Vehicle Segment:
Mid-size Pickup Truck
Competitors:
Toyota Tacoma, Chevrolet Colorado (sister vehicle), Nissan Frontier
Manufacturer Claims:
Exceptional capability, modern features, strong towing and payload capacity, refined interior for its class.
Manual Advantage:
Vehicle-specific, technician-level accuracy, comprehensive coverage eliminating reliance on generic information, cost savings on repairs and maintenance.
Primary Coverage:
Complete Service and Repair
Scope:
All Models & All Repairs A-Z
Estimated Page Count:
Varies by specific model/configuration, but comprehensive factory documentation often exceeds 2000 pages when fully compiled. This PDF format consolidates this information.
Type:
Factory Service Manual (FSM) / Repair Manual
Format:
PDF (Portable Document Format)
Powertrain:
Engine Mechanical, Engine Control System, Fuel Service Specifications, Emission Control, Intake/Exhaust/Cooling Systems, Lube, Ignition, Starting, Charging, Automatic Transmission, Manual Transmission, Transfer Case, Driveline Components (Propeller Shaft, Drive Shaft, Differential, Axles)
Chassis:
Suspension, Tire & Wheel, Brake Control, Brake System (Hydraulic & ABS), Parking Brake, Steering Column, Power Steering
Body And Electrical:
Air Conditioning, Supplemental Restraint System (SRS), Seat Belts, Engine Immobilizer, Cruise Control, Wiper & Washer System, Door Locks, Meter & Audio/Visual Systems, Horn, Windshield/Glass/Mirrors, Instrument Panel, Seats, Engine Hood/Doors, Exterior & Interior Trim, Electrical Systems, Multiplex/CAN Communication
Maintenance:
Scheduled maintenance, fluid checks and changes, filter replacements, inspections
Diagnostics:
Troubleshooting guides, diagnostic trouble codes (DTCs), circuit testing, component diagnosis
Repair:
Step-by-step repair procedures for all major systems, component removal and installation, adjustments, rebuilds
Specifications:
Torque specifications, fluid types and capacities, clearances, diagnostic data, wiring diagrams, component locations
Depth:
Factory-level detail, suitable for professional technicians and advanced DIYers. Covers diagnostics, repair, and calibration.
๐ Manual Specifications
Searchable:
Yes (typical for well-created PDFs)
Printability:
Yes, all pages are printable
Image Resolution:
High resolution, allowing for blow-up and enlargement of diagrams and illustrations
Binding:
N/A (Digital PDF format, no physical binding)
Paper:
N/A (Digital PDF format, no physical paper)
โ๏ธ Engine Specifications
Engine Option 1:
2.5L Ecotec DOHC I-4 (LLX)
Engine Option 1 Specs:
Approx. 193 hp @ 6300 rpm, 189 lb-ft @ 4400 rpm
Engine Option 2:
3.6L LFX V6 DOHC (HFV6)
Engine Option 2 Specs:
Approx. 305 hp @ 6800 rpm, 269 lb-ft @ 4000 rpm
Fuel Type:
Unleaded Gasoline
Injection Type:
Multi-port Fuel Injection (MPI) for 2.5L, Direct Injection (DI) for 3.6L
Fuel Octane Recommendation:
87 Octane Minimum (Refer to manual for specific calibration requirements)
Standard Transmission 2015:
6-speed manual transmission (MGU) for 2.5L models
Optional Transmission 2015:
6-speed automatic transmission (MYB) with manual mode (available on both engines)
Transmission Coolant Spec:
Dexron VI Automatic Transmission Fluid (ATF) for MYB; Manual transmission fluid specification varies by type (consult manual for specifics).
Wheelbase:
3640 mm (143.3 in) for Extended Cab, 3256 mm (128.2 in) for Crew Cab
Overall Length:
Approx. 5174 mm (203.7 in) for 6ft bed, 5405 mm (212.8 in) for 5ft bed (Crew Cab)
Ground Clearance:
Varies by configuration, but typically around 8.6 inches (218 mm)
Curb Weight:
Approx. 1800-2000 kg (3968-4409 lbs) depending on configuration
Max Payload Capacity:
Up to 1,400 lbs (635 kg) depending on configuration
Max Towing Capacity:
Up to 7,000 lbs (3,175 kg) with the 3.6L V6 and towing package
NHTSA Overall Rating:
4 Stars (for 2015 models, specific ratings vary by body style and testing year)
Standard Active Safety:
Anti-lock Braking System (ABS), Traction Control, Electronic Stability Control (StabiliTrak)
Standard Passive Safety:
Driver and front passenger airbags, side-impact airbags, curtain airbags (for Crew Cab models)
Infotainment System:
Available IntelliLink infotainment system with 8-inch color touchscreen, Bluetooth connectivity, available navigation, and smartphone integration (e.g., Apple CarPlay compatibility in later iterations, though likely not for 2015 base).
Available Driver Assistance:
Rear Vision Camera, Forward Collision Alert, Lane Departure Warning (typically on higher trims or optional)
Connectivity Features:
USB ports, auxiliary audio input, available OnStar integration for emergency and convenience services.
Oil Change Interval:
7,500 miles or 6 months, whichever comes first (using synthetic oil, refer to manual for exact details based on driving conditions)
Tire Rotation Interval:
7,500 miles
Engine Air Filter Replacement:
30,000-45,000 miles or as needed based on inspection
Engine Oil Specification 25L:
SAE 0W-20 Synthetic (GM dexos1โข Gen 2 or equivalent)
Engine Oil Specification 36L:
SAE 5W-30 Synthetic (GM dexos1โข Gen 2 or equivalent)
Coolant Specification:
Dex-Coolยฎ Extended Life Antifreeze/Coolant (GM P/N 12346290 or equivalent)
Common Complaints:
Potential for minor interior rattles, early transmission issues on some units (though later models improved), occasional infotainment system glitches.
Specific Repair Focus:
The manual will provide detailed procedures for addressing these and any other known issues, including diagnostic trees for powertrain and electrical systems.
Gmc Truck Legacy:
GMC has a long-standing reputation for building durable, capable trucks, often positioned as a more premium or work-oriented alternative to Chevrolet.
Canyon Introduction:
The GMC Canyon nameplate has existed for several generations, with the 2015 model marking the debut of the second generation, developed in partnership with Isuzu.
Manufacturing Location:
Wentzville, Missouri, USA
๐ Awards & Recognition
Motor Trend Truck Of The Year:
While the 2015 Canyon did not win MotorTrend Truck of the Year (that went to the Ford F-150), it was highly praised by critics for its refinement and capability in the mid-size segment.
IIHS Safety Rating:
Good in most categories tested by IIHS (Insurance Institute for Highway Safety) for similar truck platforms, specific 2015 Canyon ratings should be verified.
