Segment:
Mid-size Crossover SUV
Target Audience:
Families, those seeking versatile utility and comfort
Competitors:
Ford Edge, Toyota Highlander, Honda Pilot, Nissan Murano
Vehicle Attributes:
Spacious interior, comfortable ride, available all-wheel drive, strong V6 engine
Manual Advantages:
Licensed OE data, comprehensive coverage, digital convenience, cost savings over dealership repairs.
Diagnostic Procedures:
Comprehensive diagnostic procedures
Repair Procedures:
All repair procedures
Maintenance Schedules:
Complete maintenance schedules
Electrical System:
Full electrical system and wiring diagrams
Body And Chassis:
Body and chassis repair
Comfort And Convenience:
HVAC and comfort systems
Estimated Pages:
Thousands (typical for OE-derived software)
Type:
Service and Repair Manual Software
Format:
PDF Download (Software Access)
Engine:
Engine mechanical, lubrication, cooling, fuel, ignition, emissions, and engine management
Transmission:
Automatic transmission (6T75), clutch, drivetrain components
Brakes:
Hydraulic system, ABS, traction control, parking brake
Suspension And Steering:
Front and rear suspension, steering system, power steering
Electrical:
Battery, charging system, starting system, lighting, instrumentation, body control modules, infotainment, power distribution
Body:
Exterior body panels, doors, windows, interior trim, bumpers, HVAC system
Safety Systems:
Airbag system, seat belts
Routine Maintenance:
Oil changes, filter replacements, fluid checks and top-offs, tire rotation, spark plug replacement
Troubleshooting:
Diagnostic trouble codes (DTCs), symptom-based troubleshooting guides
Major Repairs:
Engine overhaul, transmission rebuild, suspension component replacement, brake caliper replacement, steering rack replacement
Component Replacement:
Detailed steps for replacing virtually all components
Wiring Diagrams:
Comprehensive wiring schematics for all systems
Depth:
Factory-level diagnostic and repair information, suitable for professional technicians and advanced DIYers.
Transmission Type:
6-speed Automatic (6T75)
Features:
All-Wheel Drive (AWD) or Front-Wheel Drive (FWD) options
Transmission Fluid Type:
Dexron VI (Automatic Transmission Fluid)
Transmission Fluid Capacity:
Approx. 8.7 Quarts (8.2 Liters) for fill, 11.2 Quarts (10.6 Liters) for overhaul
Length:
200.0 inches (5080 mm)
Width:
78.2 inches (1986 mm)
Height:
68.9 inches (1750 mm)
Wheelbase:
118.9 inches (3020 mm)
Front Track:
67.1 inches (1704 mm)
Rear Track:
67.0 inches (1702 mm)
Curb Weight FWD:
4,654 lbs (2,111 kg)
Curb Weight AWD:
4,819 lbs (2,186 kg)
Gross Vehicle Weight Rating Gvwr:
6,411 lbs (2,908 kg)
Towing Capacity:
Up to 5,200 lbs (2,359 kg) with available trailering package
Cargo Volume Behind 3Rd Row:
24.4 cu ft (691 L)
Cargo Volume Behind 2Nd Row:
67.3 cu ft (1905 L)
Cargo Volume Behind 1St Row:
116.9 cu ft (3309 L)
NHTSA Rollover Resistance:
4/5 stars (AWD model)
IIHS Top Safety Pick:
Yes
Traction Control:
Standard
Electronic Stability Control:
Standard (StabiliTrak)
Anti Lock Braking System:
Standard (ABS)
Airbags:
Frontal, side-impact, and head curtain airbags
Seat Belts:
3-point seat belts with pretensioners
Child Seat Anchors:
LATCH system
Infotainment System:
Chevrolet MyLink (available), touch-screen display, AM/FM/CD/MP3 player, auxiliary audio input, USB connectivity, Bluetooth.
Driver Assistance Features:
Rear parking assist (available), rearview camera (available), blind-spot monitoring (available on higher trims).
Connectivity Options:
USB port, auxiliary audio input, Bluetooth for phone and audio streaming.
Oil Change Interval:
7,500 miles (12,000 km) or 6 months, whichever comes first (under normal driving conditions)
Tire Rotation Interval:
7,500 miles (12,000 km)
Cabin Air Filter Replacement:
Every 15,000 miles (24,000 km) or 12 months
Engine Air Filter Replacement:
Every 45,000 miles (72,000 km)
Spark Plug Replacement:
100,000 miles (160,000 km)
Power Steering Fluid:
GM Power Steering Fluid (or equivalent)
Windshield Washer Fluid:
Automotive windshield washer fluid
Common Problems:
Potential for transmission issues (especially early models), catalytic converter failures, water pump leaks, and steering column clunks.
Manufacturer:
Chevrolet, a division of General Motors (GM)
First Generation:
First generation introduced for the 2007 model year (as a 2007 model), with the 2009 model representing an update/evolution within this generation.
Platform Sharing:
Shares the GM Lambda platform with other GM SUVs like the Buick Enclave and GMC Acadia.
Assembly Location:
Lansing, Michigan, USA (GM Lansing Delta Township Assembly)
