
Speed Download
Engine Management:
Engine control system, fuel service specifications, emission control, intake, exhaust, cooling, lube, ignition, starting, charging.
Drivetrain:
Automatic transmission, manual transmission, transfer propeller shaft, drive shaft, differential, axle, suspension.
Brakes Steering:
Brake control, brake systems, parking brake, steering column, power steering.
Chassis Body:
Tire & wheel, exterior & interior components, engine hood/door, windshield/glass mirror.
Electrical Electronics:
Electrical systems, multiplex/CAN communication, supplemental restraint system (SRS), seat belts, engine immobilizer, cruise control, wiper & washer, door locks, meter audio/visual, horn, instrument panel.
Comfort Convenience:
Air conditioning, seats.
Diagnostics:
Diagnostic procedures for all major systems.
Maintenance:
Scheduled maintenance procedures and recommendations.
Repair:
Complete step-by-step repair instructions for all components.
Troubleshooting:
Troubleshooting guides for common and complex issues.
Depth:
Dealership-level, factory-accurate, including complete rebuilds and advanced diagnostics.
Illustrations:
Detailed diagrams and illustrations for clarity.
Schematics:
Wiring schematics included for electrical systems.
Specifications:
Comprehensive technical specifications for all components and systems.
Searchability:
Likely searchable text content within PDF for ease of use.
Printability:
All pages are printable.
Zoom Capability:
Images can be blown up for enlarged copies.
Binding:
Digital (PDF) - No physical binding.
Paper Type:
N/A (Digital format)
Operating Systems:
Windows Vista (32 and 64), XP, ME, 98, NT, 2000, and Mac.
Software Requirements:
Adobe PDF Reader, Winzip (free online).
Engine Options:
2.0L Turbocharged Inline-4, 3.6L Naturally Aspirated V6 (later models also offered a 2.0L Turbocharged V6 as the ATS-V).
2.0L Turbo I4 (Example Spec):
Approx. 272 hp @ 5500 rpm, 295 lb-ft torque @ 1700-5500 rpm.
3.6L V6 (Example Spec):
Approx. 321 hp @ 6800 rpm, 275 lb-ft torque @ 4800 rpm.
Fuel Delivery:
Direct Injection
Engine Code Example:
LF3 (for 3.6L Twin-Turbo V6 in ATS-V, but manual covers standard engines too)
Transmission Options:
6-speed manual (M3R), 8-speed automatic (8L45, 8L90).
All Wheel Drive:
Available on most models with automatic transmission.
Automatic Features:
Driver Shift Control (paddle shifters on some models), various drive modes.
Wheelbase:
Approximately 109.9 inches (2791 mm).
Length:
Approximately 182.8 inches (4643 mm).
Width:
Approximately 71.1 inches (1806 mm).
Height:
Approximately 56.2 inches (1427 mm).
Curb Weight:
Ranging from approximately 3,300 lbs (1497 kg) for RWD models to over 3,600 lbs (1633 kg) for AWD models.
Gross Vehicle Weight Rating:
Varies by configuration (detailed in manual).
NHTSA Rating:
Generally received 5-star overall safety ratings from NHTSA for various model years within the range.
IIHS Rating:
Achieved 'Good' ratings in IIHS crashworthiness tests, often earning Top Safety Pick designations.
Active Safety Systems:
Available features include Forward Collision Alert, Lane Departure Warning, Lane Keep Assist, Blind Spot Monitoring, Rear Cross-Traffic Alert, Adaptive Cruise Control.
Passive Safety Features:
Advanced airbag system (front, side, curtain), anti-lock braking system (ABS), traction control (TCS), electronic stability control (ESC).
Seat Belt Pretensioners:
Included as standard.
Infotainment System:
CUE (Cadillac User Experience) infotainment system with touchscreen, voice recognition, Bluetooth, and available navigation.
Display Size:
8-inch color touchscreen (standard on most models).
Driver Assistance Availability:
Many advanced driver-assistance systems (ADAS) were available as options or part of packages, including those listed in safety features.
Connectivity Features:
Available built-in Wi-Fi hotspot (OnStar 4G LTE), USB ports, auxiliary audio input.
Oil Change Interval:
Typically every 7,500 miles (12,000 km) or 12 months, whichever comes first, with synthetic oil. Consult manual for specific engine/oil type.
Tire Rotation Interval:
Recommended every 7,500 miles (12,000 km) or with every oil change.
Brake Fluid Flush:
Recommended every 2-3 years or as indicated by the vehicle's maintenance monitor.
Engine Oil Type:
Dexos1 Gen2 0W-20 Synthetic (for 2.0T and 3.6L naturally aspirated). Manual will specify exact GM dexos specification.
Transmission Fluid Automatic:
Dexron ULV (for 8-speed transmissions). Specific procedure and fluid type detailed in manual.
Coolant Type:
GM Super Coolant (P/N 88867070 or equivalent) - Orange colored, ethylene glycol based.
Brake Fluid Type:
DOT 3 or DOT 4 (check manual for exact spec, often DOT 4 LV for ABS systems).
Common Issues Potential:
Occasional reports of turbocharger issues on the 2.0T, potential for water pump leaks, and HVAC system glitches. Suspension components can wear over time. Detailed diagnostic procedures in the manual address these.
Cadillac Heritage:
Long-standing American luxury automotive manufacturer known for innovation and comfort, evolving towards performance and driver engagement.
Ats Introduction:
The Cadillac ATS was introduced for the 2013 model year as Cadillac's entry into the compact luxury sedan segment, designed to compete directly with European rivals.
Platform Development:
Built on the Alpha platform, which was lauded for its lightweight construction and chassis tuning, contributing to excellent handling characteristics.
Manufacturing Locations:
Primarily produced at the General Motors Lansing Grand River Assembly Plant in Lansing, Michigan, USA.
