🏷️ Basic Information

Make:

Harley-Davidson

Model:

Softail

Year:

2007

Platform:

Softail

Chassis Code General:

FXST/FLST Series

👋 Introduction

Positioning:

This manual is designed for owners and independent mechanics who wish to perform maintenance, diagnostics, and repairs on their 2007 Harley-Davidson Softail motorcycles. It aims to provide dealership-level repair information in an accessible digital format, saving owners significant costs associated with authorized service centers.

Comparison:

As the official factory service manual, this document is the benchmark for quality and accuracy. It surpasses generic Haynes or Clymer manuals in its depth of detail and is directly comparable to what Harley-Davidson technicians use.

Manual Advantages:

📋 Manual Details

Models Covered:

Estimated Page Count:

Varies by specific model variant, typically 500-800 pages for a complete FSM.

Type:

Official Full Workshop Service and Repair Manual (FSM)

Language:

English

Format:

PDF

📖 Manual Coverage

Major Systems:

Repair Procedures:

Depth:

Comprehensive Workshop Manual. Covers everything from basic maintenance and adjustments to complete engine and transmission overhauls. Includes detailed diagnostic procedures and repair techniques identical to those used by Harley-Davidson dealerships.

📊 Manual Specifications

Format:

PDF

Printable:

Yes, printable without restriction.

Binding Type:

N/A (Digital Download)

Paper Type:

N/A (Digital Download)

Digital Features:

⚙️ Engine Specifications

Engine Type:

Twin Cam 96 (1584cc) V-Twin

Torque Output:

Approximately 90-95 ft-lbs (122-129 Nm) at 3000 RPM (varies slightly by model).

Fuel Delivery:

Electronic Sequential Port Fuel Injection (ESPFI) for most models, some variants might still have carburetion for specific markets or earlier models, but 2007 Softails are predominantly fuel injected.

Cooling System:

Air-Cooled

Bore X Stroke:

3.750 in. x 4.375 in. (95.25 mm x 111.13 mm)

Compression Ratio:

9.2:1

🔧 Transmission

Transmission Type:

6-Speed Cruise Drive

Optional Transmissions:

N/A for 2007 Softail models.

Clutch Type:

Multi-plate, wet

Transmission Fluid Type:

Harley-Davidson Formula + Transmission Fluid or equivalent.

Primary Drive System:

3-inch, Carbon-belt primary drive

📐 Dimensions

Wheelbase:

Approx. 64.5 - 66.5 inches (1638 - 1689 mm) depending on model.

Dry Weight:

Approx. 670 - 720 lbs (304 - 327 kg) depending on model.

Gvwr:

Not typically specified by Harley-Davidson for motorcycles in the same manner as cars, but refers to the maximum loaded weight the vehicle can safely carry.

Fuel Capacity:

Approx. 5.0 gallons (18.9 L) for most Softail models.

🛡️ Safety Features

Safety Standards:

Manufactured to meet all relevant US Federal Motor Vehicle Safety Standards (FMVSS) for motorcycles.

Active Safety:

Passive Safety:

💡 Technology Features

Infotainment Systems:

Limited to basic features on most 2007 Softail models. Typically includes a speedometer, odometer, trip meters, fuel gauge, and indicator lights. Some higher-end models might have a basic radio or CD player, but not standard across the range.

Driver Assistance Features:

None typically; these are rider-operated vehicles with no electronic driver aids beyond basic lighting and braking systems.

Connectivity Features:

None.

🔧 Maintenance

Scheduled Maintenance Intervals:

Refer to the manual for precise intervals, but typically include: 1,000 miles (1,600 km) initial service, then every 5,000 miles (8,000 km) or annually for oil changes, inspections, and lubrication. More comprehensive services for engine, transmission, and belt drive occur at higher mileage intervals.

Engine Oil Type:

Harley-Davidson 20W-50 SYN3 Synthetic Motorcycle Oil or equivalent meeting H-D specifications.

Primary Chain Case Fluid:

Harley-Davidson Formula + Transmission Fluid or equivalent.

Brake Fluid Type:

DOT 4 Hydraulic Brake Fluid (ensure clean reservoir and fresh fluid).

Common Wear Items:

Troubleshooting Areas:

📚 Vehicle History

Brand Legacy:

Harley-Davidson, founded in 1903, is an iconic American motorcycle manufacturer known for its cruiser and touring motorcycles, characterized by their V-twin engines, distinctive styling, and strong rider community.

Softail Lineage:

The Softail platform, introduced in 1983, mimics the appearance of a hardtail frame but incorporates hidden rear shock absorbers, providing modern suspension comfort while maintaining a classic rigid look. The Twin Cam engine became standard in the Softail line starting in the late 1990s, evolving into the Twin Cam 96 for 2007.

Manufacturing Location:

United States (various Harley-Davidson plants).

🏆 Awards & Recognition

Industry Recognition:

Harley-Davidson motorcycles, and specifically the Softail line, have consistently received accolades for their styling, riding experience, and iconic status within the motorcycling community. Specific awards for the 2007 model year would be tied to enthusiast reviews and general brand recognition.
