🏷️ Basic Information

Make:

Ford

Model:

Escape

Year:

2013

Generation Code:

Third Generation (2013-2019)

Platform:

Ford C1

👋 Introduction

Segment:

Compact Crossover SUV

Target Audience:

Families, individuals seeking a versatile and fuel-efficient SUV.

Key Competitors:

Honda CR-V, Toyota RAV4, Mazda CX-5, Nissan Rogue, Chevrolet Equinox.

Design:

New 'Kinetic' design language, sleeker profile, modern interior.

Technology:

Available SYNC with MyFord Touch, MyKey, PowerLiftgate, Blind Spot Information System (BLIS).

Powertrain:

Choice of three engines, including EcoBoost options for enhanced fuel economy.

📋 Manual Details

General Coverage:

Comprehensive repair and service information for the 2013 Ford Escape.

Total Pages:

5640

Type:

Workshop Repair Service Manual

Language:

English

Format:

Digital (Likely PDF, though not explicitly stated, common for this volume)

📖 Manual Coverage

Powertrain:

Engine mechanical, fuel system, ignition system, exhaust system, cooling system, lubrication system, engine control systems (PCM/ECM), automatic transmission (6F35), manual transmission (if applicable, though less common for this year/model), transaxle, differentials, driveline components, AWD system.

Chassis:

Suspension (front struts, rear multi-link), steering system (electric power-assisted steering - EPAS), braking system (ABS, EBD, DSC, brake bleeding procedures, component replacement), wheels and tires.

Electrical:

Body control module (BCM), powertrain control module (PCM), infotainment system, instrument cluster, lighting (headlights, taillights, interior), power accessories (windows, locks, mirrors), audio system, navigation system, charging system (alternator, battery), starter system, fuses and relays, wiring diagrams, CAN bus communication.

Body:

Body panels, doors, hood, liftgate, interior trim, seats, HVAC system (air conditioning, heating, ventilation), safety systems (airbags, seatbelts), exterior trim, glass replacement.

Maintenance:

Scheduled maintenance, oil changes, filter replacements, fluid checks and top-offs, brake pad and rotor replacement, tire rotation and balancing, spark plug replacement, air filter replacement.

Diagnostics Troubleshooting:

Diagnostic Trouble Codes (DTCs) interpretation, symptom-based troubleshooting guides, electrical system diagnostics, fuel system diagnostics, HVAC system troubleshooting, emissions system diagnosis.

Repair Rebuild:

Engine component repair (e.g., cylinder head, pistons), transmission overhaul, brake system component replacement, suspension and steering component repair, electrical component replacement, body panel repair and replacement, HVAC system component repair.

Installation Replacement:

Replacement of major components such as engine, transmission, alternator, starter, fuel pump, radiator, AC compressor, power steering pump, suspension struts, brake calipers, body modules.

Depth:

In-depth technical information including torque specifications, diagnostic procedures, wiring diagrams, component testing methods, and detailed step-by-step repair instructions for professional technicians and advanced DIYers.

📊 Manual Specifications

Type:

Likely PDF

Searchability:

Typically searchable text for quick information retrieval.

Quality:

High-resolution diagrams and clear text for easy readability and printing.

Type:

N/A (Digital format)

Type:

N/A (Digital format)

⚙️ Engine Specifications

Engine 1 Displacement:

2.5L DOHC i-VCT Duratec

Engine 1 Cylinders:

4

Engine 1 Horsepower:

168 hp @ 4,500 rpm

Engine 1 Torque:

170 lb-ft @ 4,500 rpm

Engine 2 Displacement:

1.6L EcoBoost DOHC Ti-VCT

Engine 2 Cylinders:

4 (Turbocharged)

Engine 2 Horsepower:

178 hp @ 5,700 rpm

Engine 2 Torque:

184 lb-ft @ 2,500 rpm

Engine 3 Displacement:

2.0L EcoBoost DOHC Ti-VCT

Engine 3 Cylinders:

4 (Turbocharged)

Engine 3 Horsepower:

240 hp @ 5,500 rpm

Engine 3 Torque:

270 lb-ft @ 2,500 rpm

Type:

Electronic Fuel Injection (EFI)

Fuel Type:

Unleaded Gasoline (87 octane recommended, higher for EcoBoost for optimal performance)

Coolant Type:

Ford Premium Engine Coolant (Yellow) or equivalent G12/G12+ specification

🔧 Transmission

Transmission Type:

6-Speed SelectShift Automatic Transmission (6F35)

Transmission Type:

N/A (6-speed automatic was standard across all engine options for 2013).

Selectshift:

Allows manual gear selection for driver engagement.

Fluid Type:

MERCON LV Automatic Transmission Fluid

Fluid Capacity:

Approximately 9.0 - 9.5 liters (9.5 - 10.0 quarts) for refill after transmission service.

📐 Dimensions

Length:

178.2 inches (4526 mm)

Width Without Mirrors:

72.9 inches (1852 mm)

Height:

66.5 inches (1689 mm)

Wheelbase:

104.7 inches (2659 mm)

Passenger Volume:

Approximately 100.7 cubic feet (2851 liters)

Cargo Volume Behind 2Nd Row:

Approximately 34.3 cubic feet (971 liters)

Cargo Volume Behind 1St Row:

Approximately 68.1 cubic feet (1928 liters)

Curb Weight Base Model:

Approximately 3,450 lbs (1,565 kg)

Gross Vehicle Weight Rating Gvwr:

Varies by engine/drivetrain, typically around 4,500 - 4,700 lbs (2,041 - 2,132 kg)

Max Towing Capacity:

2,000 lbs (907 kg) for 2.5L and 1.6L EcoBoost, 3,500 lbs (1,588 kg) for 2.0L EcoBoost with optional tow package.

🛡️ Safety Features

NHTSA Overall Rating:

5-Star (for models equipped with specific safety features, check VIN-specific details)

IIHS Top Safety Pick:

Yes (for models meeting specific criteria)

ABS:

Standard Anti-lock Braking System (ABS)

Esc:

Standard Electronic Stability Control (ESC) with Roll Stability Control (RSC)

Traction Control:

Standard Traction Control System (TCS)

Blind Spot:

Available Blind Spot Information System (BLIS)

Parking Assist:

Available Active Park Assist

Airbags:

Front airbags, front side-impact airbags, side-curtain airbags for front and rear occupants.

Seatbelts:

Front seatbelt pretensioners, height-adjustable shoulder belts, rear seat LATCH (Lower Anchors and Tethers for Children) system.

💡 Technology Features

System:

Available SYNC with MyFord Touch infotainment system (optional on some trims), featuring touchscreen interface, voice recognition, Bluetooth connectivity, USB ports, and optional navigation.

Audio Options:

Standard AM/FM/CD player with auxiliary input; optional premium audio systems (e.g., SONY).

Cruise Control:

Standard Cruise Control; Available Adaptive Cruise Control (on select models).

Rear View Camera:

Available Rear View Camera and Rear Parking Sensors.

Bluetooth:

Standard Bluetooth hands-free calling and audio streaming with SYNC system.

Keyless Entry:

Standard keyless entry; Available Intelligent Access with push-button start.

Liftgate:

Available Power Liftgate.

🔧 Maintenance

Oil Change Interval:

Every 7,500 miles (12,000 km) or 6 months, whichever comes first, under normal driving conditions. Severe conditions may require more frequent changes (refer to manual for details).

Air Filter Replacement:

Every 30,000 miles (48,000 km) or as needed based on driving environment.

Cabin Air Filter Replacement:

Every 15,000 miles (24,000 km) or annually.

Spark Plug Replacement:

Typically every 100,000 miles (160,000 km) for iridium spark plugs.

Transmission Fluid Change:

Typically every 100,000 miles (160,000 km) or as indicated by the powertrain control module (PCM) based on driving conditions.

Engine Oil Specification:

SAE 5W-20 meeting Ford Specification WSS-M2C945-A or WSS-M2C946-A (depending on engine). Consult manual for precise specification.

Brake Fluid Specification:

DOT 3 or DOT 4 Motor Vehicle Brake Fluid (meeting FMVSS 116).

Powertrain Common Issues:

Some reports of transmission shudder or hesitant shifting in earlier models; potential for turbocharger issues on EcoBoost engines if not maintained properly; minor coolant leaks in some cases.

Electrical Common Issues:

Occasional issues with SYNC system glitches or connectivity problems; potential for water intrusion into the liftgate area or taillight housings.

Chassis Common Issues:

Some reports of early wear on suspension components like control arm bushings or struts, particularly in vehicles driven in harsh climates.

📚 Vehicle History

Ford History:

Ford Motor Company, founded by Henry Ford in 1903, is one of the world's largest automobile manufacturers with a long history of innovation and popular vehicles.

Escape Introduction:

First introduced for the 2001 model year as a compact SUV.

Third Gen Redesign:

The 2013 model represents a complete redesign, moving to the global C1 platform, adopting new EcoBoost engine technology, and featuring a more car-like driving experience.

Manufacturing Locations:

Primarily assembled in North America (e.g., Louisville, Kentucky, USA).

🏆 Awards & Recognition

Popular Mechanics Breakthrough Awards:

The 2013 Escape's EcoBoost engines received recognition for their efficiency and performance.

Kbb Best Family Cars:

The Ford Escape has frequently been listed in automotive publications for its practicality and value.

Fuel Economy Epa:

2.5L: ~22 city/31 hwy MPG; 1.6L EcoBoost: ~23 city/33 hwy MPG; 2.0L EcoBoost: ~22 city/30 hwy MPG (FWD estimates, actual mileage may vary).
