Holden WM Statesman & Caprice Workshop Manual

Regular price: $17.99
Sale price: $17.99
Regular price
Unit price: per

🏷️ Basic Information Identification Make: Holden Model: Caprice Generation: WM Series II Codes Chassis Code: WM 👋 Introduction Market Position Segment: Full-size Luxury Sedan Target Audience: Holden WM Statesman and...

16 people are viewing this right now

Type: Car

Vendor:

Sku: 51383

Tags: Caprice Car Cars Featured Holden WM Series WM Statesman

Product variants

Description

🏷️ Basic Information

Identification

Make:

Holden

Model:

Caprice

Generation:

WM Series II

Codes

Chassis Code:

👋 Introduction

Market Position

Segment:

Full-size Luxury Sedan

Target Audience:

Holden WM Statesman and Caprice owners seeking DIY maintenance, repair, or modification guidance

Competitive Analysis

Competitors At Launch:

Ford Fairlane/Fairmont Ghia, Toyota Avalon (in some markets)

Key Features

Value Proposition:

Provides dealer-level technical information for cost-effective vehicle ownership and maintenance.

Manual Advantage:

Contains proprietary information not readily available to the general public.

📋 Manual Details

Coverage Areas

Languages:

English

Manual Type:

Factory Service Repair Manual

Content Scope:

Comprehensive Repair, Maintenance, Diagnostics, Installation

Page Count

Estimated Page Count:

Thousands (typical for factory service manuals)

Manual Type

Format:

Digital PDF Download

📖 Manual Coverage

Systems Covered

Powertrain:

Engine, Transmission, Drivetrain

Chassis:

Suspension, Steering, Brakes

Electrical:

Wiring Diagrams, ECUs, Lighting, Audio, Security

Body:

Body Panels, Doors, Windows, Interior Trim, HVAC

Procedures Included

Maintenance:

Scheduled Maintenance, Oil Changes, Filter Replacements, Fluid Checks

Diagnostics:

Trouble Codes (DTCs), Diagnostic Procedures, Component Testing

Repair:

Engine Rebuild, Transmission Overhaul, Component Replacement, Bodywork Repair

Installation:

Accessory Installation, Component Upgrades

Technical Depth

Depth:

Factory-Level Diagnostics and Repair Procedures

Detail Level:

Step-by-step instructions, torque specifications, special tools required

📊 Manual Specifications

File Format

Format:

Compatibility:

Windows 7/8/Vista (32 & 64-bit), XP, ME, 98, NT, 2000, macOS

Required Software:

Adobe PDF Reader, WinRAR (or equivalent decompression utility)

Print Quality

Resolution:

High-resolution, suitable for printing

Image Quality:

Hundreds of clear photos and diagrams

Binding Type

Binding:

N/A (Digital Download)

Paper Type

Paper Type:

N/A (Digital Download)

⚙️ Engine Specifications

Primary Engine

Engine Code Statesman:

LLT (3.6L V6 SIDI), L76/L98 (6.0L V8)

Engine Code Caprice:

L76/L98 (6.0L V8), LSA (6.2L Supercharged V8 - later models/HSV variants)

Performance

V6 Power Output:

Approx. 260 kW (3.6L LLT)

V8 Power Output:

Approx. 260-270 kW (6.0L L76/L98), 400+ kW (6.2L LSA)

Fuel System

Fuel Delivery V6:

Sequential Multi-Port Fuel Injection (SIDI)

Fuel Delivery V8:

Multi-Point Fuel Injection (MPFI)

🔧 Transmission

Standard

V6 Transmission:

6-speed automatic (e.g., 6L50)

V8 Transmission Statesman:

6-speed automatic (e.g., 6L80)

V8 Transmission Caprice:

6-speed automatic (e.g., 6L80), 6-speed manual (HSV variants)

Features

Automatic Features:

Driver Shift Control (sequential manual mode)

📐 Dimensions

Exterior

Wheelbase:

Approx. 3009 mm (118.5 in)

Length:

Approx. 5037 mm (198.3 in)

Width:

Approx. 1849 mm (72.8 in)

Weights

Curb Weight V6:

Approx. 1770 kg (3902 lbs)

Curb Weight V8:

Approx. 1800-1850 kg (3968-4079 lbs)

🛡️ Safety Features

Ratings

Ancap Rating:

Likely 4 or 5 Stars (depending on specific year and test cycle)

Active Features

Yes, with EBD (Electronic Brakeforce Distribution)

Traction Control:

Yes (TCS)

Electronic Stability Control:

Yes (ESC/ESP)

Passive Features

Airbags:

Front, Side, Curtain Airbags

💡 Technology Features

Infotainment

Head Unit:

Color touchscreen display with audio system (CD/MP3, AM/FM)

Navigation:

Optional GPS Navigation System

Driver Assistance

Parking Assist:

Rear parking sensors, optional reversing camera

Cruise Control:

Standard Adaptive Cruise Control (on higher trims)

Connectivity

Bluetooth:

Optional Bluetooth phone connectivity

USB/Auxiliary input for audio

🔧 Maintenance

Service Intervals

Oil Change Interval:

Refer to manual (typically 10,000-15,000 km or 6-12 months)

Major Service Points:

Timing Belt (if applicable, check engine type), Spark Plugs, Coolant Flush, Transmission Fluid Change

Fluid Specifications

Engine Oil V6:

SAE 5W-30 Fully Synthetic (GM spec - e.g., dexos2)

Engine Oil V8:

SAE 10W-30/10W-40 or 5W-30 Fully Synthetic (check specific engine L76/L98/LSA)

Transmission Fluid:

Dexron-VI or equivalent for 6-speed automatics

Coolant Type:

GM-specific Long Life Coolant (e.g., Dex-Cool)

Known Issues

Common Wear Items:

Suspension bushings, ball joints, water pump (especially on V8s), ignition coils

Electrical Gremlins:

Can occur with age, particularly related to window motors, central locking, or infotainment systems.

Engine Specific:

Lifter tick on some V8 engines, potential oil leaks from valve covers.

📚 Vehicle History

Brand Heritage

Brand Origin:

Australian automotive manufacturer, originally part of General Motors

Model Evolution

Predecessor:

Holden VS, VT, VY, VZ Statesman/Caprice

Platform:

GM Zeta platform (shared with Commodore/Monaro)

Production

Production Years Wm:

2006-2013

Manufacturing Location:

Elizabeth, South Australia, Australia

🏆 Awards & Recognition

Recognitions

Awards:

Received positive reviews for ride comfort, space, and V8 performance from Australian automotive publications.

Ratings

Safety Ratings Context:

ANCAP ratings evolved over the production run; later models generally scored higher.

Certifications

Certification Level:

Factory Authorized Repair Information
