Target Audience:
DIY enthusiasts, independent repair shops, and anyone seeking professional-level repair information for their 2009 GMC Sierra 1500.
Advantage:
Offers licensed OE material in a convenient, easily accessible online format, superior to outdated printed manuals in terms of cost and usability.
Accessibility:
Compatible with PC, laptop, smartphone, and tablet devices.
Licensing:
Officially licensed, derived from OE materials, ensuring accuracy and completeness.
Access Duration:
One-year access included, with options for renewal discounts.
General Coverage:
Comprehensive service and repair information for the 2009 GMC Sierra 1500.
Estimated Page Count:
Varies by specific software version, typically thousands of pages of technical data.
Type:
Online Service and Repair Manual Software
Format:
Web-based software accessible via internet browser.
Engine:
Detailed diagnostics, repair procedures, and component specifications for all available 2009 Sierra 1500 engines.
Drivetrain:
Coverage for automatic and manual transmissions, transfer cases (if applicable), differentials, axles, and drive shafts.
Brakes:
Complete information on hydraulic systems, ABS, traction control, disc and drum brake components, and parking brake.
Suspension Steering:
Front and rear suspension systems, steering gear, power steering, alignment procedures, and wheel bearing service.
Electrical Lighting:
Wiring diagrams, electrical component locations, diagnostic procedures for lighting, starting/charging, and accessory systems.
HVAC:
Air conditioning system diagnostics, refrigerant handling, climate control systems, and heater core service.
Body Chassis:
Body panel removal/installation, interior trim, glass, doors, bumpers, and frame component service.
Safety Restraints:
Airbag system diagnostics, seat belt mechanisms, and related safety components.
Maintenance:
Routine maintenance tasks such as oil changes, filter replacements, fluid checks, and tune-ups.
Troubleshooting:
Diagnostic flowcharts and symptom-based troubleshooting guides for common and complex issues.
Repair:
Step-by-step repair instructions for all major vehicle systems and components.
Diagnostics:
Procedures for using diagnostic scan tools, interpreting trouble codes (DTCs), and performing system tests.
Depth:
OE (Original Equipment) level technical information, covering everything from basic maintenance to complete component rebuilds and advanced diagnostics.
Access Method:
Web-based, requires internet connection and compatible web browser.
Print Options:
While primarily online, users can typically print individual pages or sections.
Binding:
Not applicable (software).
Paper Quality:
Not applicable (software).
Engine Options:
Includes 4.3L V6, 4.8L V8, 5.3L V8, and 6.2L V8 engines.
4.8L V8 Horsepower:
Approximately 302 hp @ 5600 rpm
4.8L V8 Torque:
Approximately 305 lb-ft @ 4600 rpm
5.3L V8 Horsepower:
Approximately 315 hp @ 5200 rpm
5.3L V8 Torque:
Approximately 338 lb-ft @ 4400 rpm
6.2L V8 Horsepower:
Approximately 367 hp @ 5500 rpm
6.2L V8 Torque:
Approximately 375 lb-ft @ 4300 rpm
Fuel Delivery:
Electronic Fuel Injection (EFI) with Active Fuel Management (AFM) on certain V8 engines.
Engine Code Identification:
Manual provides guidance on identifying engine codes for specific engine variants.
Standard Transmission:
4-speed automatic (e.g., 4L60-E) typically standard on lower trims and V6 engines.
Optional Transmission:
6-speed automatic (e.g., 6L80, 6L90) available on V8 engines and higher trims.
Drivetrain Options:
Available in 2WD (RWD) and 4WD configurations.
Automatic Transmission Fluid Spec:
Dexron VI is the specified fluid for the 4-speed and 6-speed automatic transmissions.
Wheelbase Options:
Typically 119.0 inches (Standard Cab) and 133.0 inches (Extended/Crew Cab).
Overall Length Options:
Varies by cab and bed configuration, ranging from approximately 220 to 240 inches.
Curb Weight Range:
Approximately 4,700 to 5,500 lbs depending on configuration.
Gross Vehicle Weight Rating Gvwr:
Ranges typically from 7,000 lbs to 7,200 lbs for 1500 models.
NHTSA Frontal Crash Rating:
Generally 4 or 5 stars (varies by specific test and configuration).
NHTSA Side Crash Rating:
Generally 5 stars.
IIHS Moderate Overlap Frontal Offset:
Generally rated 'Good'.
Stability Control:
Standard StabiliTrak electronic stability control system.
Traction Control:
Standard traction control system.
Airbags:
Includes front-seat airbags, available side-curtain airbags and front-seat side-impact airbags.
Seat Belts:
All seating positions equipped with three-point seat belts.
Infotainment Options:
Available with AM/FM stereo, CD player, MP3 playback, and optional navigation systems. Higher trims may offer Bose premium audio.
Rear Parking Assist:
Available rear parking assist sensors.
Bluetooth Handsfree:
Optional Bluetooth connectivity for hands-free calling.
Oil Change Interval:
Typically every 7,500 miles or 6 months, or as indicated by the Oil Life Monitoring System.
Tire Rotation Interval:
Recommended every 7,500 miles.
Engine Air Filter Replacement:
Recommended every 45,000 miles or as needed based on conditions.
Engine Oil Spec:
Typically SAE 5W-30 synthetic blend or full synthetic for most engines. Refer to specific engine for exact type.
Coolant Spec:
GM OE specified (blue) coolant, typically a 50/50 mix of DEX-COOL antifreeze and distilled water.
Active Fuel Management Afm Lifter Wear:
Some V8 engines with AFM can experience lifter noise or failure due to oil consumption or sludge buildup. Manual provides diagnostic and repair procedures.
Transmission Hard Shifting:
Some instances of rough or delayed shifting in automatic transmissions may require software updates or transmission fluid service.
Gm Truck Legacy:
GMC has a long-standing reputation for producing durable and capable trucks dating back to the early 20th century.
Sierra Nameplate:
The Sierra nameplate was introduced in 1999, replacing the C/K series trucks. The 2007 model year introduced the redesigned GMT900 platform, which this 2009 model is part of.
Manufacturing Locations:
Produced at various General Motors assembly plants in North America, including Fort Wayne, Indiana, and Silao, Mexico.
Jdpower Dependability Ranking:
While specific rankings vary by year, GMC trucks often perform well in dependability studies for their segment.
Motor Trend Truck Of The Year:
Related GM trucks have won 'MotorTrend Truck of the Year' awards in previous generations, reflecting overall platform strength.
