Harley FLHTCU Ultra Classic Electra Glide 2011 Manual
- Regular price
- $16.99
- Sale price
- $16.99
- Regular price
-
- Unit price
- / per
🏷️ Basic Information Identification Make: Harley-Davidson Model: FLHTCU Ultra Classic Electra Glide Year: 2011 Product Name: Harley FLHTCU Ultra Classic Electra Glide 2011 Manual Product Description: Harley Davidson FLHTCU Ultra...
26 people are viewing this right now
Type: Motorcycle
Vendor:
Sku: 484398
Couldn't load pickup availability
Share
🏷️ Basic Information
Identification
Make:
Harley-Davidson
Model:
FLHTCU Ultra Classic Electra Glide
Year:
2011
Product Name:
Harley FLHTCU Ultra Classic Electra Glide 2011 Manual
Product Description:
Harley Davidson FLHTCU Ultra Classic Electra Glide 2011 Service Repair Manual PDF
👋 Introduction
Market Position
Segment:
Full-Dress Touring Motorcycle
Target Audience:
Long-distance touring riders, Harley-Davidson enthusiasts seeking in-depth maintenance and repair knowledge
Competitive Analysis
Key Competitors:
Honda Gold Wing, Indian Roadmaster, Kawasaki Vulcan Voyager
Key Features
Vehicle Features:
Powerful Twin Cam 103 engine, comfortable seating for rider and passenger, ample luggage capacity, advanced infotainment system, premium touring features
Manual Value Proposition
Value:
Empowers owners and technicians to perform maintenance and repairs efficiently, saving time and money, and ensuring optimal vehicle performance and longevity.
📋 Manual Details
Coverage Areas
Primary Coverage:
Complete Service and Repair for 2011 Harley-Davidson FLHTCU Ultra Classic Electra Glide
Page Count
Estimated Pages:
800+
Manual Type
Type:
Service Repair Manual
Language
Language:
English
Format
Format:
PDF
📖 Manual Coverage
Systems Covered
Engine:
Twin Cam 103 V-Twin Engine (Air-cooled, Pushrod, OHV, 45° V-twin)
Fuel System:
Electronic Sequential Port Fuel Injection (ESPFI)
Ignition System:
Electronic Ignition
Transmission:
6-Speed Cruise Drive Transmission
Clutch:
Hydraulic Actuated, Multi-plate Wet Clutch
Drivetrain:
Belt Drive (Primary), Belt Drive (Final)
Frame And Suspension:
Steel Tubular Frame, Air-Adjustable Rear Shocks, Showa Dual Bending Valve Front Forks
Brakes:
Hydraulic Disc Brakes (Front & Rear), Linked Braking System (LBS), Optional ABS
Electrical System:
12V System, Battery, Charging System, Lighting (Headlight, Taillight, Signals), Instrumentation, Audio System
Wheels And Tires:
Laced or Cast Aluminum Wheels, Tire Specifications and Maintenance
Body And Fairings:
Touring Fairing, Saddlebags, Tour-Pak, Windshields, Body Panel Removal and Installation
Comfort And Convenience:
Cruise Control, Fairing Vents, Rider/Passenger Comfort Features
Procedures Included
Basic Maintenance:
Oil Changes, Filter Replacement, Air Filter Cleaning/Replacement, Spark Plug Replacement, Brake Fluid Flush
Engine Repair:
Top End Rebuild (Cylinder Head, Piston), Bottom End Rebuild (Crankshaft, Connecting Rods), Camshaft Service, Valve Adjustment
Transmission Repair:
Clutch Service, Gearbox Disassembly and Reassembly, Shift Drum and Pawl Service
Brakes Repair:
Brake Caliper Service, Master Cylinder Replacement, ABS Bleeding Procedures (if equipped)
Electrical Troubleshooting:
Wiring Diagrams, Component Testing, Fault Code Diagnosis
Suspension Service:
Front Fork Seal Replacement, Rear Shock Absorber Adjustment/Replacement
Fuel System Service:
Fuel Injector Cleaning/Testing, Fuel Pump Service
Cooling System Maintenance:
Air Cooling System Checks (for overheating)
Diagnostic Procedures:
Using Harley-Davidson Digital Technician (DT) or equivalent diagnostic tools
Special Tool Usage:
Procedures and diagrams for specific Harley-Davidson tools required for repairs
Technical Depth
Depth:
Comprehensive Service and Repair
Level Of Detail:
Step-by-step instructions, detailed diagrams, torque specifications, clearances, and troubleshooting guides
📊 Manual Specifications
File Format
File Type:
PDF (Portable Document Format)
Searchability:
Searchable text content for quick information retrieval
Print Quality
Print Readability:
High-resolution, suitable for printing individual pages or the entire manual
Binding Type
Binding:
N/A (Digital PDF)
Paper Type
Paper Quality:
N/A (Digital PDF)
⚙️ Engine Specifications
Primary Engine
Engine Type:
Air-Cooled, Twin Cam 103™, Pushrod, 45° V-Twin
Displacement:
1690 cc (103 cu. in.)
Bore X Stroke:
3.875 in. x 4.380 in. (98.4 mm x 111.3 mm)
Compression Ratio:
9.6:1
Valve Train:
Overhead Valves (OHV), Pushrod Actuated, 2 Valves per Cylinder
Performance
Peak Torque:
Approx. 102 lb-ft @ 3500 RPM (manufacturer stated, actual may vary)
Fuel System
Fuel Delivery:
Electronic Sequential Port Fuel Injection (ESPFI)
Fuel Type:
Premium Unleaded Gasoline, 91 Octane Minimum
Lubrication System
Oil Capacity:
3.0 US qt (2.8 L)
Oil Type:
Harley-Davidson Genuine V-Twin 20W-50 Synthetic (or equivalent meeting HD-360 specification)
Oil Filter Part Number
Part Number:
63796-77A (chrome), 63731-99 (black)
🔧 Transmission
Standard
Type:
6-Speed Cruise Drive
Gear Ratios:
1st: 9.593, 2nd: 6.650, 3rd: 4.938, 4th: 3.810, 5th: 3.173, 6th: 2.790
Transmission Fluid Type:
Harley-Davidson Genuine Formula Transmission Fluid (or equivalent)
Transmission Fluid Capacity:
2.7 US qt (2.5 L)
📐 Dimensions
Exterior
Length:
103.7 in. (2634 mm)
Width:
38.0 in. (965 mm)
Height:
54.5 in. (1384 mm)
Wheelbase:
64.5 in. (1638 mm)
Ground Clearance:
5.1 in. (130 mm)
Weights
Dry Weight:
838 lbs (380 kg)
Wet Weight:
874 lbs (396.4 kg) (approximate, with all fluids and full tank)
Gross Vehicle Weight Rating:
1360 lbs (617 kg)
Cargo
Saddlebag Capacity:
Approx. 2.2 cu ft per saddlebag
Tour Pak Capacity:
Approx. 3.7 cu ft
🛡️ Safety Features
Ratings
Safety Certification:
Meets DOT, ECE, and local regulations for motorcycle operation.
Active Features
Braking:
Hydraulic Disc Brakes, Optional Anti-lock Braking System (ABS), Linked Braking System (LBS)
Lighting:
Halogen Headlight, LED Taillight, Amber LED Front and Rear Turn Signals
Passive Features
Frame Construction:
High-tensile steel, triple-cradle frame designed for stability and rigidity
Wind Protection:
Large Batwing Fairing with integrated windshield for rider and passenger comfort and protection
💡 Technology Features
Infotainment
Audio System:
Boom!™ Box infotainment system with 5.25-inch speakers, AM/FM radio, CD player, CB/Intercom, and 3.5mm auxiliary input.
Display:
Integrated LCD screen for audio, navigation (optional), and vehicle information.
Connectivity:
Bluetooth connectivity for audio streaming and hands-free calling (when equipped with compatible mobile devices).
Driver Assistance
Cruise Control:
Standard Electronic Cruise Control for relaxed highway cruising.
Braking Assistance:
Optional Anti-lock Braking System (ABS) and Linked Braking System (LBS) for enhanced safety.
Comfort Features
Touring Package:
Includes full fairing, fairing lowers, large saddlebags, and Tour-Pak with passenger backrest.
🔧 Maintenance
Service Intervals
First Service:
1000 miles or 1 month, whichever comes first
Subsequent Oil Changes:
Every 5,000 miles or 6 months, whichever comes first (for synthetic oil)
Air Filter Check:
Every 5,000 miles or 6 months
Spark Plug Replacement:
Every 10,000 miles
Brake Fluid Flush:
Every 2 years (regardless of mileage)
Fluid Specifications
Engine Oil:
Harley-Davidson Genuine V-Twin 20W-50 Synthetic (or equivalent meeting HD-360 spec)
Transmission Oil:
Harley-Davidson Genuine Formula Transmission Fluid (or equivalent)
Primary Chain Case Oil:
Harley-Davidson Genuine Formula Primary Chain Case Oil (or equivalent, e.g., Syn3)
Brake Fluid:
DOT 4 (for standard ABS/non-ABS systems)
Fork Oil:
Refer to manual for specific weight and type, typically SAE 15W or 20W
Known Issues
Common Wear Items:
Clutch wear, primary chain tensioner wear (especially earlier models), exhaust flange leaks, battery charging issues (voltage regulator)
Common Issues
Electrical Gremlins:
Can occur on older bikes due to wiring harness age and moisture ingress; manual will detail diagnostic steps.
Infotainment System:
Rare software glitches or connectivity issues, solvable with firmware updates or resets detailed in the manual.
📚 Vehicle History
Brand Heritage
Brand Origin:
Founded in Milwaukee, Wisconsin, USA, in 1903. Pioneer in motorcycle manufacturing.
Model Evolution
Electra Glide Lineage:
The Electra Glide line dates back to the 1960s, evolving into the premier touring platform for Harley-Davidson.
Ultra Classic Development:
The Ultra Classic designation signifies the top-tier touring model, featuring the most amenities and comfort for extended rides.
Production
Manufacturing Location:
York, Pennsylvania, USA (primary)
🏆 Awards & Recognition
Recognitions
Touring Benchmark:
Consistently recognized as a benchmark in the large-displacement touring motorcycle segment for comfort and capability.
