Positioning:
The 2009 Chevrolet Silverado 1500 is a leading half-ton pickup truck known for its robust construction, towing capabilities, and versatility, competing against models like the Ford F-150 and Ram 1500.
Key Competitors:
Ford F-150, Dodge Ram 1500, Toyota Tundra, Nissan Titan.
Unique Selling Points:
Known for its strong V8 engine options, comfortable ride, and durable platform, the Silverado 1500 of this era is a popular choice for both work and personal use.
Primary Coverage:
Service, Repair, Maintenance, Diagnostics, Wiring Diagrams, Specifications
Estimated Page Count:
Extensive (Digital format, not a fixed page count)
Type:
Factory-Derived Service and Repair Manual
Format:
Digital Download (PDF)
Engine:
Covers all major engine components, diagnostics, and repair procedures for all available engine variants.
Drivetrain:
Detailed coverage of transmission (automatic and manual), transfer case, differentials, drive axles, and CV joints.
Brakes:
Comprehensive information on hydraulic systems, ABS, EBD, brake pad/rotor replacement, caliper service, and bleeding procedures.
Suspension Steering:
Covers front and rear suspension components, steering system, power steering, alignment specifications, and component replacement.
Electrical Electronics:
Includes detailed wiring diagrams, component testing, diagnostics for body control modules, Powertrain Control Module (PCM), and various electrical systems.
Heating Air Conditioning:
Covers refrigerant systems, A/C compressor, climate control modules, blower motor, and leak detection procedures.
Body Chassis:
Information on body panels, doors, glass, bumpers, interior trim, and structural components.
Maintenance:
Detailed scheduled maintenance procedures, fluid changes, filter replacements, and inspections.
Troubleshooting:
Diagnostic procedures, symptom-based troubleshooting charts, and fault code explanations.
Repair:
Step-by-step repair instructions for virtually every component and system of the vehicle.
Installation Replacement:
Instructions for removing and installing major components and replacement parts.
Depth:
Comprehensive from basic DIY maintenance to advanced diagnostic and repair procedures requiring specialized tools.
Quality:
High-resolution, clear text and diagrams, optimized for digital viewing and printing.
Binding:
N/A (Digital Download)
Paper:
N/A (Digital Download)
Device Compatibility:
Compatible with PC, laptop, smartphone, and tablet via web browser.
Subscription Period:
1-year access included, with discounts for extended access.
Engine Options:
4.8L V8 (LH8), 5.3L V8 (LMG/LY5), 6.0L V8 (L76/L96) - Gas
Horsepower 4.8L:
Approx. 295 hp @ 5600 rpm
Torque 4.8L:
Approx. 305 lb-ft @ 4600 rpm
Horsepower 5.3L:
Approx. 315 hp @ 5200 rpm
Torque 5.3L:
Approx. 338 lb-ft @ 4400 rpm
Horsepower 6.0L:
Approx. 367 hp @ 5400 rpm
Torque 6.0L:
Approx. 375 lb-ft @ 4300 rpm
Injection Type:
Sequential Fuel Injection (SFI) with Active Fuel Management (AFM) on 5.3L and 6.0L engines.
Engine Codes Covered:
LH8, LMG, LY5, L76, L96
Transmission Type Std:
4-speed automatic (4L60-E or 4L70-E depending on configuration)
Transmission Type Opt:
6-speed automatic (6L80-E/6L90-E for certain 6.0L and heavy-duty configurations) or 4-speed manual (less common for 1500 models)
Transmission Features:
Includes details on Tow/Haul mode, electronic control, and diagnostic procedures for automatic transmissions.
Wheelbase Std:
Approx. 119.7 inches (Regular Cab, Short Bed)
Wheelbase Extended:
Approx. 133.7 inches (Extended Cab, Standard Bed; Crew Cab, Short Bed)
Wheelbase Longest:
Approx. 143.5 inches (Crew Cab, Long Bed)
Curb Weight Range:
Approx. 4,800 - 5,500 lbs, varying by configuration and powertrain.
Gvwr Range:
Approx. 6,900 - 7,200 lbs
NHTSA Frontal Driver:
5-Star
NHTSA Frontal Passenger:
5-Star
NHTSA Side Driver:
5-Star
NHTSA Side Passenger:
5-Star
Active Safety Features:
Anti-lock Braking System (ABS), Electronic Brake-force Distribution (EBD), Traction Control System (TCS), StabiliTrak (Electronic Stability Control - available on some trims).
Passive Safety Features:
Driver and front passenger airbags, front side-impact airbags, available roof-mounted side-curtain airbags.
Infotainment Options:
Optional AM/FM/CD/MP3 stereo with auxiliary input, available Bose premium audio system, and optional navigation system with a touch screen interface.
Available Driver Assistance:
StabiliTrak (ESC), parking assist sensors (rear), integrated trailer brake controller (available).
Connectivity Features:
Bluetooth hands-free calling (available on higher trims), USB connectivity (on select models/packages).
Oil Change Interval:
Typically every 7,500 miles or 6 months, or as indicated by the Oil Life Monitoring System (OLMS).
Engine Air Filter Replacement:
Inspect every 30,000 miles, replace as needed or every 60,000 miles.
Cabin Air Filter Replacement:
Inspect every 15,000 miles, replace as needed or every 30,000 miles.
Spark Plug Replacement:
Typically iridium spark plugs, replace at 90,000 - 100,000 miles depending on engine and specific plug type.
Engine Oil Type:
SAE 5W-30 synthetic blend or full synthetic, meeting GM specification GM6094M.
Engine Oil Capacity:
Approx. 5.5 - 6.0 quarts (5.2 - 5.7 liters) for 5.3L V8, check manual for specifics.
Transmission Fluid Type:
Dexron-VI Automatic Transmission Fluid (ATF).
Coolant Type:
GM P/N 12346290 or equivalent Orange Long-Life Coolant (OAT).
Brake Fluid Type:
DOT 3 or DOT 4 brake fluid.
Common Problems:
Active Fuel Management (AFM) lifter/camshaft issues (especially on 5.3L), occasional transmission shifting problems, exhaust manifold cracks, and some electrical component failures are reported.
Chevrolet Truck Legacy:
Chevrolet has a long and storied history in the pickup truck market, with the Silverado line evolving from the C/K series trucks, consistently focusing on durability and performance.
Silverado Generation Details:
The 2009 Silverado is part of the GMT900 platform generation (introduced for 2007), which featured a significant redesign with improved aerodynamics, updated interiors, and enhanced chassis components.
Manufacturing Locations:
Assembly plants in North America, including Fort Wayne, Indiana; Silao, Mexico; and Oshawa, Ontario, Canada.
