Market Position:
The Ford Focus has historically been a strong contender in the compact car segment, known for its European-derived chassis dynamics and wide range of trim levels catering to various consumer needs, from economy to performance.
Competitors:
Competes directly with vehicles like the Honda Civic, Toyota Corolla, Volkswagen Golf, Mazda3, and Chevrolet Cruze.
Key Features 2014:
The 2014 Focus offered advanced features for its class, including SYNC infotainment, optional Active Park Assist, and a refined independent rear suspension (Control Blade) contributing to its agile handling.
Value Proposition:
This workshop manual provides owners and technicians with the necessary information to perform diagnostics, maintenance, and repairs efficiently and accurately, saving time and money compared to dealership-only servicing.
Comprehensive Coverage:
Covers all major mechanical, electrical, and body systems for the specified Ford Focus models.
Page Count:
Extensive, typically 1500+ pages for a complete workshop manual
Manual Type:
Service & Repair Workshop Manual
Format:
Digital (likely PDF)
Powertrain:
Engine (including specific variants), transmission (manual and automatic), driveline, exhaust.
Chassis:
Suspension (front and rear), steering, brakes (including ABS and electronic stability control).
Electrical:
Complete wiring diagrams, lighting, charging system, starting system, body controls, instrument cluster, comfort and convenience features, infotainment.
Body And Trim:
Body panels, doors, windows, seats, interior trim, exterior trim, bumpers, glass, sunroof.
Climate Control:
HVAC system, air conditioning, heating, ventilation.
Routine Maintenance:
Oil changes, filter replacements, fluid checks and top-ups, spark plug replacement, belt inspection and replacement.
Troubleshooting:
Diagnostic charts, symptom-based troubleshooting for various systems, fault code interpretation (OBD-II).
Repair And Overhaul:
Engine mechanical repair (e.g., cylinder head, pistons, crankshaft), transmission overhaul, brake component replacement, suspension component replacement, electrical component repair/replacement.
Diagnostics And Testing:
Component testing procedures, electrical circuit testing, pressure tests, diagnostic tool usage.
Specifications And Tolerances:
Detailed torque specifications, clearances, measurements for all serviceable components.
Depth:
In-depth diagnostic procedures, component-level repair instructions, and complete rebuild specifications, suitable for professional technicians and advanced DIY enthusiasts.
File Format:
PDF (Portable Document Format)
Print Quality:
High-resolution images, diagrams, and text for clear readability and printing.
Binding Type:
N/A (Digital format)
Paper Type:
N/A (Digital format)
Searchability:
Searchable text for quick access to specific information and keywords.
Interactivity:
Likely includes clickable table of contents and hyperlinks for navigation.
Engine Variants:
2.0L Duratec DOHC (GDI for Titanium/ST), 1.6L Ti-VCT (for lower trims, market dependent), 2.3L EcoBoost (for ST variant).
Performance 2.0L Duratec Gdi
Horsepower 2.0L Gdi:
160 hp @ 6500 rpm (Standard)
Torque 2.0L Gdi:
146 lb-ft @ 4450 rpm (Standard)
Performance 2.3L Ecoboost St
Horsepower 2.3L Ecoboost St:
252 hp @ 5500 rpm (ST)
Torque 2.3L Ecoboost St:
270 lb-ft @ 2500-4500 rpm (ST)
Fuel Delivery:
Electronic Fuel Injection (EFI), Direct Injection for GDI variants.
ECU:
PCM (Powertrain Control Module) with diagnostic capabilities (OBD-II).
Emission Controls:
Catalytic converter, oxygen sensors, EGR (Exhaust Gas Recirculation) on some variants.
Standard Transmission:
5-speed manual transmission (MTX-75 or IB5 depending on engine/market).
Optional Transmission:
6-speed PowerShift automatic dual-clutch transmission (DCT) with SelectShift functionality.
Transmission Features:
Includes detailed procedures for clutch replacement, transmission fluid changes, diagnostic checks, and torque converter procedures for automatic transmissions.
Manual Transmission Fluid:
API GL-4 SAE 75W-90 synthetic gear oil (e.g., Ford WSS-M2C200-D2).
Automatic Transmission Fluid:
Ford WSS-M2C200-D2 or equivalent (for PowerShift DCT).
Length Sedan:
Approx. 4534 mm (178.5 in)
Length Hatchback:
Approx. 4359 mm (171.6 in)
Width:
Approx. 1823 mm (71.8 in) (excluding mirrors)
Height:
Approx. 1484 mm (58.4 in) (sedan), 1477 mm (58.1 in) (hatchback)
Cargo Volume Sedan:
Approx. 13.2 cubic feet
Cargo Volume Hatchback:
Approx. 23.8 cubic feet (rear seats up)
Curb Weight:
Varies by trim and drivetrain, typically 2800-3100 lbs (1270-1406 kg)
Wheel Bolt Pattern:
5x108 mm
Tire Sizes:
Commonly 215/60R16, 215/55R17, 235/40R18 (ST)
NHTSA Overall Rating:
Typically 5-star (for models equipped with optional safety features).
IIHS Top Safety Pick:
Awarded 'Top Safety Pick' for models with good performance in crash tests.
Active Safety Features:
ABS (Anti-lock Braking System), ESC (Electronic Stability Control), Traction Control, optional Blind Spot Monitoring, optional Lane Departure Warning.
Passive Safety Features:
Front airbags, front side-impact airbags, side-curtain airbags, driver's knee airbag.
Driver Assistance Systems:
Available: Rearview camera, Active Park Assist, Cross-Traffic Alert.
Infotainment System:
Ford SYNC system (available with SYNC AppLink and MyFord Touch on higher trims) for voice control of audio, phone, and climate.
Audio System:
Standard 4-speaker or 6-speaker audio, optional 9-speaker Sony premium audio system.
Adaptive Cruise Control:
Not widely available or standard on 2014 models. Focus on Active Park Assist and Blind Spot Monitoring.
Connectivity Options:
Bluetooth for hands-free calling and audio streaming, USB ports, optional SiriusXM Satellite Radio.
Instrument Cluster Features:
Analog gauges with integrated LCD display showing vehicle information, trip computer, and warnings. ST model features sportier gauge cluster.
Oil Change Interval:
Every 5,000 to 7,500 miles (8,000 to 12,000 km) or 6 to 12 months, depending on driving conditions and oil type used. Refer to manual for specific recommendations based on oil specification.
Service Intervals Filters
Air Filter Replacement:
Every 30,000 miles (48,000 km) or as needed based on inspection.
Cabin Filter Replacement:
Every 15,000 to 30,000 miles (24,000 to 48,000 km) or annually.
Service Intervals Spark Plugs
Spark Plug Replacement:
Typically 60,000 to 100,000 miles (96,000 to 160,000 km) depending on plug type (e.g., iridium).
Engine Oil Type:
SAE 5W-20, meeting Ford specification WSS-M2C945-A (for 2.0L GDI) or WSS-M2C913-C (for 1.6L Ti-VCT).
Coolant Type:
Ford Premium Gold Coolant (or equivalent) - long-life organic acid technology (OAT), typically Ford specification WSS-M97B57-A2.
Fluid Capacities Engine Oil
Engine Oil Capacity 2.0L:
Approx. 4.5 US quarts (4.3 liters)
Coolant Capacity:
Approx. 7.5 US quarts (7.1 liters)
Common Issues:
PowerShift transmission issues (e.g., shuddering, hesitation), fuel injectors on GDI engines, potential ECU module failures, coolant leaks from plastic components, door latch actuator failures.
Ford Heritage:
Ford Motor Company, established in 1903, has a long and storied history in automotive manufacturing, known for popularizing the automobile with the Model T and continuous innovation across various segments.
Focus Generation Mk3:
The 2014 model year represents the third generation (Mk3) of the Ford Focus, which debuted in North America for the 2012 model year. This generation was globally developed on Ford's Global C platform.
Production Locations 2014:
Key assembly plants included Wayne, Michigan (USA) and Saarlouis (Germany), with production also occurring in Russia, Thailand, and Taiwan for various global markets.
IIHS Award:
IIHS Top Safety Pick for 2014.
Kbb Rating:
Generally well-regarded by automotive review sites like Kelley Blue Book for its handling, fuel economy, and feature availability.
Emissions Certification:
Meets EPA and CARB emissions standards for the 2014 model year.
